Asus Z87M-PLUS User Manual page 99

PS/2 Keyboard and Mouse Support [Auto]
Select any of these settings when PS/2 keyboard and mouse are installed. These
settings only apply when Fast Boot is enabled.
[Auto]
[Full Initialization]
[Disabled]
Network Stack Driver Support [Disabled]
[Disabled]
[Enabled]
Next Boot after AC Power Loss [Normal Boot]
[Normal Boot] Returns to normal boot on the next boot after an AC power loss.
[Fast Boot] Accelerates the boot speed on the next boot after an AC power loss.
Boot Logo Display [Enabled]
[Enabled] Enables the full screen boot logo display during POST.
[Disabled] Disables the full screen boot logo display during POST.
The following items appear only when you set the Boot Logo Display to [Enabled].
Boot Logo Size Control [Auto]
[Auto]
[Full Screen]
Post Delay Time [3 sec]
This item appears only when you set the Boot Logo Display item to [Enabled]. This
item allows you to select a desired additional POST waiting time to easily enter the
BIOS Setup. You can only execute the POST delay time during normal boot. The
values range from 0 to 10 seconds.
This feature will only work when set under normal boot.
The following items appear only when you set the Boot Logo Display to [Disabled].
Post Report [5 sec]
This item allows you to select a desired POST report waiting time. Configuration
options: [1 sec] - [10 sec] [Until Press ESC]
ASUS Z87M-PLUS
For a faster POST time, PS/2 devices will only be available when
the system boots up or rebooted when the PS/2 devices have not
been reconnected or changed. If you disconnect or change PS/2
devices before restarting the system, PS/2 devices will not be
available and BIOS setup program will not be accessible via PS/2
devices.
For full system control, PS/2 devices will be available during
POST at any circumstances. This process will extend POST time.
For the fastest POST time, all PS/2 devices will not be available
until your computer enters the operating system.
Select to skip the network stack driver from loading during POST.
Select to load the network stack driver during POST.
Automatically adjusts for Windows
Maximizes the boot logo size.
requirements.
®
3-41
