1.1.5

ASUS EZ DIY

ASUS UEFI BIOS
ASUS UEFI BIOS, a UEFI compliant architecture, offers the first mouse-controlled intuitive
graphical BIOS interface that goes beyond the traditional keyboard-only BIOS controls,
providing you with more flexibility, convenience, and easy to navigate UEFI BIOS than the
traditional BIOS versions. It offers you with dual selectable modes and native support for hard
drives larger than 2.2 TB.
ASUS UEFI BIOS includes the following new features:
• New My Favorite function allows you to quickly access the frequently used items
• New Quick Note function allows you to take notes in the BIOS environment
• New log reminder allows you to view all your modified settings
• F12 BIOS snapshot hotkey
• F3 Shortcut for most accessed information
• ASUS DRAM SPD (Serial Presence Detect) information detecting faulty DIMMs, and
helping with difficult POST situations.
USB BIOS Flashback
USB BIOS Flashback offers a hassle-free updating solution for your ultimate convenience.
Install a USB storage device containing the BIOS file, press the reset button on your chassis
for about three seconds, and the UEFI BIOS is automatically updated even without entering
the existing BIOS or operating system. It also allows you to regularly check for UEFI BIOS
updates, and download the latest BIOS automatically.
ASUS Q-shield
ASUS Q-Shield's special design makes it convenient and easy to install on your
motherboard. With better electric conductivity, it ideally protects your motherboard against
static electricity and shields it against EMI (Electronic Magnetic Interference).
ASUS Q-connector
ASUS Q-Connector is a unique adapter that allows you to easily connect or disconnect the
chassis front panel cables to one module, eliminating the hassle of plugging one cable at a
time and making the connection quick and accurate.
1.1.6

Other special features

HDMI Support
High Definition Multimedia Surface (HDMI) is a set of digital video standards that delivers
mulit-channel audio and uncompressed digital video up to 4K/2K resolution visuals through
a single cable. Supporting HDCP copy protection such as HD DVD and blu-ray discs, HDMI
provides you with the highest quality home theater experience.
ErP Ready
The motherboard is European Union's Energy-related Products (ErP) ready, and ErP requires
products to meet certain energy efficiency requirement in regards to energy consumptions.
This is in line with ASUS vision of creating environment-friendly and energy-efficient products
through product design and innovation to reduce carbon footprint of the product and thus
mitigate environmental impacts.
1-4
Chapter 1: Product introduction
