1.2.5
Expansion slots
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
Slot No.
Slot Description
1
PCIe 3.0/2.0 x16_1 slot (at x16 mode)
2
PCIe 2.0 x1_1 slot
3
PCIe 2.0 x1_2 slot
4
PCIe 2.0 x16_2 slot (run at x4 mode, compatible with PCIe x1 and x4 devices)
1-16
Z87M-PLUS
PCIEX16_1
PCIEX1_1
PCIEX1_2
PCIEX16_2
Chapter 1: Product introduction
