Alpine INE-W940 Owner's Manual

In-dash gps navigation receiver

Hide thumbs Also See for INE-W940:

Owner's manual (97 pages)

Manuel de l'utilisateur (86 pages)

Manual de usuario (84 pages)

Table Of Contents

Table of Contents

Quick Links

Need help?

Do you have a question about the INE-W940 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpine INE-W940

Page 1 You will be informed of product and software updates (if applicable), special promotions, news about Alpine, and entered for a chance to win prizes. Merci d’avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration.
Page 2 ALPINE ELECTRONICS OF AMERICA, INC. ALPINE ITALIA S.p.A. Phone 01-48638989 19145 Gramercy Place, Torrance, Viale C. Colombo 8, 20090 Trezzano ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. California 90501, U.S.A. Sul Naviglio (MI), Italy Phone 1-800-ALPINE-1 (1-800-257-4631) 161-165 Princes Highway, Hallam...
Page 3: Table Of Contents
ENGLISH Contents PTY (Program Type) Tuning ......20 Displaying Radio Text ........20 Operating Instructions CD/MP3/WMA/AAC Playback ............21 Repeat Play .............21 PRECAUTIONS M.I.X. (Random Play) ........21 Selecting Folders IMPORTANT INFORMATION ....... 7 (Concerning MP3/WMA/AAC) ....22 WARNING Searching from CD Text .........22 File/Folder Name Search Points to Observe for Safe Usage .....
Page 4 Adjusting the Touch Panel ......32 (Tuner Condition) ........42 Initializing the Touch Panel Corrected Sirius XM Setting Values ............32 (INE-W940/INE-NAV-40 only) ....42 Visual Setting ..........32 Managing Artist, Song and Sports Team Adjusting Brightness ........32 Alerts ............42 Adjusting Color of Picture ......
Page 5 About the Rear Camera Guide ......60 Hanging up the Telephone ......51 SiriusXM Satellite Radio (Optional) Calling ............51 (INE-W940/INE-NAV-40 only) Using Short Cut Dialing to Make a Call ..51 Dialing a Number in Call History ....51 Receiving Channels with the SiriusXM Dialing a Number in the Phone Book ..
Page 6 Repeat Play ............. 72 System Example ..........92 Random Play (Shuffle) ........72 LIMITED WARRANTY Random Play (Shuffle All) ......72 ® Pandora internet radio (optional) (INE-W940/INE-NAV-40 only) ® Listening to Pandora ........73 ® iPhone Pandora ......... 73 ®...
Page 7: Operating Instructions
They contain instructions on how to use this to reach your destination. The system does not reflect road product in a safe and effective manner. Alpine cannot be closures or construction, road characteristics (i.e. type of road responsible for problems resulting from failure to observe the surface, slope or grade, weight or height restrictions, etc.), traffic...
Page 8: Warning
Failure to do so may cause personal injury or damage to the in a safe location before performing these functions. Failure to do product. Return it to your authorized Alpine dealer or the nearest so may result in an accident.
Page 9: Notice
• High humidity and water • Excessive dust If you have problems, do not attempt to repair the unit yourself. • Excessive vibrations Return it to your Alpine dealer or the nearest Alpine Service Station for servicing. Correct Handling Never Attempt the Following Do not drop the disc while handling.
Page 10: Discs Playable On This Unit
This will restrict operation of these functions to times when the vehicle is parked. This ensures the focus of the driver’s attention will be on the road and not on the INE-W940/ INE-NAV-40/INE-W940S. This has been done for the safety of the driver and passengers.
Page 11 Discs that cannot be played Tips for making your own discs DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3/WMA/ The INE-W940/INE-NAV-40/INE-W940S plays DVD Video, ® AAC files), photo CDs, etc. DivX , Audio CD and has a built in MP3/WMA/AAC decoder. The following information is designed to help you create your own...
Page 12 • This unit is compatible with discs recorded in the standard DVD-Video format. Alpine accepts no responsibility for lost data, etc., even if data, etc., • Note that discs not finalized (processed to enable to play on is lost while using this product.
Page 13 • The BLUETOOTH word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under license. • “MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.”...
Page 14: Getting Started
Alpine dealer. Controllable with Remote Control • INE-W940/INE-NAV-40/INE-W940S ........1 This unit can be controlled with an optional Alpine remote control. • Power cable.................1 For details, consult your Alpine dealer. Point the optional remote • Flush head screw (M5×8)............6 control transmitter at the remote control sensor.
Page 15: Turning The System On
Turning the System On Adjusting the Volume With the Alpine system, when the ignition key is turned to ACC or ON, Adjust the volume by pressing the opening screen will be automatically displayed. Volume decreases/increases continuously by pressing and holding...
Page 16: Switching Sources
Switching Sources About Sound Menu button During audio/visual playback, press the (AUDIO) button or touch a Touch [Sound Menu] icon on the screen to change the screen to the source button in the top banner to switch to the desired source. Sound Menu screen.
Page 17: Switching The Dual Screen Display
Switching the Dual Screen Display Touch Operation When you touch on the dual screen during video playback, the You can operate the system by using the touch panel on the screen. screen size selection message is displayed. • Be sure to touch the onscreen button lightly with the pad of your Dual Wide (Initial setting) finger to protect the display.
Page 18: About The Indicator Display
About the Indicator Display The Indicator Bar at the bottom of the screen displays various types of information, like the current time. The display will differ depending on the source. For details, refer to the display example of each source. Lights up when connected to a BLUETOOTH compatible device.
Page 19: Radio/Rbds
In manual mode, touch and hold to change the frequency Radio/RBDS continuously. Presetting Stations Manually The RBDS (Radio Broadcast Data System) is a radio information system. The RBDS allows you to receive a variety of information such as traffic information, station names. Tune in a desired radio station you wish to store in the preset memory by manual or automatic seek Display example for Radio main screen...
Page 20: Pty (Program Type) Tuning
PTY (Program Type) Tuning FM Radio mode Touch [PTY Search] of Bottom banner. The Select PTY list screen is displayed. If [PTY Search] is not displayed, touch [<<] in the bottom banner to display [PTY Search]. Touch the selected program type to start searching for a station in the type.
Page 21: Cd/Mp3/Wma/Aac
] again or touch [ ] in the middle of the screen to start playback. • The INE-W940/INE-NAV-40/INE-W940S can play back MP3/WMA/ AAC files saved to CD or DVD. Use a format compliant with this unit. For further information about playing or storing MP3/WMA/AAC files, refer to pages 22 and 23 before using the unit.
Page 22: Selecting Folders (Concerning Mp3/Wma/Aac)
Selecting Folders (Concerning MP3/ About MP3/WMA/AAC WMA/AAC) CAUTION Touch [ ] or [ ] of Bottom banner to select the Except for private use, duplicating audio data (including MP3/ folder. WMA/AAC data) or distributing, transferring, or copying it, whether for free or for a fee, without permission of the copyright holder is strictly prohibited by the Copyright Act and by Searching from CD Text international treaty.
Page 23 Supported playback sampling rates and bit rates Order of files Files are played back in the order that the writing software writes them to the disc. Therefore, the playback order may not be Sampling rates: 8 kHz - 48 kHz (Disc/USB) what’s expected.
Page 24: Dvd
The DVD operation screen display Touch the screen while the DVD playback screen is displayed. The DVD operation screen is displayed. Display example for DVD Video main screen • The operation screen changes to the visual screen in the DVD mode for 5 seconds after an operation has been performed.
Page 25: Playing A Disc
The menu operation mode will be displayed. the vehicle is stopped and the emergency brake is applied. If the INE-W940/INE-NAV-40/INE-W940S is not installed correctly, the driver will be able to watch the DVD/TV/Video while driving the vehicle and may be distracted from looking ahead causing an accident.
Page 26: Numeric Keypad Input Operations
Numeric Keypad Input Operations Stopping Playback Touch [10KEY] of Bottom banner. Touch and hold [ ] for at least 2 seconds during The numeric keypad input mode screen appears playback. If [10KEY] is not displayed, touch [<<] in the bottom banner “...
Page 27: Playing Still Frames (Pausing)
Playing Still Frames (Pausing) Repeat Playback Use this function to play the disc’s titles, chapters or tracks, etc., repeatedly. During playback, Touch [ / ] of Bottom banner. Touch [ ] of Bottom banner. The repeat mode switches every time the button is touched. Touch [ / ] or [ ] in the middle of the screen to...
Page 28: Searching Directly By Chapter Number
Searching Directly by Chapter Number Switching the Angle On DVDs in which scenes have been filmed from multiple angles, the angle can be switched during playback. Use this function to easily move to the beginnings of the chapters on the Touch [ANGLE] of Bottom banner.
Page 29: About Divx
® About DivX ® DivX is a codec (software) to compress moving images while maintaining image quality using a highly advanced compression ratio and operating speed. ® • Official DivX Certified product ® ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation.
Page 30: Setup
Touch [General]. Setup Setup Operation Touch the [SETUP] icon on the Audio/Visual Playback screen to display the Setup main screen. [Setup] icon The General Setup screen appears. Select the desired item. General Setup Setting items: Language / Clock Display / Top/Bottom Banner Fade Out / General Setup Operation Screen/LED Customize / Visual / About /...
Page 31: Format Settings
Format Settings Screen/LED Customize The character code to be used for tag text information displayed on the Touch [Screen/LED Customize] on the General setup menu in step 3. screen can be selected from 6 character codes. Refer to “General Setup Operation” (page 30). Setting item: Format Sel.
Page 32: Adjusting The Touch Panel
Adjusting the Touch Panel Adjusting Brightness Setting item: Bright Adjustment becomes necessary when the display position on the LCD Setting content: -15 to +15 (Initial setting: 0) and the touch position on the touch panel do not match. You can adjust the brightness between MIN (-15) and MAX Setting item: Screen Alignment (+15).
Page 33: About Ine-W940/Ine-Nav-40/Ine-W940S
Touch [Restore Factory Setting]. You can view the version information of this product. Make note of this After the confirmation message appears, touch information and refer to it whenever you contact Alpine Tech Support or [OK]. an Alpine-authorized dealer. The confirmation screen appears again.
Page 34: Sound Setup
Touch [ ] or [ ] etc., to change its setting. Sound Setup • When the pop-up window for setup is displayed, touch [ ] to close the window after setting. Touch [ ] to return to the previous screen. Sound Setup Operation •...
Page 35: Setting The Mx (Media Xpander)
Adjusting the Crossover Settings (X-OVER) (only when Subwoofer is MX Compress Media set to “On”) This corrects information that was omitted at the time of compression. This reproduces a well-balanced sound close to • The Equalizer Presets (Factory’s EQ) settings are disabled. the original.
Page 36: Adjusting The Subwoofer Level
To store the adjusted setting value, touch and hold Adjusting the Subwoofer Level [Preset1], [Preset2], or [Preset3] for at least 2 seconds. You can set the Subwoofer level when a Subwoofer is connected. • Touch [Flat] to set all values to 0.0. Setting item: SubW.
Page 37: Adjusting The Parametric Equalizer Curve (Parametric Eq)
To store the adjusted setting value, touch and hold Adjusting the Level [Preset1], [Preset2], or [Preset3] for at least 2 Touch [ ] or [ ] of “Level” to adjust the level of selected seconds. band. • Touch [Flat] to initialize all values. Setting contents: -7 to +7 (Initial setting: 0) •...
Page 38: Rear Speaker Setting
Rear Speaker Setting About Time Correction You can set the rear speaker output to “Off.” The distance between the listener and the speakers in a car vary widely Setting item: Rear Speaker due to the complex speaker placement. This difference in the distances from the speakers to the listener creates a shift in the sounds image and Setting contents: On (Initial setting) / Off frequency characteristics.
Page 39: About The Crossover
Adjusting to a frequency range 166.6 65.7 outside that recommended may cause damage to the speakers. For the recommended crossover frequencies of Alpine speakers, refer 170.0 67.0 to the respective Owner’s Manual. We are not responsible for damage or malfunction of speakers caused...
Page 40: Source Setup
Source Setup Disc Setting [Disc] is selected on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 40). Source Setup Operation • You can perform DVD setup in DVD video mode. • Touch [Stop] before performing Disc setup. To display the Source Setup Menu screen: Changing the Language Setting Your vehicle must be parked with the ignition key in the ACC or...
Page 41: Setting Of The Subtitle Language
Set the rating level of PARENTAL Setting of the Subtitle Language 4 Touch [Parental]. Set the language of the subtitles displayed on the screen. 5 Touch [ ] on [ ] to turn “On". Select “Off” to cancel parental lock or if you do not want Setting item: SUBT.
Page 42: Radio Setting
4:3 PAN-SCAN: Sirius XM Setting (INE-W940/INE-NAV- Select this when connected to a conventional 4:3 size monitor. The picture will fill the entire TV screen. However, due to the 40 only) mismatch in aspect ratio, parts of the movie at the extreme left and right sides will not be visible (when playing a 16:9 size movie).
Page 43: Setting The Favorite Sports Team Alerts
Deleting all stored Alert Setting the Parental Lock The operation will delete all stored songs, artists and teams alert information. You can lock out channels with passcode protection. Channels that are locked cannot be accessed without entering the passcode. You can Touch [Delete All].
Page 44: Signal Strength Information
Changing the Lock Passcode Setting the Primary AUX Name (AUX Setup) Touch [Edit Code]. The numeric keypad screen is displayed. When AUX In is set to “ON”, this setting is available. Use the keypad to enter the current (old) 4-digit Setting item: Primary Name passcode.
Page 45: Setting The Aux3 Sel. (Switching The Visual Input Signal System)
Setting the AUX3 Sel. (Switching the Visual BLUETOOTH Setup Input Signal System) After setting to “AUX3” in “Setting the AUX3 In Sel.,” this setting can BLUETOOTH Setup Operation be carried out. The video input type can be changed. Setting item: AUX3 Signal Setting contents: Auto (Initial setting) / NTSC / PAL To display the BLUETOOTH Setup Menu screen: Auto:...
Page 46: Bluetooth Setting
Setting the BLUETOOTH Device BLUETOOTH Setting Select one of 3 paired BLUETOOTH compatible devices that you previously registered. [BLUETOOTH] is selected on the BLUETOOTH setup menu in step Touch [Set BLUETOOTH Device]. 3. Refer to “BLUETOOTH Setup Operation” (page 45). Setting item: BLUETOOTH Touch [Audio] or [Hands-free] of the device you Setting contents: Off / On (Initial setting)
Page 47: Setting Received Calls Automatically
Setting Received Calls Automatically Adjusting the Ring Tone Volume [Auto Answer] is selected on the BLUETOOTH setup menu in step 3. [Ring Tone Volume] is selected on the BLUETOOTH setup menu in Refer to “BLUETOOTH Setup Operation” (page 45). step 3. Refer to “BLUETOOTH Setup Operation” (page 45). When a call is received, you can set whether to answer it automatically You can adjust the volume of the incoming call.
Page 48: Camera Setup
Camera Setup AUX Camera Setting [Camera] is selected on the Camera setup menu in step 3. Refer to “Camera Setup Operation” (page 48). Camera Setup Operation Setting the Camera Input With an optional camera connected, its video is output to the monitor. When the camera is connected, set this item.
Page 49: Camera Interrupt Setting (Power Off Mode)
Adjusting guides simultaneously (for Rear camera only) Touch [Link]. The 3 vertical guides of the currently-selected guide link together, allowing them to be adjusted simultaneously. Turning guide display ON/OFF Turning the selected guide off. Touch [ON/OFF]. The currently selected guide will turn off. To turn the guide on, touch [ON/OFF] again.
Page 50: Bluetooth Operation
• You can search for this unit using a BLUETOOTH compatible device, About BLUETOOTH and then connect that BLUETOOTH compatible device to this unit. The device name of this unit is “INE-W940,” “INE-NAV-40” or BLUETOOTH is a wireless technology allowing communication “INE-W940S” and the initial number of the passcode is “0000.”...
Page 51: Changing The Connecting Bluetooth Device
Changing the connecting BLUETOOTH Calling Device Use the Phone menu screen to make a phone call. If multiple BLUETOOTH devices are registered in this device, you can Using Short Cut Dialing to Make a Call change the connection among the registered devices. You can assign up to 4 phone numbers for one-touch dialing to make a Press the (PHONE) button.
Page 52: Dialing A Number In The Phone Book
Dialing a Number in the Phone Book Adjusting the Speech Volume You can use the phone book of the mobile phone to make a phone call. You can adjust the transmit volume and receive volume respectively. Before using, you need to transfer the phone book from the mobile Touch [ ] or [ ] for “Vol.”...
Page 53: Adding The Phone Book
• You can store up to 1,000 phone numbers in the phone book. Assigning as a Short Cut Dialing Number • You can store up to 5 phone numbers by one person’s name. Adding the Phone Book Assigning from Call History Press the (PHONE) button.
Page 54: Call Waiting Function
Call Waiting Function BLUETOOTH Audio If a call comes in from another phone during a call, a notice is displayed If a BLUETOOTH compatible mobile phone, portable player, etc. is on the screen. This function can only be used if the connected mobile connected by wireless, you can play back a song (operation is phone has a call waiting function service included.
Page 55: Repeat Play
Repeat Play Available for AVRCP Ver. 1.3 and 1.4 only. Touch [ ] during playback. The repeat mode switches every time the button is touched. (FILE) (GROUP) (ALL) (OFF) • Operations may differ depending on the connected BLUETOOTH compatible device. M.I.X.
Page 56: Auxiliary Device (Optional)
Example for AUX1, AUX2, AUX3, DVD, Game mode display Operating Auxiliary Devices (Optional) To operate devices connected to the AUX terminals of INE-W940/INE- NAV-40/INE-W940S, follow the procedure described below. • Set AUX In to “On.” Refer to “Setting the AUX Mode” (page 44).
Page 57: About The Dvd Operation Screen
Menu operation mode screen display example About the DVD Operation Screen When the external DVD player playback screen is displayed, you can touch the screen to display the operation screen. For details on how to operate, refer to the Owner’s Manual of the connected DVD player. External DVD player display example [Key] The menu operation mode will be displayed.
Page 58: About The Dvd Changer Operation Screen
About the DVD Changer Operation Screen About the DVB-T Operation Screen When the External DVD changer playback screen is displayed, you can When you touch the screen in the DVB-T mode, the operation screen is touch the screen to display the operation screen. For details on how to displayed.
Page 59: Operating A Tv
Operating a TV To operate a TV Receiver (TV) (Optional), set “Setting the Primary AUX Name (AUX Setup)” (page 44) or “Setting the Secondary AUX Name” (page 44) to “TV.” Change to the TV Mode Press the (AUDIO) button. Touch [TV] of Top banner. The display shows the TV mode screen.
Page 60: Camera Operation (Optional)
Adjusting the Caution Display Location Camera Operation Touch the screen when the image from the camera is (Optional) displayed. The operation screen is displayed on the screen. • After a 5-second time-out, the operation screen returns to the camera display screen. When an optional camera is connected, the view video of camera can be output to the monitor.
Page 61 Distance guidance mark Error between the screen and the actual road surface In the following conditions, errors are produced between the screen The distance guides represent the ground level distance from the rear guidance and the actual road surface. (The illustrations represent a case bumper.
Page 62 When there is a steep downward slope behind the car (example) <Screen> <Situation of the car> Error Error In the case of a downward slope behind the car, the distance guides are displayed farther from the rear bumper than the actual distance. If there is an obstacle on the downward slope, it seems closer than its actual position.
Page 63: Siriusxm Satellite Radio (Optional)
Radio (Optional) • Refer to the SiriusXM Tuner User Guide for details on how to install the SiriusXM Tuner. (INE-W940/INE- Tuning Channels by Category NAV-40 only) Channels are grouped into categories based on the type of content heard on the channels.
Page 64: Checking The Siriusxm Radio Id Number
Checking the SiriusXM Radio ID Number Search Function To subscribe to the SiriusXM Satellite Radio service, it is necessary to Touch [ (Search)] of Bottom banner. locate and identify the Radio ID of your SiriusXM Tuner. The Radio ID Search list screen is displayed. contains 8 characters and can be found on the bottom of your SiriusXM Tuner or can be displayed on when selecting Channel 0 by following the Touch the desired category.
Page 65: Selecting The Channel Directly
Selecting the Channel Directly Receiving and Tuning to an Alert You can directly select the channel number on the display of the Whenever a stored sports team, artist, or song is playing on another numeric keypad. channel, an interruption ALERT appears on the unit display. To tune to the game, artist or song identified by the alert, follow the steps below: Touch [Direct Channel].
Page 66: Parental Lock Function
Parental Lock Function This function can help restrict the listening of channels to children of appropriate age levels only. For information on setting the Parental Control passcode, refer to “Setting the Parental Lock” (page 43). When a locked channel is selected, “Channel Locked” is displayed and then the numeric keypad appears for you to enter the passcode.
Page 67: Usb Memory (Optional)
USB Memory Playback (Optional) Press the (AUDIO) button. Touch [USB] of Top banner. The USB mode is activated and the display changes to the You can play back music files (MP3/WMA/AAC) and video files USB screen. ® (DivX ) stored in a USB memory device on the internal player of this ®...
Page 68: Random Play (M.i.x.)
The search mode screen appears. Searching for a Desired Song Touch [Artists]. The Artists search screen is displayed. INE-W940/INE-NAV-40/INE-W940S can carry out 2 kinds of searches. Select the desired artist. File/Folder Name Search To Play Back the Artist Directly 1 Touch [ ] of the artist’s name.
Page 69: Direct Up/Down Function
To Search for a Song in the Album of the Artist 1 Touch the desired artist’s name. All albums of the selected artist are displayed. Touch the desired album’s name. All songs of the selected album are displayed. Touch the desired song’s name. The selected song is played back.
Page 70 461iV (sold separately). You can connect a video-capable iPod to enjoy video as well as music. When the INE-W940/INE-NAV-40/INE-W940S is connected by the above cable, the controls on the iPod are disabled. • Internet or telephone functions, etc., of the iPhone or iPod touch are not controllable from the unit, but these functions can be controlled using the iPhone or iPod touch itself.
Page 71: Playback
All songs of the selected album are displayed. • If a song is playing on the iPod/iPhone when it is connected to the Touch the desired song’s name. INE-W940/INE-NAV-40/INE-W940S, it will continue playing after The selected song is played back. the connection.
Page 72: Alphabet Skip Function
Alphabet Skip Function Search Position Memory The unit is provided with a alphabet skip function for effective During iPod/iPhone playback, you can quickly move back up the searching. When you use this function in the search mode, you can selected hierarchy, a level at time. quickly search an artist or a song, etc.
Page 73: Pandora ® Internet Radio (Optional)
® latest version of the Pandora application installed. displayed. • INE-W940/INE-NAV-40 remembers the source just before turning off Display example for iPhone Pandora Radio screen the power. Even if you reconnect an iPhone without launching Pandora Application while the power is off, Pandora mode (not iPod mode) is displayed when power is turned back on.
Page 74: Thumbs" Feedback
• INE-W940/INE-NAV-40 remembers the source just before turning off Creating a New Station ® the power. If Pandora is the last SOURCE to be played, it will appear as the SOURCE the next time the unit is power up even if the app is not launched on your smartphone.
Page 75: Bookmarking A Desired Track Or Artist
Bookmarking a Desired Track or Artist The currently playing song or artist can be bookmarked and saved to your Pandora account. During playback, touch [Artwork display]. The type selection telop is displayed. Artwork display Touch [Track] or [Artist]. The current track or artist is bookmarked. “ ”...
Page 76: Product Software Update
* These functions differ from disc to disc. For details, refer to the disc’s This product use software that can be updated through a USB memory instructions. device. Download the software from the Alpine website and update the product using the USB memory device. Updating this product Check the Alpine website for details on updating.
Page 77: List Of Language Codes
List of Language Codes (For details, see page 40.) Language Abbreviation Langua g e Abbre viation Code Abbre viation Code Language Code 6565 Af ar 7369 Inter lingue 8278 Kirundi 6566 Abkhazian 7375 Inupiak 8279 Romanian 6570 Afr ikaans 7378 Indonesian 8285 Russian...
Page 78: List Of Country Codes
List of Country Codes (For details, see page 41.) Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 6568 Andorra 6877 Dominica 7573 Kiribati 6569 United Arab Emirates 6879 Dominican Republic 7577 Comoros Afghanistan 6890 Algeria 7578 Saint Kitts and Nevis 6570 6571 Antigua and Barbuda...
Page 79 Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 8069 Peru 8374 Svalbard and Jan Mayen 8487 Taiwan, Province of China 8070 French Polynesia 8375 Slovakia 8490 Tanzania, United Republic of 8071 Papua New Guinea 8376 Sierra Leone 8565 Ukraine 8072 Philippines 8377...
Page 80: Troubleshooting
This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is Disc properly connected, or then consult your authorized Alpine dealer. Disc playback sound is wavering. • Moisture condensation in the disc Module.
Page 81: Fault Messages
• The BLUETOOTH audio device was not connected correctly. - Turn the ignition key off, and then set to ON again. - Check the settings for INE-W940/INE-NAV-40/INE-W940S - Attempt to connect another iPod/iPhone/USB memory device. and the BLUETOOTH audio device and reconnect.
Page 82 Navigation SiriusXM The vehicle’s position is erroneous. Check Tuner • The GPS reception is poor. • The SiriusXM Tuner is disconnected or the unit is having trouble - Drive the vehicle in an area of good GPS reception to allow the communicating with the Tuner.
Page 83: Specifications
PICKUP Specifications Wave length DVD: 666 nm CD: 785 nm MONITOR SECTION Laser power CLASS II Screen Size 6.1" LCD Type Transparent type TN LCD GPS SECTION Operation System TFT active matrix GPS Reception frequency 1575.42 ±1 MHz Number of Picture Elements 1,152,000 pcs. (800 × 3 × 480) GPS Reception sensitivity -130 dB max.
Page 84: End User License Agreement (Microsoft)
INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE terms are provided, then the terms of this EULA shall IN THE DEVICE, AND MS HAS RELIED UPON ALPINE TO apply, except that MS, Microsoft Corporation or affiliate CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE entity providing the Supplemental Component(s) shall be SOFTWARE IS SUITABLE FOR SUCH USE.
Page 85: End User License Agreement (Navteq)
Should you have any questions concerning this EULA, or if you The warranty on the System shall not extend to an exchange or desire to contact ALPINE for any other reason, please refer to refund due to misspelling, omission of letters, or any other the address provided in the documentation for the DEVICE.
Page 86: Installation And Connections
INE-W940/INE-NAV-40/INE-W940S has the appropriate amperage. Failure to do so may result in damage to REACH OF CHILDREN. the unit and/or the vehicle. When in doubt, consult your Alpine Swallowing them may result in serious injury. If swallowed, dealer.
Page 87: Installation
Mounting the Microphone. Installation For safe use, make sure of the following: • location is stable and firm. • driver’s view and operations are not obstructed. • microphone is located where the driver’s voice can be easily picked up (on the sun visor, etc.). Caution Do not block the unit’s fan or heat sink, thus preventing When you speak into the microphone, you should not have...
Page 88 Chassis • For the screw marked “*2,” use an appropriate screw for the chosen mounting location. Slide the INE-W940/INE-NAV-40/INE-W940S into the dashboard until it clicks. This ensures that the unit is properly locked and will not accidentally come out from the dashboard.
Page 89 • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
Page 90: Connections
Connections Antenna Microphone (Included) (Yellow) To Video Output terminal (Red) (White) To Audio Output terminals (R, L) Rear Left Amplifier Rear Right Front Left Amplifier Front Right Subwoofers Amplifier CAMERA To Camera with RCA Output (Yellow) terminal REMOTE OUT To remote input lead (Brown) To the instrument cluster ILLUMI...
Page 91 To Microphone (Included). Right Rear (+) Speaker Output Lead (Violet) Steering Remote Control Interface Connector To steering remote control interface box. For details about connections, consult your nearest Alpine dealer. AUX/PRE OUT Connector Power Supply Connector Remote Turn-On Lead (Blue/White) Connect this lead to the remote turn-on lead of your amplifier or signal processor.
Page 92: System Example
System Example Connection of a USB Memory GPS Antenna (included) USB connector USB extension cable USB Memory (Sold separately) (Included) • Do not leave USB memory, in a vehicle for a long time. Heat and humidity may damage the USB memory. Connection of an iPod/iPhone USB connector iPod/iPhone...
Page 93 Connection of an External device To Video Output terminal DVD Player (sold separately) To Audio Output terminal DVE-5207, etc. iPod VIDEO input connector AUX/PRE OUT Connector To Video Output terminal AUX/PRE OUT cable (Yellow) (Red) DVD Changer (Sold separately) (White) To Audio Output terminal REMOTE IN REMOTE IN...
Page 94 Connection of an External Amplifier Power Supply Connector AUX/PRE OUT Connector AUX/PRE OUT cable Amplifier 4 ch (Sold separately) (Red) Input (White) Front speaker (Red) Input (White) Rear speaker Amplifier for subwoofer (Sold separately) (Red) Input Subwoofer (White) REMOTE TURN-ON REMOTE ON (Blue/White) (Blue/White)
Page 95 Connection of cameras AUX/PRE OUT Connector AUX/PRE OUT cable To Video Output terminal (Yellow) Camera with RCA video output (sold separately) HCE-C105, etc. 1 CAMERA Input RCA Connector (CAMERA) 2 RCA Extension Cable (sold separately)
