Page 1 ICQ:613-211-859 (099)048-99-03 (093)672-77-76 User's Manual Set Alpine KIT-8MBF for installation Alpine INE-W928R on Mercedes A Class W169, B Class W245, Vito, Viano, Sprinter In the online store Winauto you also can buy installation kit Alpine KIT-8MBF. Delivery in Kyiv and throughout Ukraine with payment upon receipt! winauto.ua...
Page 2 • Mercedes A-Class (W169) 2005-> KIT-8MBF / KIT-8MBI • Mercedes B-Class (T245) 2005-> KIT-8MBM • Mercedes Viano / Vito (W639 / V639) Compatible with these Alpine navigation devices INE-W928R Mounting Frames for A-Class / B-Class Mounting Frames for Viano / Vito •...
Page 3 Online-store car audio and autogoods Winauto Mercedes A-Class / B-Class Insert pulling hooks into air vent catches. Pull out air vents air vent catches Disconnect plugs for hazard light switch Remove air vents completely Unclip and remove lower panel...
Page 4 DIN head unit Connect all required circuit points and push double DIN head into dash board Clip OEM trim panel on dash board to finish installation Mount facia plate and mounting frames for A-Class / B-Class to Alpine INE-W928R...
Page 5 Online-store car audio and autogoods Winauto Mercedes A-Class / B-Class Mercedes Viano / Vito Connect all required circuit points and push Vehicle with OEM head unit. double DIN head into dash board Remove OEM trim panel surrounding the radio. Reinstall everything in reverse order to finish installation.
