Denon DVD-A1XV Operating Instructions Manual

Dvd audio-video/super audio cd player
Hide thumbs
Table of Contents

Advertisement

Quick Links

DVD AUDIO-VIDEO/SUPER AUDIO CD PLAYER
DVD-A1XV
OPERATING INSTRUCTIONS
ON / STANDBY
SELECT
OPEN/CLOSE
PLAY
STOP
STILL / PAUSE
REPEAT
RANDOM
VIDEO MODE
HDMI / DVI
SUPER
PURE
AUDIO CD
DIRECT
SELECT
FORMAT
SET UP
SELECT
SETUP
PUSH ENTER
DVD-A1XV
DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER
FORMAT
Ntsc/PAL
ANGLE
AUDIO
A-B
MARKER
ZOOM
DIMMER
PICT ADJ.
MEMORY
SELECT
RC-993

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVD-A1XV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Denon DVD-A1XV

Summary of Contents for Denon DVD-A1XV

  • Page 1 DVD AUDIO-VIDEO/SUPER AUDIO CD PLAYER DVD-A1XV OPERATING INSTRUCTIONS ON / STANDBY SELECT FORMAT NTSC/PAL ANGLE SUBTITLE AUDIO OPEN/CLOSE PLAY STOP STILL / PAUSE REPEAT RANDOM MARKER ZOOM DIMMER VIDEO MODE HDMI / DVI SUPER PURE AUDIO CD DIRECT SELECT FORMAT...
  • Page 2 Super audio CD player. Electric shock or malfunction may result. Please, record and retain the Model name and serial number of your set shown on the rating label. Model No. DVD-A1XV Serial No. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN...

  • Page 3: Laser Product

    • DECLARATION OF CONFORMITY We declare under our sole responsibility that this product, to which this declaration relates, is in conformity with the following standards: EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3. Following the provisions of 73/23/EEC, 89/336/EEC and 93/68/EEC Directive. •...
  • Page 4 NOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION / NOTE SULL’USO NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA • Avoid high temperatures. Allow for sufficient heat dispersion when installed on a rack. • Vermeiden Sie hohe Temperaturen. Beachten Sie, daß...
  • Page 5 About the operating instructions on the CD-ROM 1. Check the computer environment. • Adobe Acrobat Reader 5.0 or later is required to view the text. • If Adobe Acrobat Reader is not installed on the computer, install it from the included CD-ROM. (Adobe Reader 6.0) [Windows] AdbeRdr60_ece.exe •...
  • Page 6 Acerca de las instrucciones de funcionamiento del CD-ROM 1. Compruebe el entorno del ordenador. • Se necesita la versión del Adobe Acrobat Reader 5.0 o una superior para ver el texto. • Si la versión del Adobe Acrobat Reader no está instalada en el ordenador, instálela desde el CD-ROM suministrado.

  • Page 7: Table Of Contents

    Features...8, 9 Discs ...10 Cautions on Handling Discs...11 Connections ...12 ~ 22 Part Names and Functions...23 ~ 26 Remote Control Unit ...27 ~ 29 Loading Discs ...30 Changing the Default Settings ...31 ~ 56 Using the Pure Direct Mode...57, 58 ⁄0 Using the Super Audio CD Setup ...58 ⁄1...
  • Page 8 9. THX ® Ultra Certification, the symbol of excellent high quality (NOTE 3) The DVD-A1XV meets THX ® Ultra standards, a strict set of criteria advocated by Lucasfilm on the picture and sound quality of DVD video players and their operability with connected equipment.
  • Page 9 CDs with no loss in sound quality. 12. Dolby Digital/DTS decoder (NOTE 5, 6) The DVD-A1XV is equipped with a built-in Dolby Digital/DTS decoder, allowing you to recreate the atmosphere of a movie theater or concert hall when using the DVD-A1XV in combination with an AV amplifier and speakers.
  • Page 10 2. The DVD-A1XV cannot play DVD-R, -RW, +R and +RW discs recorded in the “VR” mode or with “CPRM”. If you wish to play images recorded using a DVD recorder on the DVD-A1XV, set the DVD recorder to the “Video mode”...

  • Page 11: Cautions On Handling Discs

    Only the discs including the marks shown on page 10 can be played on the DVD-A1XV. Note, however, that discs with special shapes (heart-shaped discs, hexagonal discs, etc.) cannot be played on the DVD-A1XV. Do not attempt to play such discs, as they may damage the player.
  • Page 12 PAL. (See pages 43, 44.) • Use the “2ch AUDIO OUT” connectors to connect a TV to the DVD-A1XV. To use with 5.1ch audio output, set “2CH (SRS OFF)” or “2CH (SRS ON)” under “AUDIO CHANNEL” in “AUDIO SETUP” on the “SETUP” menu to the initial settings. (See pages 46, 47.) •...
  • Page 13 • Set the “COMPONENT VIDEO OUT” in “VIDEO SETUP” in “SETUP” to comply with Progressive TV. • Use the “2ch AUDIO OUT” connectors to connect a TV to the DVD-A1XV. To use with 5.1ch audio output, set “2CH (SRS OFF)”...
  • Page 14 (3) Connecting to a TV with 21-pin SCART Terminal Use the commercially 21-pin SCART cable to connect the TV’s 21-pin SCART terminal to the DVD-A1XV’s 21-pin SCART terminal (AV1). DVD-A1XV NOTE: • Some discs contain copy prohibit signals. If such discs are played via a VCR, the copy prohibit system may cause disturbance in the picture.
  • Page 15 2 Sound output from the DVD-A1XV’s digital audio output connectors [ In the case of bitstream output ] Audio recording format Dolby Digital DVD video MPEG Audio [ In the case of PCM output ] Audio recording format 48 kHz / 16 ~ 24 bit...
  • Page 16 “SPEAKER CONFIGURATION”, “CHANNEL LEVEL” and “DELAY TIME” settings. (See pages 46 ~ 51.) • With the DVD-A1XV, we recommend turning the digital output off by using the “PURE DIRECT MODE” and only outputting analog signals in order to keep interference from the digital output circuitry to a minimum and allow you to enjoy high-quality multi-channel sound thanks to the high-bit, high sampling frequency.
  • Page 17 “LPCM (44.1kHz/48kHz)” “ON” Playing DVDs with incorrect settings may result noise that could damage your ears or the speakers. DVD-A1XV NOTE: • Digital audio signals cannot be output when playing Super Audio CDs. Use analog connections to record Super Audio CDs.
  • Page 18 If you want to use the analog terminals, set to “DENON LINK” to “OFF”. • The DVD-A1XV’s speaker settings are invalidated when the DENON LINK connector is connected. (Make the speaker settings on the AV amplifier to which the DVD-A1XV is connected.) •...
  • Page 19 • For IEEE1394 connection, set “IEEE1394” under ”DIGITAL INTERFACE SETUP”at “SETUP” to ”ON”. (See pages 38 ~ 42.) The DVD-A1XV’s IEEE 1394 mode is designed based on IEEE Std. 1394a-2000, Standard for a High Performance Serial Bus. IEEE 1394 network The following types of connections can be made between devices handling IEEE 1394 audio signals (A&M protocol):...
  • Page 20 TV or Monitor with “component video output” or “S-video output” or “Video output”. (See pages 12 ~ 14.) • The “IEEE 1394 audio signal (A&M protocol)” output from the DVD-A1XV’s IEEE 1394 connector can only be received on AV equipment equipped with an IEEE 1394 connector.
  • Page 21 • When selecting MULTI (NORMAL), the DVD-A1XV speaker settings under “AUDIO SETUP”become invalid. • Among the devices that support HDMI, some devices can control other devices via the HDMI connector; however, the DVD-A1XV cannot be controlled by another device via the HDMI connector.
  • Page 22 Make an audio connection also because an audio signal will not be output via the DVI-D connector. Commercially DVI cables are available in 24-pin and 29-pin types. The DVD-A1XV supports the 24-pin DVI-D cable, but the 29-pin DVI cable cannot be connected.

  • Page 23: Part Names And Functions

    HDMI / DVI SUPER PURE AUDIO CD DIRECT SELECT FORMAT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER INTERLACED OTHERS HDMI/DVI AUTO TIME:0msec TIME:+200msec channel area is played with priory channel area is played with priority.
  • Page 24 STILL / PAUSE VIDEO MODE HDMI / DVI SUPER PURE AUDIO CD DIRECT SELECT FORMAT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER : search in the reverse direction. : search in the forward direction.
  • Page 25 (2) Rear Panel 21-pin SCART terminal (AV1) • Connect using a 21-pin SCART cable (available in stores). Audio output connectors (2ch AUDIO OUT) • Connect using the included audio cord. Multi-channel sound is down-mixed and output. Component video output connectors (COMPONENT VIDEO OUT) •...
  • Page 26 (3) Display SUPER DVD GROUP TITLE TRACK CHAP ANGLE D.MIX PROG RAND TOTAL SING AUDIO VCD 1 A-B PROGRESSIVE Lights to indicate the currently playing disc. Lights in the repeat play mode. These light to indicate the names of sections of the disc being played.

  • Page 27: Remote Control Unit

    6 REMOTE CONTROL UNIT 2 The DVD-A1XV can be controlled from a distance using the included remote control unit (RC-993). (1) Inserting Batteries q Remove the remote control unit’s rear cover. w Place three R6P/AA batteries in the battery compartment in the direction indicated by the marks.
  • Page 28 (3) Names and Functions of Remote Control Unit Buttons 2 Button not explained here function in the same way as the corresponding buttons on the main unit. SELECT FORMAT NTSC/PAL ANGLE SUBTITLE REPEAT RANDOM MARKER ZOOM DIMMER SETUP PICT ADJ. MEMORY SELECT RC-993...
  • Page 29 SELECT FORMAT NTSC/PAL ANGLE SUBTITLE AUDIO REPEAT RANDOM MARKER ZOOM DIMMER SETUP PICT ADJ. MEMORY SELECT RC-993 OPEN/CLOSE button NTSC/PAL button • Use this to switch the set’s video output format (NTSC/PAL). SUPER AUDIO CD SETUP button PROGRAM/DIRECT button CLEAR button •...

  • Page 30: Loading Discs

    Inner disc guide (8 cm disc) Disc tray NOTE: • Do not move the DVD-A1XV while a disc is playing. Doing so may scratch the disc. (1) Opening and Closing the Disc Tray q Turn on the power. w Press the OPEN/CLOSE button.

  • Page 31: Changing The Default Settings

    HDMI / DVI SUPER PURE SELECT FORMAT AUDIO CD DIRECT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER (Green) ON / STANDBY ON / STANDBY (Red) ON / STANDBY ON / STANDBY Main unit SELECT...
  • Page 32 VIDEO SETUP Use this to set the DVD-A1XV’s screen mode. AUDIO SETUP Use this to set the DVD-A1XV’s audio output mode. RATINGS Use this to disable playback of adult DVDs so that children cannot watch them. Note that playback of adult DVDs cannot be disabled if the rating level is not recorded on the DVD.
  • Page 33 Setup items for use Bold characters indicate factory defaults. LANGUAGE SETUP DIALOG ENGLISH FRENCH SPANISH GERMAN ITALIAN OTHERS SUBTITLE ENGLISH FRENCH SPANISH GERMAN ITALIAN OTHERS DISC MENUS ENGLISH FRENCH SPANISH GERMAN ITALIAN OTHERS OSD LANGUAGE ENGLISH FRANÇAIS ESPAÑOL DEUTSCH DIGITAL INTERFACE SETUP HDMI/DVI NORMAL PICTURE ADJUST...
  • Page 34 Bold characters indicate factory defaults. AUDIO SETUP AUDIO CHANNEL MULTI CHANNEL 2 CH (SRS OFF) 2 CH (SRS ON) DIGITAL OUTPUT NORMAL LPCM (44.1 kHz/48 kHz) SOURCE DIRECT BASS ENHANCER COMPRESSION SACD FILTER 50kHz 100kHz RATINGS 0 (LOCK ALL) RATING LEVEL 8 (NO LIMIT) PASSWORD CHANGE...
  • Page 35 When “LANGUAGE SETUP” is selected See pages 31, 32. Use the • and ª cursor buttons to select the desired setting, then press the ENTER button. DIALOG Use this to set the language of the sound output from the speakers. SUBTITLE Use this to set the language of the subtitles displayed on the TV.
  • Page 36 w When “SUBTITLE” is selected: Select this if you do not want to display the subtitles. (For some discs it is not possible to turn off the subtitle display.) ENGLISH (Factory default) Select this when you want to play the DVD with the subtitles in English.
  • Page 37 Language code list Code Language Code 6565 Afar 7079 6566 Abkhazian 7082 6570 Afrikaans 7089 6577 Ameharic 7165 6582 Arabic 7168 6583 Assamese 7176 6588 Aymara 7178 6590 Azerbaijani 7185 6665 Bashkir 7265 6669 7273 Byelorussian 6671 Bulgarian 7282 6672 Bihari 7285 6678...
  • Page 38 When “DIGITAL INTERFACE SETUP” is selected See pages 31, 32. Use the • and ª cursor buttons to select the desired setting, then press the ENTER button. HDMI/DVI PICTURE ADJUST Switches the digital RGB video range (data range) via the HDMI and the DVI-D connectors.
  • Page 39 w When “HDMI AUDIO SETUP” is selected: 2CH (Factory default) The audio signals are output via the HDMI connector with a down- mixed to 2 channel. MULTI (NORMAL) The multi-channel audio signals are output via the HDMI connector with a bitstream. MULTI (LPCM) The multi-channel audio signals are output via the HDMI connector with a linear PCM.
  • Page 40 B When “CHANNEL LEVEL” is selected, use the • and ª cursor buttons to select the speaker to be adjusted, then use the cursor buttons to set the level. • TEST TONE Use the cursor buttons to select auto or manual. Adjust so that the volume of the test tones output from the different speakers sounds the same.
  • Page 41 • When “DEFAULT” is selected: When “DEFAULT” is selected and the ENTER button is pressed, all the items are restored to their factory default settings. When digital connections are made with an AV amplifier, make the speaker settings on the AV amplifier. For DVD audio discs, the disc’s settings are given priority, so the sound may not be produced as set with the above speaker mode setting.
  • Page 42 t When “IEEE1394” is selected: OFF (Factory default) Digital audio signals are not output from the IEEE1394 terminal. Digital audio signals are output from the IEEE1394 terminal. No audio signals are output from the analog connectors when IEEE1394 is set. B When “ON”...
  • Page 43 Select the video output connected to the TV or monitor whose image you want to view. On the DVD-A1XV, interlace output, progressive output and HDMI/DVI output signals are each processed on independent video circuits. The audio output is optimized for the selected video output, so choose the video output you wish to view.
  • Page 44 The signals output from the DVD-A1XV’s “COMPONENT VIDEO OUT” connector are formatted in the interlaced format. Select this when using the DVD-A1XV connected to an interlace type NOTE: • For the component output only, it is possible to switch between interlace image output and progressive image output.
  • Page 45 t When “SQUEEZE MODE” is selected: OFF (Factory default) Select this to display as full size of a 16:9 TV, regardless of the image’s size. Select this to display the image with a ratio of 4:3 at the center of a 16:9 TV display, regardless of the image’s size.
  • Page 46 When “AUDIO SETUP” is selected See pages 31, 32. Use the • and ª cursor buttons to select the desired setting, then press the ENTER button. AUDIO CHANNEL Use this to adjust for the connected speaker systems. DIGITAL OUTPUT Use this to select the digital output’s signal format. LPCM (44.1 kHz/48 kHz) Use this to set the digital audio output when playing DVDs recorded in linear PCM audio.
  • Page 47 Use the • and ª cursor buttons to select the desired setting, then press the ENTER button. q When “AUDIO CHANNEL” is selected: MULTI CHANNEL (Factory default) Select this for systems in which three or more speakers are connected. When MULTI CHANNEL is set, the speaker settings (SPEAKER CONFIGURATION), speaker output level adjustment (CHANNEL LEVEL) and speaker distances (DELAY TIME) can be set.
  • Page 48 B When “SPEAKER CONFIGURATION” is selected, use the • and ª cursor buttons to select the speaker to be set then press the ENTER button. • The type of speaker used for the front speakers, center speaker, subwoofer and surround speakers can be set. Use the • and ª cursor buttons to select the speaker type, then press the ENTER button.
  • Page 49 B When “DELAY TIME” is selected: With 5.1-channel surround sound, ideally the distance between the listening position and all the speakers aside from the subwoofer should be the same. The delay time setting can be used to make the sound from the different speakers reach the listening position at the same time.
  • Page 50 w When “DIGITAL OUTPUT” is selected: NORMAL (Factory default) When playing DVDs recorded in Dolby Digital or DTS, bitstream signals are output from the digital audio output terminals. When playing DVDs recorded in linear PCM or packed PCM, linear PCM signals are output.
  • Page 51 t When “BASS ENHANCER” is selected: (For 2 channel source.) OFF (Factory default) No sound is produced from the subwoofer. Sound is produced from the subwoofer. In the case, set the subwoofer to “YES” at the speaker settings. This works only with analog audio output. This does not work, at “SOURCE DIRECT”...
  • Page 52 When “RATINGS” is selected See pages 31, 32. Use the • and ª cursor buttons to select the desired setting, then press the ENTER button. RATING LEVEL Use this to restrict playback of adult DVDs you do not want children to view. Note that even with adult DVDs, viewing cannot be restricted unless the restriction level is recorded on the disc.
  • Page 53 w When “PASSWORD” is selected: Use the cursor button to select the “CHANGE”, then press the ENTER button. Use the number buttons to input a old (current) 4- digit password. The default password is “0000”. Use the number buttons to input a new 4-digit password.
  • Page 54 2 seconds immediately following the operation, even while the display has been off. AUTO POWER MODE To save power, DVD-A1XV’s can automatically be set to the standby mode when it is not used for long periods of time. SLIDE SHOW The time interval for switching to the next still picture when playing slide shows of still pictures (in JPEG format) can be set.
  • Page 55 w When “CAPTIONS” is selected: OFF (Factory default) Select this when you do not want to display the captions on the screen when playing DVDs containing English captions Select this to display the captions on the screen when playing DVDs containing English captions.
  • Page 56 OFF (Factory default) The power does not automatically switch to the standby mode. The DVD-A1XV’s power turns off and the standby mode is set if the DVD-A1XV remains in the stop mode for approximately 30 minutes. u When “SLIDE SHOW” is selected: Use the •...

  • Page 57: Using The Pure Direct Mode

    PURE SELECT FORMAT AUDIO CD DIRECT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER PURE DIRECT MEMORY SE TUP PURE D I R ECT MODE PURE DIRECT MEMORY SELECT PURE D I R ECT MODE 1...

  • Page 58: Using The Super Audio Cd Setup

    VIDEO MODE HDMI / DVI SUPER PURE AUDIO CD DIRECT SELECT FORMAT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER SUPER AUDIO CD SETUP Main unit SUPER AUDIO CD SETUP Remote control unit PURE DIRECT MEMORY...

  • Page 59: Adjusting The Picture Quality

    11 ADJUSTING THE PICTURE QUALITY Press the PICTURE ADJUST button. • The image quality adjustment screen will appear. Returns the settings to the factory default settings. M1 TO M5 Image quality settings that have been adjusted to your preference can be stored to 5 memories, M1 to M5. SET permits set to setup level and setting of the screen display position (horizontal and vertical).
  • Page 60 When Image Quality Adjustment 1 is selected and adjusted: • Press cursor button (ª), then select the image quality adjustment item with cursor buttons ( adjustment value with cursor buttons (•, ª), and press the ENTER button. • All of the adjusted contents will be stored. CONTRAST (–6 to +6) (Factory default: 0) •...
  • Page 61 When Gamma Correction is selected and adjusted: Two kinds of displays are prepared for adjustment of Gamma Correction. • When use the Numerical table of Gamma Correction. (Figure 1) :Pressing the cursor button (ª) • When use the Graph of Gamma Correction. (Figure 2) :Pressing the enter button Select the adjust point with cursor buttons ( the ENTER button.
  • Page 62 When the Display Position is Selected and Adjusted: • Press the cursor button (ª), then select the horizontal/vertical direction with the cursor buttons ( ), set the adjustment value with the (•, ª) cursor buttons, and press the ENTER button. SETUP LEVEL (0 IRE, 0 IRE) (Factory default: 0 IRE) •...

  • Page 63: Using The Video Setup

    STILL / PAUSE VIDEO MODE HDMI / DVI SUPER PURE SELECT FORMAT AUDIO CD DIRECT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER 3, 4 SELECT HDMI / DVI SELECT SELECT FORMAT NTSC/PAL ANGLE SUBTITLE AUDIO...
  • Page 64 Select the video output connected to the TV or monitor whose image you want to view. On the DVD-A1XV, interlace output, progressive output and HDMI/DVI output signals are each processed on independent video circuits. The audio output is optimized for the selected video output, so choose the video output you wish to view.
  • Page 65 When “TV SYSTEM” is selected: • The modes described below will appear on the display. Select the item you wish to set and press the VIDEO MODE knob to define PROGRESSIVE (Factory default) The audio signals are synchronized with the progressive output. (For component video output signals when “COMPONENT VIDEO OUT”...

  • Page 66: Playback

    HDMI / DVI SUPER PURE AUDIO CD DIRECT SELECT FORMAT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER ON / STANDBY ON / STANDBY (Green) ON / STANDBY ON / STANDBY (Red) Main unit OPEN/CLOSE...
  • Page 67 • Press the RETURN button during playback of a video CD to return to the menu screen. • If appears on the TV screen while buttons are being operated, that operation is not possible on the DVD-A1XV or with that disc. • Set the disc in the disc guide. PLAY...
  • Page 68 (Auto Power Off) (See pages 54, 56.) <Resume play memory function (DVD only)> • With the DVD-A1XV, when the STOP button is pressed, that position is stored in the memory. At this time, “ PLAY button is pressed after pressing the STOP button, playback resumes from the position at which it was stopped.
  • Page 69 (5) Skipping to the Beginning of Chapters or Tracks Cueing using the SKIP buttons During playback, press one of the SKIP buttons on the main unit or the remote control unit. : Reverse direction (PREVIOUS) : Forward direction (NEXT) • A number of chapters or tracks equal to the number of times the button is pressed is skipped.
  • Page 70 (8) Selecting the still image (only for DVD-audios) During playback, press the PAGE + or PAGE – button on the remote control unit. • For DVD audio discs with still images, the desired image can be selected. • On some discs the image cannot be selected due to the intentions of the discs’...

  • Page 71: Playing Repeatedly

    14 PLAYING REPEATEDLY 2 Use this function to play your favourite audio or video sections repeatedly. Playing Repeatedly (Repeat Playback) In the play mode, press the REPEAT button. • The display on the TV screen switches each time the button is pressed, and the corresponding repeat play mode or normal playback mode is set.
  • Page 72 Playing a Certain Section Repeatedly (A-B Repeat Playback) During playback, press the A-B button. • This sets start point A. Press the A-B button again. • This sets end point B, and repeat playback of the A-B section starts. To return to normal playback: Press the A-B button until “A TO B CANCELED”...

  • Page 73: Playing Tracks In The Desired Order

    VIDEO MODE HDMI / DVI SUPER PURE AUDIO CD DIRECT SELECT FORMAT SET UP SELECT PUSH ENTER DVD-A1XV DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER PROGRAM /DIRECT Remote control unit Remote control unit PLAY PLAY Main unit SELECT FORMAT NTSC/PAL...

  • Page 74: Playing Tracks In The Random Order

    SUPER PURE SELECT FORMAT AUDIO CD DIRECT SET UP SELECT PUSH ENTER DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER DVD-A1XV RANDOM Remote control unit PLAY PLAY Main unit Remote control unit SEARCH MODE Remote control unit for DVD audio discs...

  • Page 75: Using The On-Screen Display

    17 USING THE ON-SCREEN DISPLAY 2 Use this function to display and change information on the disc (titles, chapters, time, etc.) In the play mode, press the DISPLAY button. • The On-Screen Display appears. • The picture on the TV screen switches each time the button is pressed. •...

  • Page 76: Using The Multiple Audio, Subtitle And Angle Functions

    18 USING THE MULTIPLE AUDIO, SUBTITLE AND ANGLE FUNCTIONS Switching the Audio Language (Multiple Audio Function) 2 With DVDs containing multiple audio language signals, the audio language can be switched during playback. During playback, press the AUDIO button. • The current audio language number is displayed. Use the •...
  • Page 77 Switching the Subtitle Language (Multiple Subtitle Function) 2 With DVDs containing multiple subtitle language signals, the subtitle language can be switched during playback. During playback, press the SUBTITLE button. • The current subtitle language number is displayed. Use the • and ª cursor buttons to select the desired language. •...
  • Page 78 Switching the Angle (Multiple Angle Function) 2 With DVDs containing multiple angle signals, the angle can be switched during playback. During playback, press the ANGLE button. • The current angle number is displayed. Use the • and ª cursor buttons to select the desired angle. •...

  • Page 79: Using The Menus

    19 USING THE MENUS Using the Top Menu 2 For DVDs containing multiple titles, the desired title can be selected and played from the top menu. During playback, press the TOP MENU button. • The top menu appears. Use the cursor or number buttons to select the desired title. •...
  • Page 80 Using the DVD Menu 2 Some DVDs include special menus called DVD menus. For example, DVDs with complex contents may contain guide menus, and DVDs with multiple languages may contain audio and subtitle language menus. These menus are called “DVD menus”. Here we describe the general procedure for using DVD menus.

  • Page 81: Marking Scenes You Want To See Again

    20 MARKING SCENES YOU WANT TO SEE AGAIN 2 Set marks at scenes you want to see again so that you can start playback from the marked position whenever you want. Setting Marks (for DVD-audios and DVD-videos only) During playback, press the MARKER button. •...

  • Page 82: Playing In The Zoom Mode

    21 PLAYING IN THE ZOOM MODE In the play or pause mode, press the ZOOM button. • The zoom rate increases each time the ZOOM button is pressed. For DVD video discs and video CDs: OFF Æ x1.5 Æ x2 Æ x4 Æ OFF For DVD audio discs: OFF Æ...
  • Page 83 2 There are many music distribution sites on the internet from which music files in MP3 format can be downloaded. Music downloaded as instructed on the site and written onto a CD-R/RW disc can be played on the DVD-A1XV. If music recorded on commercially available music CDs is converted on a computer into MP3 files using an MP3 encoder (conversion software), the data on a 12 cm CD is reduced into about 1/10 the amount of the original data.
  • Page 84 • The number of files playable with the DVD-A1XV is approximately 600 or less. • With the DVD-A1XV it is possible to display folder names and file names on the screen like titles. The DVD-A1XV can display up to 8 characters, consisting of numbers, capital letters, and the “_” (underscore) mark.

  • Page 85: Playing Wma

    23 PLAYING WMA 2 Listening to WMA (Windows Media Audio) CD-R/CD-RW • This unit can play CD-R/RW music files that have been recorded in the WMA (Windows Media Audio)* audio compression format. Windows Media and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 86: Playing Still Picture Files (Jpeg Format)

    24 PLAYING STILL PICTURE FILES (JPEG FORMAT) 2 JPEG files stored on Kodak picture CDs, Fujicolor CDs, CD-Rs and CD-RWs can be played as a slide show and enjoyed on the DVD-A1XV. Playing still picture 2 Kodak picture CDs and Fujifilm Fujicolor CDs can be played on the DVD-A1XV.
  • Page 87 Use the • and ª cursor buttons to select the folder containing the file(s) you want to play, then press the ENTER button. To change the folder Use the cursor button to select “ROOT”, then press the ENTER button. The screen in step 1 reappears.
  • Page 88 • TRACK REPEAT (the select WMA or MP3 or JPEG file is played repeatedly) NOTES: • The DVD-A1XV is compatible with image data stored in JPEG format, but Denon does not guarantee that all image data stored in JPEG format can be viewed.

  • Page 89: Troubleshooting

    2 Are the amplifier and speakers operating properly ? If the DVD-A1XV does not seem to be functioning properly, check the table below. If this does not solve the problem, the DVD-A1XV may be damaged. Turn off the power, unplug the power cord from the power outlet, and contact your store of purchase or nearest Denon sales office.
  • Page 90 • Check the settings of “HDMI/DVI SELECT”. HDMI/DVI connection. • Check whether the output format of the DVD-A1XV (HDMI/DVI FORMAT) matches the input • Check whether the video output setting at “PURE DIRECT” is set to “VIDEO OUT : OFF”...

  • Page 91: Main Specifications

    26 MAIN SPECIFICATIONS Signal system: NTSC/PAL Applicable discs: (1) DVD-Audio/DVD-Video discs 1-layer 12 cm single-sided discs, 2-layer 12 cm single-sided discs, 2-layer 12 cm double-sided discs (1 layer per side) 1-layer 8 cm single-sided discs, 2-layer 8 cm single-sided discs, 2-layer 8 cm double-sided discs (1 layer per side) (2) Super audio CDs Single layer 12 cm discs, Dual layer 12 cm discs, Hybrid layer 12 cm discs...
  • Page 92 TOKYO, JAPAN www.denon.com 00D 511 4289 013...
