Installing the Wi-Fi antenna connector
To install the Wi-Fi antenna connector:
1.
Remove the bolt from the Wi-Fi antenna
connector but leave the washer on the
connector.
2.
Insert the connector into the I/O shield's Wi-Fi port hole.
3.
Replace the bolt on the connector to secure the antenna connector and the I/O shield
in place.
ASUS MAXIMUS VI IMPACT
washer
bolt
bolt
washer
2-17
