MAXIMUS VI IMPACT specifications summary
Internal Connectors
BIOS Features
Manageability
Software
Form Factor
Specifications are subject to change without notice.
1 x USB 3.0 connector (supports additional 2 USB 3.0 ports)
1 x USB 2.0 connector (supports additional 2 USB 2.0 port sharing
with ROG_EXT header)
1 x ROG Extension (ROG_EXT) header
4 x SATA 6Gb/s connectors
1 x 4-pin CPU fan connector
3 x 4-pin Chassis fan connectors
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V Power connector
10 x ProbeIt measurement points
1 x LN2 Mode jumper
1 x FastBoot jumper
1 x Power-on button
1 x Reset button
1 x DRCT (DirectKey) header
1 x S/PDIF out header
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x TPM connector
1 x SupremeFX Impact connector
1 x mPCIe Combo II connector
64 Mb UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 2.5, ACPI
2.0a, Multi-language BIOS
WfM2.0, DMI2.0, WOL by PME, PXE
Drivers
ROG GameFirst II
ROG RAMDisk
ROG CPU-Z
ROG Mem TweakIt
Kaspersky Anti-Virus
®
DAEMON Tools Pro Standard
ASUS WebStorage
ASUS Utilities
Mini-ITX Form Factor, 6.7" x 6.7" (17cm x 17cm)
xiii
