Ryobi RY28120 Quick Start Manual

First Time Assembly
WARNING: This Quick Start Guide is not a substitute for reading the
operator's manual. To reduce the risk of injury, user must read and understand
operator's manual before using this product.
1
Remove product from carton.
Assemble per instructions
in your operator's manual.
2
Align and assemble 2 booms
until fully seated.
3
Spread handle over boom and
snap into place. Secure with bolt,
washer, and wing nut.
Curved Shaft
4
- OR -
Snap shield into place over boom and bracket.
Secure with bolt, washer, and wing nut as shown.
5
6
7
8
Straight Shaft
9
Mix 2.6 oz. 2-cycle oil with
1 gallon of fresh gasoline in
separate gas container. Shake,
then pour into trimmer tank.
First Time Start
Place trimmer on ground
with the trim head end facing
away from you.
10X
Repeatedly press the primer
bulb 10 times.
Set choke lever to A
start position.
Squeeze and hold triggers.
Pull quickly and powerfully
10
Continue to squeeze and hold
trigger for 10 seconds after
engine starts. If engine
11
Set choke lever to
12
You are now ready to Trim!
If engine did not start,
TRIM!
To stop trimmer, press
the red switch located
Go to www.ryobitools.com and register your new tool online.
For any questions about operating or maintaining your product,
call the Ryobi Help Line!
®
1-800-860-4050
Your Product has been fully tested prior to shipment to
ensure your complete satisfaction. Troubleshooting tips are
also available in your operator's manual.
For additional registration instruction, refer to operator's manual.
to start (6x MAX.)
does not start,
RePeAT STePS
7 10
B run position.
RePeAT STePS
7 11
–
on the top of the
trigger housing.
990000226
9-13-12 (REV:01)
