REAR SWIVEL OUTLET
ADJUSTMENT
Fig. 98: front seats (on dashboard ends)
Fig. 99: rear seat (on the console be-
tween seats)
110
fig. 98
Air flow can be adjusted by means of vanes
(A) with press-on opening and closing.
Air flow can be directed by rotating the out-
let by means of the vanes.
A0B0038m
fig. 99

MANUAL CLIMATE

CONTROL SYSTEM

(fig. 99a - where applicable)
CONTROLS
1 Air temperature adjustment knob (mix-
ing warm / cold air)
2 Climate control compressor on / off but-
ton
3 Inside air re-circulation on / off button
4 Fan knob
5 Maximum defrosting / demisting on /
off button for windscreen and front side win-
dows and wing mirror coils
6 Rearscreen heating and wing mirror de-
frosting on / off button.
7 Air distribution knob.
A0B0289m
