Summary of Contents for Alfa Romeo Alfa 156 Sportwagon Q4
-
Page 2: Table Of Contents
This supplement describes all the main char- CONTENTS acteristics of Alfa 156 Sportwagon Q4 and Alfa Crosswagon Q4 versions. For any topic not specifically dealt with in ALFA 156 Sportwagon Q4 ALFA Crosswagon Q4 this supplement, refer to the main Owner’s INSTRUMENT CLUSTER .... -
Page 4: Instrument Cluster
INSTRUMENT CLUSTER A0B0634m fig. 1 A. Speedometer - B. Odometer with double counter (total and partial) display - C. Check panel - D. Rev counter - E. Fuel level gauge with reserve warning light - F. Clock - G. Engine coolant fluid temperature gauge with maximum temperature warning light - H. Warning lights. -
Page 5: Quick Tyre Repair Kit
QUICK TYRE REPAIR – small cylinder C containing sealer and IF THE CAR IS TO fitted with a filling pipe and a sticker bear- KIT - FIX&GO BE TOWED ing the notice “MAX 80 km/h”, to be placed in a position visible to the driver (on the dashboard) after fixing the tyre;... -
Page 6: Interior Fittings
INTERIOR FITTINGS CLEANING LEATHER SEATS – Remove dried on dirt with a lightly moistened chamois leather or cloth without pressing too hard. – Remove liquid or grease stains with a dry absorbent cloth without rubbing. Then wipe with a soft cloth or chamois leather with water and neutral soap. -
Page 7: Engine Code - Body Version
ENGINE CODE - BODY VERSION Version Body version Engine code Alfa 156 Sportwagon Q4 932BXN20 70 937A5000 ENGINE Alfa 156 Sportwagon Q4 Code type 937A5000 Cycle Diesel Injection Common Rail multipoint injection system Number and position of cylinders 4 in line Piston bore and stroke 82 x 90.4... -
Page 8: Transmission
TRANSMISSION Altitude reduces car per- WARNING formance since air is thin. Do not drive uphill cater- corner, but follow the GENERAL INSTRUCTIONS AND max. gradient line. WARNINGS WARNING Only drive the car on grounds suitable for its characteristics and for your dri- WARNING ving skill. - Page 9 GEARBOX CLUTCH In the event of signifi- cant grip difference Six forward gears plus reverse all syn- Dry single disk with hydraulic control. between front and rear chronised. axle, do not accelerate sharply: in FOUR-WHEEL DRIVE To engage reverse gear (R), raise the this case it is best to run the ring under the grip (with the fingers of the engine at medium or low rpm and...
-
Page 10: Wheels And Tyres
WHEELS AND TYRES Type Tyre 205/50 R17 93V ( 7Jx17” ) Tyres that can be fitted with snow chains: use snow chains with reduced size and max. protrusion beyond the tyre profile of 9 mm (see paragraph “Snow chains” on page 11). To prevent damages to 4-wheel drive system, tyres shall be of the same type, tread and make. - Page 11 WHEEL GEOMETRY Alfa 156 Sportwagon Q4 Front wheels toe-in: – 1 mm ± 1 mm Rear wheels toe-in: 3.2 mm ± 1 mm...
-
Page 12: Snow Chains
Use of snow chains could be compulsory also for 4-wheel drive cars. Before purchasing or using snow chains, you are recommended to contact Alfa Romeo Authorised Services. Check the tension of the chain after the first few metres have been driven. -
Page 13: Dimensions
DIMENSIONS A0B0636m fig. 5 Dimensions are expressed in mm Height indicated is for an unladen car 2595 4441 1458 1529 1743 1504... -
Page 14: Weights
WEIGHTS Alfa 156 Sportwagon Q4 1510 kg Kerb weight 2005 kg Max. permitted weight (*) 495 kg Payload including the driver (**) 1450 kg Towable weight 60 kg Max. load on ball Weights not to be exceeded. The driver must arrange the goods in the luggage compartment/on load surface/roof (do not exceed 50 kg on roof) so that they comply with these limits. -
Page 15: Refilling
REFILLING Alfa 156 Sportwagon Q4 Specified fuels Recommended products Diesel fuel for motor vehicles (Specification Fuel tank: litres EN590) – including a reserve of litres Mixture of distilled water and PARAFLU11 Engine cooling system litres (blue colour) at 50% or PARAFLU UP... -
Page 16: Fuel Consumption
FUEL CONSUMPTION The fuel consumption figures given in the – extraurban cycle: frequent accel- WARNING The type of route, table below are determined on the basis erating in all gears, simulating extraurban traffic situations, weather condi- of the homologation tests set down by use of the car;... -
Page 18: Instrument Cluster
INSTRUMENT CLUSTER A0B0634m fig. 1 A. Speedometer - B. Odometer with double counter (total and partial) display - C. Check panel - D. Rev counter - E. Fuel level gauge with reserve warning light - F. Clock - G. Engine coolant fluid temperature gauge with maximum temperature warning light - H. Warning lights. -
Page 19: Rearview Mirrors
REARVIEW MIRRORS The mirror has a built-in compass that Turning the automatic shows the broad driving direction on the antiglare function on display provided for the purpose. The green led (A-fig. 2) when on indi- Direction shown can be one of the fol- cates that the automatic antiglare function DRIVING MIRROR lowing:... - Page 20 Letter “C” Proceed as follows: – set the involved zone by pressing shown on the display repeatedly switch (A-fig. 3) until dis- – with display on, keep switch (A- playing the number corresponding to the If letter “C” is displayed the compass fig.
-
Page 21: Quick Tyre Repair Kit
QUICK TYRE REPAIR The quick repair kit includes (fig. 6): COMPACT SPARE WHEEL (for versions/markets where KIT - FIX&GO – tool A to remove the valve body; applicable) – compressor B with pressure gauge The car can be fitted (for versions/mar- and fittings;... - Page 22 – raise the boot mat and secure it as – take the tool container (B-fig. 8) – press the brake pedal, disengage the shown in (fig. 7); out of the boot and take it near the wheel gear, start the engine plug in the cigar to be changed;...
- Page 23 – loosen the fastening bolts by about – work the jack crank (A-fig. 13), to – completely unscrew the fastening bolts one turn (B-fig. 11); extend it until the groove (B-fig. 14) on (B-fig. 11), and remove the wheel; the upper part of jack is correctly inserted –take the jack out of the relevant con- –...
- Page 24 – fasten the five bolts; – remove the pin (A-fig. 17) and – put the jack back into its container tighten the last fastening bolt; forcing it lightly to prevent it from vibrat- – lower the car and remove the jack; ing when travelling;...
-
Page 25: If The Car Is To Be Towed
IF THE CAR IS TO BE INTERIOR FITTINGS WARNING Never use alcohol. Make sure that cleaning products do not contain TOWED alcohol and alcohol derivatives even at low strength. CLEANING LEATHER SEATS PRECAUTIONS FOR TOWING – Remove dried on dirt with a lightly THE CAR moistened chamois leather or cloth with- out pressing too hard. -
Page 26: Checking Levels
CHECKING LEVELS A0B0686m 1 Engine oil - 2 Battery - 3 Brake fluid - 4 Windscreen washer fluid - 5 Engine coolant fluid - 6 Power steering fluid WARNING To access the battery or to check engine coolant level (5), slacken fastenings (A-fig. -
Page 27: Engine Code - Body Version
ENGINE CODE - BODY VERSION Body version Version Engine code Alfa Crosswagon Q4 932BXN20 70B 937A5000 ENGINE Alfa Crosswagon Q4 Code type 937A5000 Cycle Diesel Injection Common Rail multipoint injection system Number and position of cylinders 4 in line Piston bore and stroke 82 x 90.4 Total displacement 1910... -
Page 28: Transmission
TRANSMISSION BAND BELOW DOORRWAY WARNING Do not drive uphill cater- corner, but follow the GENERAL INSTRUCTIONS The band below the door- max. gradient line. AND WARNINGS way of your car is fitted with protection, shown in the figure 19, to improve WARNING protection against damages when driving on bad roadbeds or in bad... -
Page 29: Suspensions
GEARBOX FOUR-WHEEL DRIVE In the event of signifi- cant grip difference Six forward gears plus reverse all syn- Alfa Crosswagon Q4 is a car capa- between front and rear chronised. ble of coping well with snowy, icy, muddy axle, do not accelerate sharply: in and dirt roads. -
Page 30: Wheels And Tyres
(*) These tyres cannot be fitted with traditional snow chains. Only spider type snow chains can be used. SPIKES SPIDER COMPACT snow chains - 17003 compact model - with 9 arms and 16 mm adjustable length and 17” wheel cover adapter are available at Lineaccessori Alfa Romeo. Keep your speed down when this type of chains is fitted. - Page 31 COLD TYRE INFLATION PRESSURES Tyre Compact spare wheel 225/55 R17 97H Pirelli 225 (optional for versions/markets where applicable) Front Rear 185/60 R17 93P Reduced load (2 occupants) Full load With the tyre hot the inflating pressure should be +0.3 bar compared with the specified rating. Recheck pressure value with cold tyres. With winter tyres the inflating pressure should be +0.2 bar compared with the specified rating.
-
Page 32: Snow Chains
ASR system off (button led shall be on). Remember that snow chains make braking distance longer. WARNING As concerns Alfa 156 Sportwagon Q4 version, see page 11. PERFORMANCE Alfa Crosswagon Q4 Maximum speed km/h Acceleration from 0-100 km/h sec. -
Page 33: Dimensions
DIMENSIONS A0B0635m fig. 20 Dimensions are expressed in mm Height indicated is for an unladen car 2595 4441 1497 1529 1765 1504... -
Page 34: Weights
WEIGHTS Alfa Crosswagon Q4 Kerb weight 1530 kg 2025 kg Max. permitted weight (*) Payload including the driver (**) 495 kg Towable weight 1450 kg Max. load on ball 60 kg Weights not to be exceeded. The driver must arrange the goods in the luggage compartment/on load surface/roof (do not exceed 50 kg on roof) so that they comply with these limits. -
Page 35: Refilling
REFILLING Alfa Crosswagon Q4 Specified fuels Recommended products Diesel fuel for motor vehicles (Specification Fuel tank: litres EN590) – including a reserve of litres Mixture of distilled water and PARAFLU11 Engine cooling system litres (blue colour) at 50% or PARAFLU UP (red colour) at 50% SELENIA TURBO DIESEL (*) Oil sump and filter... -
Page 36: Fuel Consumption
FUEL CONSUMPTION The fuel consumption figures given in the – extraurban cycle: frequent accel- WARNING The type of route, table below are determined on the basis erating in all gears, simulating extraurban traffic situations, weather condi- of the homologation tests set down by use of the car;... - Page 37 B.U. AFTER SALES ASSISTENZA TECNICA - INGEGNERIA ASSISTENZIALE Viale Alfa Romeo 20020 Arese (MI) - Italia Fiat Auto S.p.A. Pubblication n° 60431374 - 3 Edition – 12/2004 Printed by Satiz - Turin (Italy) All rights reserved. Reproduction, even partial, is strictly prohibited without written permission from Fiat Auto S.p.A.
