Electrolux 241567600 Use & Care Manual

Top mount refrigrator
Hide thumbs

Advertisement

Quick Links

Advertisement

loading

  Related Manuals for Electrolux 241567600

  Summary of Contents for Electrolux 241567600

  • Page 1: Table Of Contents

    Temperature Controls Looking Inside Water Dispenser & Ice Service Food Storage & Energy Saving Tips Normal Operating Sounds Care & Cleaning Warranty Before You Call Includes Connecting 4 - 5 9 - 11 12 - 14 17- 18 P/N 241567600 (0304)
  • Page 2: Welcome

    Please read this Use & Care Manual very carefully. It contains valuable information on how to properly maintain your new refrigerator. We know you’ll enjoy your new refrigerator and Thank You for choosing our product. We hope you consider us for future purchases.
  • Page 3: Safety Instructions

    Children should NEVER use these items to play. Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may become airtight chambers, and can quickly cause suffocation. These Guidelines Must Be Followed To Ensure That Safety Mechanisms In This Refrigerator Will Operate Properly. ELECTRICAL INFORMATION •...
  • Page 4 If possible, place the refrigerator out of direct sunlight and away from the range, dishwasher or other heat sources. • The refrigerator must be installed on a floor that is level and strong enough to support a fully loaded refrigerator. • Consider water supply availability for models equipped with an automatic ice maker.
  • Page 5: Installation -- Includes Connecting Optional Ice Maker To Water Supply

    A water supply line made of ¼ inch (6.4 mm) OD, copper tubing. To determine the length of copper tubing needed, you will need to measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water pipe.
  • Page 6: Removal & Reversal

    Door Removal and Reversal Instructions DOOR REMOVAL INSTRUCTIONS: If your refrigerator will not fit through an entrance area, you can reduce its size Top Hinge by removing the doors. Check first by measuring the entrance. Cover IMPORTANT: Before you begin, turn the refrigerator temperature control to “0”...
  • Page 7: Features At A Glance

    Features At A Glance Features may vary according to model...
  • Page 8: Temperature Controls

    COOL DOWN PERIOD To ensure safe food storage, allow the refrigerator to operate with the doors closed for at least 8 to 12 hours before loading it with food. REFRIGERATOR & FREEZER CONTROLS NOTE: When changing control settings, wait 24 hours before making additional adjustments.
  • Page 9: Looking Inside

    Replace the shelf on any pair of rails by reversing this procedure. To adjust cantilever shelves: NOTE: Cantilever shelves are supported at the back of the refrigerator. Cantilever shelves are available in either glass or wire. Lift front edge up.
  • Page 10 12 ounce drink cans, a bottle of wine, a two-liter soft drink bottle, or a carton of eggs. The Special Item Rack mounts on the left side of your refrigerator. To install, just slide the Special Item Rack onto any shelf as shown in the drawing.
  • Page 11: Looking Inside

    CRISPERS (SOME MODELS) The crispers, located under the bottom refrigerator shelf, are designed for storing fruits, vegetables, and other fresh produce. Wash items in clear water and remove excess water before placing them in the crispers. Items with strong odors or high moisture content should be wrapped before storing.
  • Page 12: Water Dispenser & Ice Service

    WATER DISPENSER Your refrigerator includes an automatic water dispenser on the front of the refrigerator door. The dispenser is designed to accommodate containers up to 7½ inches high. Dispensing Button Drip Tray Water Dispenser Dispensing Water To operate the water dispenser, press a drinking glass against the dispensing button.
  • Page 13 • Occasionally shake the ice container to keep ice separated. • Keep the wire signal arm in its “up” or OFF position until the refrigerator is connected to the water supply or whenever the water supply is turned off. •...
  • Page 14: Ice Service

    6 - 9 months normally will ensure the highest possible water quality. If the filter has been in a refrigerator that has not been in use for awhile (during moving for example), change the filter before reinstalling the refrigerator. The dispenser system will also operate without filtration (with filter cartridge removed).
  • Page 15: Food Storage & Energy Saving Tips

    The fresh food compartment should be kept between 34° F and 40° F with an optimum temperature of 37° F. • Avoid overcrowding the refrigerator shelves. This reduces the circulation of air around the food and results in uneven cooling.
  • Page 16: Normal Operating Sounds

    E. Cold Control & Defrost Timer or Automatic Defrost Control These parts can produce a snapping or clicking sound when turning the refrigerator on and off. The timer also produces sounds similar to an electric clock. F. Condenser Fan If condenser coils are located underneath your refrigerator as shown in the drawing at the left, you have a condenser fan.
  • Page 17: Care & Cleaning

    Keep your refrigerator and freezer clean to prevent odor build-up. Wipe up any spills immediately and clean both sections at least twice a year. Never use metallic scouring pads, brushes, abrasive cleaners or strong alkaline solutions on any surface. Do not wash any removable parts in a dishwasher. Always unplug the electrical power cord from the wall outlet •...
  • Page 18: Care & Cleaning

    6. Remember to plug the refrigerator back in. CONDENSER Your refrigerator is equipped with a condenser that never needs cleaning under normal operating conditions. • Leave refrigerator operating during vacations of 3 weeks or less. • Short Use all perishable items from refrigerator compartment. •...
  • Page 19: Warranty

    REFRIGERATOR WARRANTY Your refrigerator is protected by this warranty WARRANTY PERIOD One year from original FULL ONE-YEAR purchase date WARRANTY Second through fifth LIMITED 2 years from original YEAR WARRANTY purchase date (Cabinet Liner and Sealed System) LIMITED Time periods listed above.
  • Page 20: Before You Call

    • The temperature control is turned to "O". • Refrigerator may be in defrost cycle. Wait 20 minutes and check again. • Set freezer control to a warmer setting until freezer temperature is satisfactory. Allow 24 hours for the temperature to stabilize.
