- Page 1 User’ s Guide MADE IN Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info FD6001, FD6002, FD6003 Ultrasonic Flowmeter with Totalization...
- Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
-
Page 3: Table Of Contents
PART 1 - TABLE OF CONTENTS Description Pages Quick Start Installation 1.2-1.3 Operating Theory Product Limitations Model Number Matrix Specifications Transducer Installation 2.1-2.5 Pre-Installation Functional Test 3.1-3.2 Transmitter Installation 3.3-3.4 Power Source Jumper Settings Electrical Connections 3.5-3.6 Power Up and Configuration Keypad Operations 3.8-3.19 Trouble Shooting... - Page 4 PART 1 - QUICK START This manual contains detailed operating instructions for all General aspects of the FD6000 instruments. The following condensed instructions are provided to assist the operator in getting the instrument started up and running as quickly as possible.
- Page 5 PART 1 - QUICK START 3. TRANSDUCER/POWER CONNECTIONS A. Do not attempt to add additional cable to the transducers. B. Refer to the DIAGRAMS in Figure 1.2 for proper power and transducer connections. Verify proper jumper selections are in place for the power source. Figure 3.4.
-
Page 6: Operating Theory
PART 1 - GENERAL The FD6000 Series flowmeter is designed to General measure the flow of liquids and slurries in full-pipe closed systems. The transmitter is field configured to measure flow on a variety of pipes and liquids. The standard product is typically used on pipe sizes ranging from 1 - 120 inch [ 25 - 1524 mm ] pipe I.D. - Page 7 PART 1 - GENERAL The flowmeter is typically used as a unidirectional Measuring Limits meter and is most accurate when the transducer is mounted in the orientation detailed in this manual. But, the meter will measure flow in both directions — although flow direction will not be indicated or totalized properly.
- Page 8 Serial Number The serial number and complete model number of your meter is located on the inside of the transmitter front cover. Should technical assistance be required, please provide OMEGA’s Customer Service Department with this information.
- Page 9 PART 1 - GENERAL (Std) 115 or 230 VAC 50/60 Hz ±10% and 12 VDC. (Opt) Power consumption less than 12 VA.
- Page 10 NOTES...
-
Page 11: Transducer Installation
PART 2 - TRANSDUCER INSTALLATION The following list outlines how to install the Transducer Mounting transducer for optimal performance, highest reliability Locations and greatest accuracy: 1. Select a transducer site at least 10 pipe diameters downstream from bends, or fittings and 5 pipe diameters upstream. - Page 12 PART 2 - TRANSDUCER INSTALLATION operating range of the meter. Down stream from pump or orifices, etc., locate at least 20 diameters. See Table 2.1 Transducer Cable 2. On horizontal pipe, select a position that is between 2 and 4 o’clock on the pipe, with 12 o’clock representing the top.
- Page 13 PART 2 - TRANSDUCER INSTALLATION permanently mounted. Under flowing liquid conditions, adequate signal is indicated when the Signal Strength indicates between 000125 and 000200 counts. Acoustic Couplant For proper operation, there cannot be air voids between the traducer face and pipe. The space must Types be filled with a material which is a good transmitter of sound energy such as:...
- Page 14 PART 2 - TRANSDUCER INSTALLATION Installations requiring intrinsic safety should refer to Intrinsic Safety the Appendix drawings covering these applications. Installations 1. Pipe Preparation: For permanent silicone adhesive mounting, after determining the transducer location, some attention must be given to the pipe condition. Before the transducer head is bonded to the pipe surface, an area slightly larger than the flat surface to the...
- Page 15 PART 2 - TRANSDUCER INSTALLATION adhesive (Dow-732). Spread a bead of the adhesive on the flat surface of the transducer face, covering well. Now spread a bead to the prepared pipe surface and press the head lightly to the pipe. Let the adhesive flow enough to fill in all the area beneath the head.
- Page 16 NOTES...
- Page 17 PART 3 - PRE-INSTALLATION CHECKOUT After unpacking, it is recommended to save the shipping Unpacking carton and packing materials in case the instrument is stored or re-shipped. Inspect the equipment and carton for damage. If there is evidence of shipping damage, notify the carrier immediately.
- Page 18 PART 3 - PRE-INSTALLATION CHECKOUT forth with your thumb using moderate pressure. The cycle time should be 1-2 times per second. 8. Verify that signal strength increases with frequency of the rubbing. Typical increases will range from 20-30 counts. 9. Verify that signal strength decreases when rubbing ceases.
- Page 19 PART 3 - TRANSMITTER INSTALLATION PART 2 - ELECTRICAL CONNECTIONS 1. Place the transmitter in a location that is: Transmitter Installation ♦ Where little vibration exist. ♦ Protected from falling corrosive fluids. ♦ Within ambient temperature limits - 22 to 122°F [-30 to 50°C] ♦...
- Page 20 PART 3 - TRANSMITTER INSTALLATION PART 2 - SERVICE AND MAINTENANCE 1.45 [36.8] 3.88 [98.5] FIGURE 3.3 FD-5000 Shown NOTE: The transducer cable carries low level signals. Important ! Do not attempt to add additional cable to the factory supplied transducer cable.
- Page 21 PART 3 - TRANSMITTER INSTALLATION PART 2 - SERVICE AND MAINTENANCE The 4-20mA output is proportional to the flow rate 4-20mA OUTPUT measuring scale and can drive a load of up to 1000 ohms. The output is isolated from earth ground and circuit low. Connect the load to the 4-20 mA connection terminals located on the inside of the enclosure, matching polarity as indicated.
-
Page 22: Transmitter Installation
The transducer cable carries low level signals. Do not attempt to add additional cable to the factory supplied transducer cable. If additional cable is required contact OMEGA Engineering to order a transducer with the appropriate length of cable Cables to 300 feet [90 meters] are available. - Page 23 Verify that DT6 transducer connections are proper and secure. If the SIGNAL STR. remains greater than 000100, consult OMEGA Engineering assistance. It is possible that the GAIN control [R13] is set too far clockwise and ambient noise is influencing the readings.
- Page 24 PART 3 - KEYPAD CONFIGURATION After a successful flow meter installation and startup (covered in the previous sections of this manual) the FD6000 can be keypad configured to provide select engineering unit readings of flow and a scaled 4-20mA output. Configuration inputs are made via the keypad and are stored by the microprocessor.
- Page 25 PART 3 - KEYPAD CONFIGURATION F1 and F2 Not utilized. RESET Caution: Conducts a system reset. All configuration constants will be lost and the FD6000 will load default values for all constants. I.D. Allows entry of a pipes internal diameter. Internal diameters must be entered if volumetric flow rates are to be displayed.
- Page 26 PART 3 - KEYPAD CONFIGURATION second). Valid ranges for this entry are 0.00 to 30.00 FPS. Two useful equations that relate liquid velocity to volume: GPM = 2.45 X I.D. X FPS FPS = ( GPM X 0.408) / I.D. I.D.
- Page 27 PART 3 - KEYPAD CONFIGURATION Table 3.1 UNITS Code Flow Rate Totalizer FPS (feet per sec) GPM (gallons per min) GALLONS GPH (gallons per hr) GALLONS MGD (millions of gal GALLONS pre day) CFM (ft. per min) MPS (meters per sec) N/A CMH (m per hr) LPM (liters per min)
- Page 28 PART 3 - KEYPAD CONFIGURATION HIGH ALARM (Labeled RELAY-1 on the Main PCB) Controls the set-point of the SPDT relay labeled RELAY-1 on the Main PCB. Enter a liquid velocity at which a relay- contact action is desired. Relay contacts are utilized for signaling flow rate conditions that are higher of lower than a desired set point.
- Page 29 PART 3 - KEYPAD CONFIGURATION The External Counter output, available at the two terminals labeled CTR on the Main PCB, is influenced by the TOTAL MULT value. Since the output is designed to operate electromechanical accumulators, large flow rates will require that the TOTAL MULT be set to a value usable by these types of counters (typically speeds no faster than 3 cps).
-
Page 30: Electrical Connections
PART 3 - KEYPAD CONFIGURATION (continued) Third press Restarts the internal totalizer/external CTR (The internal totalizer starts from zero.) If inhibiting (pausing) the totalizer is necessary, there are two methods suggested: 1. Connect and external totalizer to the CTR terminals. See the section of this manual related to CTR electrical connections for connection parameters. - Page 31 PART 3 - KEYPAD CONFIGURATION of correction factors located in the Appendix of this manual for Liquid Sound Speed and their associated correction factors. n Transducer mounted in non-recommended locations. By applying a CAL value other than 100%, the factory- calibrated readings will be altered by the percentage entered.
- Page 32 PART 3 - KEYPAD CONFIGURATION FUNCT - SERVICE MODE FUNCT} SIGNAL STR Displays the raw Doppler signal strength value. This value will increase as the velocity of the liquid increases. Typically, a liquid flowing at a velocity greater than 0.2 FPS [0.06 MPS], with adequate suspended solids (100 ppm or 100 micron or larger solids) or aeration, will produce SIGNAL STR readings of at least 000125 counts.
- Page 33 PART 3 - KEYPAD CONFIGURATION FUNCT} 4 mA The 4-20mA output on standard FD6000 Series flow meters is scaled at zero flow equals 4mA and 20 FPS (6.08 MPS) equals 20mA. The 4mA key allows fine adjustments to be made to the “zero” of the 4-20mA output or allows offset to be placed on the 4-20mA output.
- Page 34 PART 3 - KEYPAD CONFIGURATION FUNCT} 20mA The 4-20mA output on standard FD6000 flow meters is scaled at zero flow equals 4mA and 20 FPS (6.08 MPS) equals 20mA. The 20mA key allows fine adjustments to be made to the “span” of the 4-20mA output. To adjust the 20mA output, an ammeter or reliable reference connection to the 4-20mA output must be present.
- Page 35 Choices are 10, 20 and 30 FPS. It is not recommended to deviate alter this value from factory settings, as certain spans have been set that correlate to the set maximum velocity. Consult OMEGA Engineering for adjustment procedures. FUNCT} DAC 3 This key is not used.
-
Page 36: Trouble Shooting
• If GND connection and pipe are at different potentials, ground FD6000 to pipe potential. • If Variable Frequency Drives are being utilized, verify that the FD6000 obtains a flow indication when the pump turns OFF. If it does, contact OMEGA Engineering. 3-20... - Page 37 Erroneous Reading true to the pipe. • Another local ultrasonic instrument is operating at about the same frequency [consult OMEGA Engineering]. • Presence of large amounts of suspended solids or aeration. Use CAL constant to compensate. • Sources of radiated interference are present.
- Page 38 APPENDIX Appendix Fluid Sound Speed Conversions Pipe Dimension Chart: Ductile Iron Pipe Dimension Chart: Cast Iron Pipe Dimension Chart: Steel, SS, PVC Velocity to Volumetric Conversion Chart...
- Page 39 Fluid Sound Speeds Original Date: 10/19/99 Revision: none Revision Date: none 120.0176921 Doppler Fluid Specific Gravity Sound Speed Calibration Entry 20 degrees C ft/s relative to 25C water Acetate, Butyl (n) 1270 4163.9 Acetate, Ethyl 0.901 1085 3559.7 Acetate, Methyl 0.934 1211 3973.1...
- Page 40 Linseed Oil .925-.939 1770 5803.3 Methanol (40,41) 0.79 1076 3530.2 Methyl alcohol (40,44) 0.79 1076 3530.2 Methylene chloride (3) 1.33 1070 3510.5 Methylethyl Ketone 1210 3967.2 Motor Oil (SAE 20/30) .88-.935 1487 4875.4 Octane (23) 0.70 1172 3845.1 Oil, Castor 0.97 1477 4845.8...
- Page 46 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
-
