Versa E680
Disassembly Manual

Advertisement

Table of Contents
loading

Related Manuals for Packard Bell NEC Versa E680

Summary of Contents for Packard Bell NEC Versa E680

  • Page 1 Versa E680 Disassembly Manual...

  • Page 2: Table Of Contents

    Removing the Keyboard............................13 Removing the Main Board............................14 Removing the LCD Module ..........................19 Removing the LCD Panel.............................20 Removing the Touch Pad.............................23 Removing the Speaker Assembly ........................24 DIP Switch Setting..............................24 Screws..................................25 Notice ...................................26 NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 2...

  • Page 3: Overview

    All disassembly procedures can be perform using the following tools: PH 0x60 Philips screwdriver PH 0x40 Philips screwdriver 4.0 x 60 Flat screwdriver 2.0 x 30 Flat screwdriver SW5,0 Spacer screwdriver Small tweezers NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 3...

  • Page 4: Hazardous Voltage

    Inside the power supply are hazardous avviare il sistema senza aver prima messo a voltages that can cause serious personal injury. Always posto il coperchio return a defective power supply to your dealer. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 4...

  • Page 5: Removing The Battery

    1. Make sure to power off the Versa E680. 2. Turn the unit upside down. 3. Unlock the battery and slide it out of its place as the arrow shows in Fig. 1 Fig. 1 Removing the battery NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 5...

  • Page 6: Removing The Hard Disk Drive

    1. Remove the screws as shown in Fig. 2 M3.5x2 Black Fig. 2 Removing the Hard disk drive cover 2. Release screw that secure HDD module as shown in Fig. 3 M6x2.5 Black Fig. 3 Screw on HDD module NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 6...
  • Page 7 Fig. 4 Disconnecting the hard disk drive 4. Unscrew the four screws on both sides of the hard disk drive as shown in Fig. 5 M4x3 Silver Fig. 5 Unscrewing the hard disk drive bracket screws NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 7...

  • Page 8: Removing The Memory Module

    Fig. 6 Removing the screw retaining the memory module slot cover 2. Unclip memory module as shown in Fig. 7 Fig. 7 Removing the memory module 3. Remove the memory module from its slot and put it aside. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 8...

  • Page 9: Removing The Wireless Lan

    Fig. 8 Removing the screws screw retaining the mini PCI slot cover 2. Disconnect the wireless antenna wires from the wireless module Unclip and remove the wireless LAN module. Fig. 9 Wireless LAN & MCD Modem Module NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 9...

  • Page 10: Removing The Cpu

    Fig. 10 Removing the screws retaining CPU cover 4. Remove heat sink screws, disconnect fan connector and lift up the heat sink. M10.5x2 Sliver Fig. 11 Removing the screws retaining the heat plate NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 10...
  • Page 11 5. Unlock CPU from CPU socket and lift up the CPU carefully. Fig. 12 Unlock CPU NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 11...

  • Page 12: Removing The Optical Disk Drive

    Note 2: When assemble the ODD, you might put a tine cardboard on the ODD before insert it to base unit. It will easy the ODD installation Note 3: You consider removing Bottom Cover before remove ODD. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 12...

  • Page 13: Removing The Keyboard

    1. Push the keyboard cover from battery compartment as shown in Fig. 14 Fig. 14 Releasing the keyboard cover 2. Lift up the keyboard cover carefully as shown in Fig. 15 Fig. 15 Lifting up Keyboard Cover NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 13...

  • Page 14: Removing The Main Board

    Keyboard) then perform the following steps: 1. Use small flat screwdriver to remove hinge cover and release screws near to battery compartment at both side. M4.5x3.5 Black Fig. 17 Removing the top cover screws NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 14...
  • Page 15 2. Disconnect all cable connection located near to left speaker as shown in Fig. 18 Fig. 18 LCD Cable and Left speaker connection 3. Disconnect Touch Pad Connection as shown in Fig. 19 Fig. 19 Touch Pad connection NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 15...
  • Page 16 5. Carefully lift up, release the top cover, and put it aside. 6. Unscrew screws on MDC Modem module and disconnect it before lift up MDC Modem. M4.5x3.5 Black Fig. 21 Removing the top cover NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 16...
  • Page 17 A = M5x2.5 Sliver B = M6x2 Black C = M2.5x10 silver Fig. 22 Screws on Main Board 8. Lift up Main Board as shown in Fig. 23 Fig. 23 Lifting up Main Board NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 17...
  • Page 18 Note 1: When lifting up Main Board bewares the coil, attach on the Wireless Antenna. Note 2: Make sure Wireless Antenna are properly place in correct location when assemble. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 18...

  • Page 19: Removing The Lcd Module

    Removing Main Board), then perform the following steps: 1. Release screws show in Fig. 24 M6x2.5 Black Fig. 24 Removing screws retaining LCD Module 2. Carefully lift up the LCD Module. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 19...

  • Page 20: Removing The Lcd Panel

    Fig. 25 Removing the rubber covers & screws on the LCD Module 2. Release the LCD Bezel carefully and put it aside as shown in Fig. 26 Fig. 26 Removing the LCD Bezel NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 20...
  • Page 21 4. Remove the screws at both sides of the LCD panel in order to release the LCD hinges as shown in Fig. 28 M3.5x2 Black Fig. 28 Removing the LCD Panel hinges NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 21...
  • Page 22 6. Remove the screws on LCD module holder at both sides of the LCD base cover and put it aside. Fig. 30 Removing Wireless Antenna M6x2.5 Black 7. Remove the screws at both sides of the LCD Hock and put it aside. M3.5x2 Sliver Fig. 31 LCD Hock NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 22...

  • Page 23: Removing The Touch Pad

    1. Unscrew the screws on the Top Cover as shown in Fig. 32 A = M3.5x2 Black B = M3x2 Sliver C = M3.5x2.5 Sliver Fig. 32 Top cover 2. Carefully separate Touch Pad module from Top cover. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 23...

  • Page 24: Removing The Speaker Assembly

    Fig. 33 Speaker Assembly 2. Carefully remove the Speaker assembly from Top Cover and place it aside. DIP Switch Setting No DIP Switch Setting Required on NEC Versa E680 / Packard Bell Easynote E5. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 24...

  • Page 25: Screws

    NEC COMPUTERS INTERNATIONAL BV SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN; NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL. NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 25...
  • Page 26 The names of actual companies and products mentioned herein may be trademarks and/or registered trademarks of their respective owners. Versa E680 Disassembly Manual Author: Allen Koay Second Edition: January 2004 Document Part Number: Version: 1.1 NECCM A division of NEC Computers International BV NEC Versa E680/PB EasyNote E5 Disassembly Manual Page 26...

This manual is also suitable for:

Easynote e5
