A You can order the following accessories from the Motion Computing
CCESSORIES
website at www.motioncomputing.com/accessories.

Motion Desktop Stand

The Motion Desktop Stand is an easel-like device that holds the Tablet PC in
portrait or landscape modes. You can open the Desktop Stand to different
widths to change the display angle: the wider you open the stand, the less the
Tablet PC tilts back.

Motion FlexDock

The Motion FlexDock is a desktop docking station that provides a
convenient interface for the Tablet PC. Its components are shown below:
Motion FlexDock: (1) Back of FlexDock; (2) Front of FlexDock; (3) RJ-45/Ethernet;
(4) RJ-45 LEDs; (5) IEEE 1394; (6) USB; (7) Audio-in/Microphone Jack; (8) Audio-
out/Headphone Jack; (9) External Monitor; (10) Power Jack; (11) USB
4
3 5
1
2
• Easily docks and undocks with the Tablet PC
• Adjusts to support the display from 0
• Automatically adjusts the display when you rotate the Tablet PC 90
between Primary Landscape and Primary Portrait
• "Grab-and-Go" capability lets you safely remove the Tablet PC from
the FlexDock without turning the system off or putting it in
Stand by mode
NOTE: For more information about installing the FlexDock, see Chapter 4 of this
User Guide or the Installation Guide packaged with the FlexDock.
Chapter 2 Motion Tablet PC Hardware
6
7 8
o o
to 90
Motion Computing M1400 Tablet PC User Guide 18
9 10
11
for viewing and writing
o
