  • Page 1 Packaged Cooling with Electric Heat Rooftop Units Precedent ™ 3 - 10 T ons — 60 Hz RT -PRC005-EN March 2003...

  • Page 2: Introduction

    Introduction Precedent . . . The same Trane With its sleek compact cabinet, rounded quality... with added flexibility. corners and beveled top, it may just be Precedent is a flexible line of packaged the most aesthetically pleasing packaged units that covers a wide variety of unit on the planet.

  • Page 3: Table Of Contents

    Contents Introduction Features and Benefits Application Considerations Selection Procedure Model Number Description General Data Performance Data Cooling Performance Fan Performance Heat Performance Controls Electric Power Dimension and Weights Mechanical Specifications RT -PRC005-EN...

  • Page 4: Features And Benefits

    This allows the drain to be performance. Our compressor line connected through the roof curb instead includes Trane built reciprocating and of a roof penetration. scrolls. Foil-Faced Insulation Easy Access Panels...
  • Page 5 LED is lit, the Micro is operational. The light indicates that the Micro is Micro Controls functioning properly. Several years ago, Trane was the first to • Features expanded diagnostic introduce microprocessor controls into capabilities when used with Trane’s the Light Commercial Market. That Integrated Comfort Systems.
  • Page 6 Trane Communication Interface The following options round-out the Available factory or field-installed. This complete line of Precedent™ options: module when applied with ReliaTel™ easily interfaces with Trane’s Integrated — 0 - 50% Manual or Motorized Comfort System. Outside Air Hinged Access Doors —...
  • Page 7 • Every unit receives a 100% unit run test packaging. before leaving the production line to make sure it lives up to rigorous Trane • Factory shake and drop tests were requirements. used as part of the package design...

  • Page 8: Application Considerations

    Actual clearances which The Precedent™ line features, with appear inadequate should be reviewed ReliaTel™ microprocessor controls, low with the local Trane sales personnel. ambient cooling down to 0F . With electromechanical controls, Precedent features low ambient cooling to 40F .

  • Page 9: Selection Procedure

    Use Calculate the building heating load the gross cooling capacity. The amount the Trane calculation methods or any using the Trane calculation form or other of heat that the fan motor generates is other standard accepted method. standard accepted method.

  • Page 10: Model Number Description

    DIGIT 14 - Fresh Air Selection DIGIT 3 - Airflow 0 = No Communications Interface 0 = No Fresh Air 1 = Trane Communications Interface C = Convertible A = Manual Outside Air Damper 0-50% 2 = LonTalk® Communications Interface...

  • Page 11: General Data

    General (3 - 5 Ton) Data Standard Efficiency Table GD - 1 — General Data 3 Ton Convertible Units 4 Ton Convertible Units 5 Ton Convertible Units TSC036A1, A3, A4, AW TSC048A1 TSC048A3, A4, AW TSC060A1 TSC060A3, A4, AW TSC060AK Cooling Performance Gross Cooling Capacity 37 ,400...
  • Page 12 General (6 - 10 Ton) Data Standard Efficiency Table GD - 2— General Data 6 Ton 7½ Ton 8½ Ton 10 Ton Convertible Units Convertible Units Convertible Units Convertible Units TSC072A3, A4, AW, AK TSC090A3,A4,AW, AK TSC092A3, A4, AW TSC102A3, A4, AW, AK TSC120A3, A4, AW, AK Cooling Performance Gross Cooling Capacity...
  • Page 13 General (3 - 5 Ton) Data High Efficiency Table GD - 3 — General Data 3 Ton 4 Ton 5 Ton Convertible Units Convertible Units Convertible Units THC036A1,A3,A4,AW THC048A1,A3,A4,AW THC060A1 THC060A3,A4,AW Cooling Performance Gross Cooling Capacity 38,000 49,800 62,100 62,400 SEER / EER 12.5/—...
  • Page 14 General (6 - 10 Ton) Data High Efficiency Table GD - 4— General Data 6 Ton 7½ Ton 8½ Ton 10 Ton Convertible Units Convertible Units Convertible Units Convertible Units THC072A3, A4, AW THC092A3, A4, AW THC102A3, A4. AW THC120A3, A4, AW Cooling Performance Gross Cooling Capacity 73,000...

  • Page 15: Performance Data

    Performance (3, 4 Ton) Data Standard Efficiency Table PD-1 — Gross Cooling Capacities (MBH) 3 Ton Single/Three Phase TSC036A1, A3, A4, AW Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 34.6 29.0 38.6 22.3 40.6 14.7 31.2 27 .3 36.6 21.1 39.5 13.8 28.2 25.6 33.4 19.6 37 .8 12.9 25.1 24.1 29.6 18.2 35.5 11.9 35.6 35.0 38.8 27 .3 41.0 20.2 32.6 32.6 36.8 26.6 39.8 19.5 30.0 30.0 33.5 25.2 38.0 18.5 27 .3 27 .3 29.9 23.5 35.6 17 .5 1080...
  • Page 16 Performance (4, 5 Ton) Data Standard Efficiency Table PD-3 — Gross Cooling Capacities (MBH) 4 Ton Three Phase TSC048A3, A4, AW Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 44.8 38.6 51.4 29.8 56.1 20.1 41.0 36.6 48.2 28.2 53.7 18.9 37 .3 34.7 44.2 26.4 50.8 17 .6 33.4 32.7 39.6 25.2 47 .1 16.0 46.0 46.0 51.6 37 .4 56.5 27 .9 42.9 42.9 48.3 35.8 54.0 26.6 39.7 39.7 44.4 34.0 51.0 25.2 36.4 36.4 40.0 32.0 47 .2 23.6 1440...
  • Page 17 Performance (6, 7½ Ton) Data Standard Efficiency Table PD-5 — Gross Cooling Capacities (MBH) 6 Ton Three Phase TSC072A3, A4, AW, AK Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 65.9 55.0 73.4 43.5 76.7 28.3 61.0 52.5 70.7 40.9 75.4 27 .3 56.3 50.1 66.3 38.8 73.2 26.0 51.7 47 .7 60.9 36.4 70.3 24.6 67 .6 66.2 73.7 52.2 77 .5 38.9 63.2 63.2 70.9 51.1 76.0 37 .8 59.2 59.2 66.4 49.1 73.7 36.4 55.3 55.3 61.0 46.6 70.6 34.9 2160...
  • Page 18 Performance (7½, 8½ Ton) Data Standard Efficiency Table PD-7 — Gross Cooling Capacities (MBH) 7½ Ton Three Phase Dual Compressors TSC092A3, A4, AW Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 84.6 72.9 93.9 55.3 98.4 36.4 78.2 69.6 90.1 53.3 96.9 35.1 71.8 66.3 83.9 50.4 94.0 33.3 65.3 63.1 76.5 47 .1 89.4 31.2 86.8 86.8 94.4 68.5 99.6 50.0 81.8 81.8 90.5 67 .5 98.0 49.7 76.4 76.4 84.3 64.7 94.5 47 .5 70.9 70.9 77 .1 61.4 89.6 45.3 2700...
  • Page 19 Performance (10 Ton) Data Standard Efficiency Table PD-9 — Gross Cooling Capacities (MBH) 10 Ton Three Phase TSC120A3, A4, AW, AK Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 109.2 95.1 119.3 71.0 123.3 46.1 101.7 91.5 115.7 69.0 122.1 44.6 93.2 87 .4 108.3 66.1 119.9 42.8 84.9 83.4 99.6 62.4 114.5 40.4 112.4 112.4 119.9 86.9 124.6 64.8 106.9 106.9 116.3 87 .4 123.4 63.2 99.8 99.8 109.3 84.9 120.2 61.3 92.8 92.8 100.9 81.3 115.0 58.9 3600...
  • Page 20 Performance (3, 4 Ton) Data High Efficiency Table PD-10 — Gross Cooling Capacities (MBH) 3 Ton THC036A1, A3, A4, AW Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 34.2 29.2 39.8 22.7 43.1 15.2 31.1 27 .4 37 .0 21.2 41.3 14.1 28.0 25.7 33.3 19.8 39.0 12.9 24.8 24.0 29.8 18.1 36.1 11.6 34.9 34.9 40.0 28.5 43.5 21.3 32.3 32.3 37 .1 27 .1 41.6 20.1 29.7 29.7 33.5 25.3 39.2 18.8 27 .1 27 .1 30.0 23.6 36.2 17 .5 1080...
  • Page 21 Performance (5 Ton) Data High Efficiency Table PD-12 — Gross Cooling Capacities (MBH) 5 Ton Single Phase THC060A1 Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 56.2 48.2 64.3 37 .8 68.4 24.8 51.4 45.6 60.5 35.2 66.7 23.5 46.8 43.2 55.3 32.8 63.9 21.9 42.2 40.8 50.0 31.0 59.9 20.1 57 .6 57 .6 64.6 46.6 69.3 34.7 53.7 53.7 60.7 44.8 67 .3 33.1 49.8 49.8 55.5 42.3 64.2 31.5 45.9 45.9 50.5 39.9 60.1 29.6 1800...
  • Page 22 Performance (5 Ton) Data High Efficiency Table PD-14 — Gross Cooling Capacities (MBH) 5Ton THC060A3, A4, AW – Dehumidification Option Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 50.7 36.2 57 .0 29.4 63.7 22.6 48.1 34.6 54.2 27 .9 60.7 21.0 45.5 32.9 51.3 26.2 57 .5 19.4 42.7 31.2 48.2 24.5 54.1 17 .7 50.8 41.8 57 .1 35.1 63.8 28.2 48.3 40.2 54.4 33.5 60.8 26.6 45.6 38.6 51.5 31.9 57 .6 25.0 42.9 36.8 48.4 30.1 54.2 23.3 1000...
  • Page 23 Performance (6, 7½ Ton) Data High Efficiency Table PD-15 — Gross Cooling Capacities (MBH) 6Ton Three Phase THC072A3, A4, AW Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 67 .3 56.6 73.6 42.5 74.5 27 .6 61.6 53.5 71.8 41.9 75.1 26.6 55.8 50.4 66.8 38.7 74.1 25.3 49.8 47 .2 59.9 36.3 71.3 23.5 68.7 68.2 73.8 51.7 75.4 37 .0 63.6 63.6 72.0 52.1 76.0 38.1 58.9 58.9 66.9 49.7 74.7 36.4 54.1 54.1 60.2 46.5 71.5 34.5 2160...
  • Page 24 Performance (8½, 10 Ton) Data High Efficiency Table PD-17 — Gross Cooling Capacities (MBH) 8½ Ton Three Phase THC102A3, A4, AW Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 94.0 81.8 105.7 62.8 110.8 40.9 86.3 77 .8 100.7 59.7 109.7 39.3 79.0 74.2 92.4 56.0 105.5 37 .1 71.8 70.5 84.0 53.1 99.6 34.6 96.9 96.9 106.2 77 .6 112.0 56.0 90.6 90.6 101.1 75.9 110.1 55.4 84.5 84.5 92.9 72.2 106.1 53.2 78.3 78.3 84.7 68.5 99.8 50.6 3060...
  • Page 25 Performance (10 Ton) Data High Efficiency Table PD-19— Gross Cooling Capacities (MBH) 10Ton THC120A3, A4, AW – Dehumidification Option Ambient Temperature (F) Enter. Entering Wet Bulb (F) Bulb Airflow MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC 94.2 68.9 105.8 56.2 118.4 42.6 89.7 66.2 101.0 53.6 113.2 40.0 84.8 63.4 95.8 50.9 107 .6 37 .3 79.7 60.4 90.2 48.1 101.5 34.6 94.4 79.8 106.0 66.8 118.6 53.6 89.9 77 .1 101.2 64.1 113.4 51.0 85.0 74.2 96.0 61.4 107 .8 48.3 79.9 71.2 90.4 58.4 101.7 45.4 2000...

  • Page 26: Fan Performance

    Fan motor heat (MBH) = 3.72 x Fan Bhp + .24. Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature motor failure.
  • Page 27 0.33 0.37 0.43 0.50 0.56 0.62 0.68 1024 0.74 Trane’s factory supplied motors, in commercial For Standard Evaporator Fan Speed (RPM), reference Table PD-48. equipment, are definite purpose motors, NOTES: NOTES: NOTES: NOTES: NOTES: specifically designed and tested to operate Data includes pressure drop due to standard filters and wet coils.
  • Page 28 1. Field Supplied Fan Sheave AK61 required. Field Supplied Belt may be necessary. 2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary. Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions.
  • Page 29 1.45 1188 1.53 1221 1.60 — — — — Trane’s factory supplied motors, in commercial For Standard Evaporator Fan Speed (RPM), reference Table PD-48. equipment, are definite purpose motors, NOTES: NOTES: NOTES: NOTES: NOTES: specifically designed and tested to operate Data includes pressure drop due to standard filters and wet coils.
  • Page 30 1.06 1.16 1.27 1.37 1.48 For Standard Evaporator Fan Speed (RPM), reference Table PD-48. Trane’s factory supplied motors, in commercial equipment, are definite purpose NOTES: NOTES: NOTES: NOTES: NOTES: motors, specifically designed and tested to operate reliably and continuously at Data includes pressure drop due to standard filters and wet coils.
  • Page 31 1.06 1.16 1.27 1.37 1.48 For Standard Evaporator Fan Speed (RPM), reference Table PD-48. Trane’s factory supplied motors, in commercial equipment, are definite purpose NOTES: NOTES: NOTES: NOTES: NOTES: motors, specifically designed and tested to operate reliably and continuously at Data includes pressure drop due to standard filters and wet coils.
  • Page 32 1.87 1019 1.99 1052 2.13 1085 2.26 For Standard Evaporator Fan Speed (RPM), reference Table PD-48. Trane’s factory supplied motors, in commercial equipment, are definite purpose NOTES: NOTES: NOTES: NOTES: NOTES: motors, specifically designed and tested to operate reliably and continuously at Data includes pressure drop due to standard filters and wet coils.
  • Page 33 1.46 1.60 1.74 1.88 2.04 2.20 Trane’s factory supplied motors, in commercial equipment, are definite purpose For Standard Evaporator Fan Speed (RPM), reference Table PD-48. motors, specifically designed and tested to operate reliably and continuously at NOTES: NOTES: NOTES: NOTES: NOTES: all cataloged conditions.
  • Page 34 1022 2.87 1046 3.04 3-HP Standard Motor & Drive Trane’s factory supplied motors, in commercial equipment, are definite purpose For Standard Evaporator Fan Speed (RPM), reference Table PD-48. motors, specifically designed and tested to operate reliably and continuously at NOTES:...
  • Page 35 Fan motor heat (MBH) = 3.72 x Fan Bhp + .24. Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature motor failure.
  • Page 36 0.33 0.37 0.43 0.50 0.56 0.62 0.68 1024 0.74 Trane’s factory supplied motors, in commercial For Standard Evaporator Fan Speed (RPM), reference Table PD-50. equipment, are definite purpose motors, NOTES: NOTES: NOTES: NOTES: NOTES: specifically designed and tested to operate Data includes pressure drop due to standard filters and wet coils.
  • Page 37 1078 1.00 1116 1.09 1151 1.17 For Standard Evaporator Fan Speed (RPM), reference Table PD-50. Trane’s factory supplied motors, in commercial NOTES: NOTES: NOTES: NOTES: NOTES: equipment, are definite purpose motors, Data includes pressure drop due to standard filters and wet coils.
  • Page 38 ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM. ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM. Trane’s factory supplied motors, in commercial equipment, are NOTES: definite purpose motors, specifically designed and tested to Data includes pressure drop due to standard filters and wet coils.
  • Page 39 ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM. ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM. Trane’s factory supplied motors, in commercial equipment, NOTES: are definite purpose motors, specifically designed and Data includes pressure drop due to standard filters and wet coils.
  • Page 40 1.01 1.11 1.22 1.33 1.44 1.54 Trane’s factory supplied motors, in commercial equipment, are definite purpose For Standard Evaporator Fan Speed (RPM), reference Table PD-50. motors, specifically designed and tested to operate reliably and continuously at NOTES: NOTES: NOTES: NOTES: NOTES: all cataloged conditions.
  • Page 41 NOTES: NOTES: NOTES: Trane’s factory supplied motors, in commercial equipment, are definite purpose Data includes pressure drop due to standard filters and wet coils. motors, specifically designed and tested to operate reliably and continuously at No accessories or options are included in pressure drop data.
  • Page 42 1.83 1.99 2.16 2.33 2-HP Standard Motor & Drive For Standard Evaporator Fan Speed (RPM), reference Table PD-50. Trane’s factory supplied motors, in commercial equipment, are definite purpose NOTES: NOTES: NOTES: NOTES: NOTES: motors, specifically designed and tested to operate reliably and continuously at Data includes pressure drop due to standard filters and wet coils.
  • Page 43 1045 3.03 1070 3.22 3-HP Standard Motor & Drive Trane’s factory supplied motors, in commercial equipment, are definite purpose For Standard Evaporator Fan Speed (RPM), reference Table PD-50. motors, specifically designed and tested to operate reliably and continuously at NOTES:...
  • Page 44 3.81 1181 4.00 1206 4.19 5-HP Oversized Motor & Drive Trane’s factory supplied motors, in commercial equipment, are definite purpose For Standard Evaporator Fan Speed (RPM), reference Table PD-50. NOTES: NOTES: NOTES: motors, specifically designed and tested to operate reliably and continuously at...
  • Page 45 Performance Data Table PD-56— Standard Motor & Sheave/Fan Speed (Rpm) Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn Tons Model No. Open Open Open Open Open Open Closed T#C036A 1043 1117 T#C048A 1000 1083 1167 1250 T#C060A 1077...
  • Page 46 Performance Data Table PD-60 — Static Pressure Drops Through Accessories (Inches Water Column) — 3 - 10 Tons Economizer with Electric Heater Unit Standard Through 2 Inch OA/RA Dampers Accessory (kW) Tons Model No. Filters Reheat Pleated Filters 100% OA 100% RA 100%OA 100%RA 9-15 17-36...
  • Page 47 Performance Data Table PD-62— Auxiliary Electric Heat Capacity Total Stage1 Stage 2 Unit No. of Tons Model No. Input Output Stages Input Output Input Output 5.00 17.07 5.00 17.07 — — T#C036A1 10.00 34.14 5.00 17.07 5.00 17.07 13.80 47.11 8.80 30.04 5.00...
  • Page 48 Performance Data Table PD-63 — 3-5 Tons Air Temperature Rise Across Electric Heaters (Degrees F) 3 Ton 4 Ton 5 Ton 1200 CFM 1600 CFM 2000 CFM Single Phase Three Phase Single Phase Three Phase Single Phase Three Phase Stages T#C036A1 T#C036A3,A4,AW T#C048A1...

  • Page 49: Controls

    CO2 temperature space adjustment and ventilation override buttons to requirements. provide central The CO2 control through a accessory shall Trane Integrated be available as field installed. Comfort system. RT-PRC005-EN...
  • Page 50 Electrical (Standard Data Efficiency) Table ED-1 — Unit Wiring — Standard Efficiency Optional Standard Indoor Fan Motor Oversize Indoor Fan Motor Belt Drive Indoor Fan Motor Unit Minimum Maximum Fuse Minimum Maximum Fuse Minimum Maximum Fuse Unit Operating Circuit Size Or Maximum Circuit Size Or Maximum Circuit...
  • Page 51 (High Electrical Efficiency) Data Table ED-2 — Unit Wiring — High Efficiency Optional Standard Indoor Fan Motor Oversize Indoor Fan Motor Belt Drive Indoor Fan Motor Unit Minimum Maximum Fuse Minimum Maximum Fuse Minimum Maximum Fuse Unit Operating Circuit Size Or Maximum Circuit Size Or Maximum Circuit...
  • Page 52 Electrical (Standard Data Efficiency) Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection) —208/230 Volts — Standard Efficiency Standard Indoor Motor Oversize Indoor Motor To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or Tons With Model No.
  • Page 53 Electrical (Standard Data Efficiency) Table ED-4 — Unit Wiring With Electric Heat (Single Point Connection) — Standard Efficiency Standard Indoor Motor Oversize Indoor Motor To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or Tons With Model No. kW Rating Stages Max Circuit Breaker...
  • Page 54 Electrical (Standard Data Efficiency) Table ED-5 — Unit Wiring With Electric Heat (Single Point Connection) — 575 Volts — Standard Efficiency Standard Indoor Motor Oversize Indoor Motor To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or Tons With Model No.

  • Page 55: Electrical Data

    Electrical (Standard Data Efficiency) Table ED-5 — Unit Wiring With Electric Heat (Single Point Connection) — Optional Belt Drive — Standard Efficiency Optional Belt Drive Indoor Motor To Use Heater Heater Control Max Fuse Size Orr Tons With Model No. kW Rating Stages Max Circuit Breaker...
  • Page 56 Electrical (High Efficiency) Data Table ED-7 — Unit Wiring With Electric Heat (Single Point Connection) — 208/230 Volts — High Efficiency Standard Indoor Motor Oversize Indoor Motor To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or Tons With Model No.
  • Page 57 Electrical Data (High Efficiency) Table ED-8 — Unit Wiring With Electric Heat (Single Point Connection) — 460 Volts — High Efficiency Standard Indoor Motor Oversize Indoor Motor To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or Tons With Model No.
  • Page 58 Electrical Data (High Efficiency) Table ED-9 — Unit Wiring With Electric Heat (Single Point Connection) — 575 Volts — High Efficiency Standard Indoor Motor Oversize Indoor Motor To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or Tons With Model No.
  • Page 59 Electrical (High Efficiency) Data Table ED-10 — Unit Wiring With Electric Heat (Single Point Connection) — Optional Belt Drive — High Efficiency Belt Drive Indoor Motor To Use Heater Heater Control Max Fuse Size Or Tons With Model No. kW Rating Stages Max Circuit Breaker 208/230 Volts Single Phase...
  • Page 60 Electrical Data Table ED-11 — Electrical Characteristics — Evaporator Fan Motor — 60 Cycle — Standard and Oversized Standard Evaporator Fan Motor Oversized Evaporator Fan Motor Amps Amps Unit Tons Model No. Volts Phase Volts Phase T#C036A1 208-230 2.30 3.90 208-230 4.70 9.80...
  • Page 61 Electrical Data Table ED-13— Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle — Standard Efficiency Compressor Motors Condenser Fan Motors Amps Amps Unit Tons Model No. Volts Phase Phase TSC036A1 208-230 3450 17 .2 104.0 TSC036A3 208-230 3450 11.3 74.0...
  • Page 62 Electrical Data T able ED-14 — Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle — High Efficiency Compressor Motors Condenser Fan Motors Unit Amps Amps Tons Model No. Volts Phase Phase THC036A1 208-230 3450 16.1 88.0 THC036A3 208-230 3450 10.3...

  • Page 63: Jobsite Connections

    Jobsite Connections Zone Sensors — Typical Number Of Wires DISCONNECT SWITCH A— Manual Changeover ........4 (BY OTHERS) Manual/Auto Changeover ......5 Manual/Auto Changeover with Status Indication LED’s ......10 ZONE SENSOR Programmable Night Setback with OR THERMOSTAT Status Indication LED’s ......7 ROOFTOP UNIT Thermostats —...
  • Page 64 Dimensional Data (3-5 Tons) All dimensions are in inches/millimeters. 3 - 5 Tons Standard Efficiency 3 and 4 Tons High Efficiency 5 Tons High Efficiency RT -PRC005-EN...
  • Page 65 Dimensional Data (3-5 Tons) All dimensions are in inches/millimeters. Downflow Airflow Supply/Return Through the Base Utilities Horizontal Airflow Supply/Return Unit Clearance and Roof Opening RT-PRC005-EN...
  • Page 66 Dimensional Data (3-5 Tons) All dimensions are in inches. 37 1/8” 928 MM Downflow Duct Connections — Field Fabricated RT -PRC005-EN...
  • Page 67 Dimensional Data (6-10 Tons) All dimensions are in inches. 6 Tons Standard and High Efficiency 7½ Tons Standard Efficiency 7½ Tons High Efficiency 8½ and 10 Tons Standard and High Efficiency RT-PRC005-EN...
  • Page 68 Dimensional Data (6-10 Tons) All dimensions are in inches. 6-10 Tons — Downflow Airflow Supply and Return; Through the Base Utilities Return 6-10 Tons — Horizontal Airflow Supply and Return Supply 6-10 Tons — Unit Clearance and Roof Opening RT -PRC005-EN...
  • Page 69 Dimensional Data (6-10 Tons) All dimensions are in inches. 6-10 Tons — Roof Curb ALL FLANGES 1 1/4” (31 MM) 6-10 Tons — Downflow Duct Connections — Field Fabricated RT-PRC005-EN...

  • Page 70: Dimensional Data

    Dimensional (3-5 Tons Options/ Data Accessories) All dimensions are in inches. Barometric Relief Damper Hood Economizer , Manual or Motorized Fresh Air Damper Swing Diameter for Hinged Doors Option See Page 65 for Through the Base Utilities Information RT -PRC005-EN...
  • Page 71 Dimensional (6-10 Tons Options/ Data Accessories) All dimensions are in inches. 6-10 Tons — Power Exhaust 6-10 Tons — Economizer and Barometric Relief Damper Hoods 6-10 Tons — Swing Diameter for Hinged Door(s) Option See Page 68 for Through the Base Utilities Information RT-PRC005-EN...
  • Page 72 Weights Table W-1— Maximum Unit And Corner Weights (Lbs) And Center Of Gravity Dimensions (In.) Maximum Weights (Lbs) Corner Weights (Lbs) Center of Gravity (In.) Unit Tons Model No. Shipping Length Width TSC036A THC036A TSC048A THC048A TSC060A THC060A TSC072A THC072A TSC090A 7½...

  • Page 73: Cooling Performance

    Mechanical Specifications General Unit Top be leak tested to 200 psig and pressure The units shall be convertible airflow. The top cover shall be one piece tested to 450 psig. The condensor coil The operating range shall be between construction or where seams exist, it shall have a patent pending 1 + 1 + 1 115°F and 0°F in cooling as standard shall be double-hemmed and gasket-...
  • Page 74 Mechanical Specifications Through the Base Electrical with Circuit operating position by the installing 24-volt electromechanical control circuit Breaker — This option is a factory- contractor. shall include control transformer and installed, thermal magnetic, molded contactor pressure lugs for power Powered Exhaust — The field installed case, HACR Circuit Breaker with wiring.
  • Page 75 The controlled units. It can be field-installed, provided to interface microprocessor humidity sensor can be set for humidity or factory-installed with the factory- controlled units with the Trane Integrated levels between 40% and 60% relative installed economizer. Comfort systems.

  • Page 76: Rt -Prc005-En
