Vaillant multi twin split range Overview page 9

Technical specification
Indoor units
VA10 - 020
System reference MXNHI
Cooling capacity kW 2.00
Heating capacity kW 2.30
Net dimensions
285x760x182
HxLxD mm
Power supply V/Ph/Hz 230/1/50
Air flow volume
450/400/370
3
high/med/low m /h
Sound pressure
32/43
2
level min/max dB(A)
Pipe connection
1/4-3/8
liq/gas in
Net weight Kg 8.6
Recommended MCB
10.0
size (type D) A
System reference
1
Nominal cooling capacity
(Min-max)
Nominal heating capacity 1
(Min-max)
Nominal power input cooling/heating
Operating current cooling/heating
EER/COP
Nominal energy label cooling/heating
Compressor type
Max. power input
Air flow volume high/med/low
3
Sound pressure level (max)
Dimensions HxLxD
Net weight
Installation
Power supply
Maximum operating current
Power to:
Interconnecting wiring
Recommended fuse rating (type D)
Pipe connection liq/gas
Max. piping length (longest single pipe circuit)
Max. total pipe length of all circuits added together
Max. height IU under OU
Max. height OU under IU
Chargless length (total for all circuits)
Additional charge per meter
1
Actual ratings dependent on system components.
2
Sound pressure level indoor unit: directivity 3 dB(A) distance 2.2m.
3
Sound pressure level external unit: directivity 3 dB(A) distance 1.8m.
Nominal cooling capacities based on indoor temperatures of 27ºCDB/19ºCWB -- outdoor temperatures 35ºCDB/24ºCWB
* adaptor supplied.
VA10 - 025 VA10 - 035
MXNHI MXNHI
2.50 3.50
2.90 3.80
285x760x182 285x760x182
230/1/50 230/1/50
500/450/400 600/550/500
32/43 32/43
1/4-3/8 1/4-3/8
8.6 8.6
10.0 10.0
kW
kW
kW
kW
1
kW
A
1
kW
m 3 /h
dB(A)
mm
Kg
V/ph/Hz
A
A
in
m
m
m
m
m
gr
VA6 - 035
MXNHKI
3.24
3.45
260x570x570
230/1/50
630/530/450
37/44
1/4-3/8
17.0
10.0
Outdoor units
VA6 - 050 MXNHO VA6 - 085 MXNHO
5.55 8.20
1.80-6.3 1.5-10.25
6.65 9.86
1.8-7.5 1.8-11.5
1.72/1.76 2.47/2.69
8.60/9.34 12.30/11.90
3.23/3.78 3.31/3.67
A/A A/A
Inverter DC twin rotary Inverter DC twin rotary
2.30 3.80
3200/2300/1600 4000/3200/2300
53 53
928x288x680 840x1068x340
54 74
230/1/50 230/1/50
10.20 16.60
Outdoor + indoor Outdoor + indoor
2 core sheathed data 2 core sheathed data
16 20
1/4-3/8 1/4-3/8
25 25
45 60
10 10
15 15
30 40
20 20
VA6 - 050 VA6 - 035
MXNHKI MXNHDI
5.03 3.61
5.47 3.85
260x580x580 290x610x550
230/1/50 230/1/50
[550/]500/
670/600/550
450/400
37/44 35/40
1/4-1/2* 1/4-3/8
19.0 14.0
10.0 10.0
VA6 - 105 MXNHO
10.27
1.5-11.0
11.11
1.8-11.5
3.27/3.14
16.37/14.00
3.14/3.53
B/B
Inverter DC twin rotary
4.00
4300/3500/2600
55
840x1068x340
75
230/1/50
18.10
Outdoor + indoor
2 core sheathed data
20
1/4-3/8
25
60
10
15
40
20
VA6 - 050
MXNHDI
5.15
5.65
290x1090x500
230/1/50
[1270/]1160/
1020/900
38/44
1/4-1/2*
25.0
10.0
9
