Technical Specification - Vaillant multi twin split range Overview

Technical specification

System reference
Cooling capacity
Min ~ max
Heating capacity
Min ~ max
Power input cooling/heating
Operating current cooling/heating
EER/COP
Energy level class
1
Annual consumption
Indoor unit (1)
Indoor unit (2)
Air flow volume (unit 1) low/med/high
Air flow volume (unit 2) low/med/high
Remote control
Sound pressure level (unit 1 - unit 2) min/max
Dimensions HxLxD (unit 1)
Dimensions HxLxD (unit 1)
Weight
Outdoor unit
Air flow volume
Sound pressure level 3
Refrigerant
Refrigerant charge heat pump
Compressor type
Dimensions HxLxD
Weight
Installation
Power supply
Max operating current
Recommended fuse size (Type D)
Interconnecting cores (indoor to outdoor)
Supply to
Pipe connection liq/gas (Units 1&2)
Max. Piping length (each circuit)
Max. height differential indoor to outdoor
Chargeless length
Additional charge per metre
1
Based on 500 hours operating at maximum load
2
Sound pressure level IU: directivity 3 dB(A) distance 2.2 m.
3
Sound pressure level OU: directivity 3 dB(A) distance 1.8 m.
4
Minimum operating temperature cooling/heating 18ºC/-7ºC
Nominal cooling capacities based on indoor temperatures of 27ºCDB/19ºCWB -- outdoor temperatures 35ºCDB/24ºCWB.
climaVAIR performance multi inverter heat pump
V10-050 M2N
kW 5.42
kW 1.25 - 6.00
kW 6.32
kW 1.62 - 6.8
kW 1.63/1.63
A 7.5/8.8
3.33/3.87
A/A
kWh 813
V10-025 MNHI +
V10-025 MNHI
m3/h 500/440/380
m3/h 500/440/380
Infra red
2
dB(A) 26/38 - 26/38
mm 285x760x185
mm 285x760x185
Kg 8.6
V10-050 M2NHO
m3/h 2800
dB(A) 52
R410a
gr 1800
DC scroll
mm 915x699x325
Kg 42
V.Ph.Hz 230/1/50
A 10.3
A 16
3 core + Earth (to each indoor)
Outdoor
inches 1/4-3/8
m 15
m 10
m 10
gr 20g
V10-060 M2N
5.47
1.3 - 6.1
6.44
1.72 - 6.96
1.64/1.77
7.8/7.4
3.33/3.64
A/A
821
V10-025 MNHI +
V10-035 MNHI
500/440/380
500/440/380
Infra red
26/38 - 28/40
285x760x185
285x760x185
8.6
V10-060 M2NHO
2800
52
R410a
1800
DC scroll
915x699x325
42
230/1/50
10.4
16
3 core + Earth (to each indoor)
Outdoor
1/4-3/8
15
10
10
20g
6 | 7 | 8
