Display Description - UNI-T UT511 Operating Manual

Model UT511: OPERATING MANUAL
Number Meaning
1 Indicator for DC voltage
2 Indicator for data store full
3 Indicator for clearing
4 Indicator for AC voltage
5 Indicator for timer
6 Step symbol
7 Indicates selected pass/fail compare
value
8 Indicates for negative reading
9 Timer 1 symbol
10 Timer 2 symbol
11 Data store is on
Table 6. Display Description
Number
12
13
14
15
16
17
18
19
20
21
Meaning
Data recall is on
Indicator for polarization index
Unit symbols
The continuity buzzer is on
Compare feature pass
Analogue bar graph
Risk of electric shock
Compare feature fail
Indicator for power adaptor
Battery life indicator
