B2723T15
///
Transport GX15
B2723T15M
Revision 1.0
Copyright © TYAN Computer Corporation, 2002-2003. All rights reserved. No
part of this manual may be reproduced or translated without prior written
consent from TYAN Computer Corp.
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN, Tiger i7501 S2723, Transport B2723T15, Transport B2723T15M,
Transport GX15 are trademarks of TYAN Computer Corporation.
Intel, Xeon and combinations thereof are trademarks of Intel Corporation.
AMI, AMIBIOS are trademarks of AMI Software Incorporated.
Microsoft, Windows are trademarks of Microsoft Corporation..
QLogic, Zircon, and combinations thereof are trademarks of QLogic
Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
Winbond is a trademark of Winbond Electronics Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.
Information contained in this document is furnished by TYAN Computer
Corporation and has been reviewed for accuracy and reliability prior to printing.
TYAN assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN products including liability or
warranties relating to fitness for a particular purpose or merchantability. TYAN
retains the right to make changes to product descriptions and/or specifications
at any time, without notice. In no event will TYAN be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
1
http://www.tyan.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TYAN Transport GX15 B2723T15
Summary of Contents for TYAN Transport GX15 B2723T15
- Page 1 In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
-
Page 2: Table Of Contents
4.2 Features at a glance ..……..……………………………..Page 19 4.3 Jumper setting ...……………………………………Page 20 4.4 Specification …...…………………………………Page 20 4.5 SMDC Features ….…………………………………..Page 25 4.6 Tyan System Operator (TSO) …..………………………………….Page 31 summary Appendix …..………………………………….Page 32 Safety Document of system .….………………………………….Page 32 Safety Document of SMDC .….………………………………….Page 33... -
Page 3: Before You Begin
1 x Tiger i7501 (S2723) Quick Reference 1 x TYAN driver CD 1 x screw 1x Tyan M3289 SMDC (optional item for B2723T15M) 1x 50-pin SMDC cable (optional item for B2723T15M) If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process. -
Page 4: Chapter 1: Introduction
IPMI Server Management, PCI-X support, one 10/100/1000 and one 10/100 Ethernet ports and onboard video. Remember to visit TYAN’s Website at http://www.tyan.com. There you can find information on all of TYAN’s products with FAQs, distributors list and BIOS setting explanations. http://www.tyan.com... -
Page 5: Hardware Specifications
• MCH + ICH3 + P64H2 + FWH • Barebone weight: 11 kg • Complete system weight: 11.5 kg I/O Expansion • 1x PCI-X expansion slot on riser card TYAN reserves the right to add support or discontinue support for any OS without notice. http://www.tyan.com... -
Page 6: Front View
1.3 – Front View Power/ PS/2 Mouse and Keyboard Reset Switches Double-deck USB 1.1 Port Power /HDD LEDs Add-on PCI Expansion Slot Serial Port Gigabit Ethernet w/ LED VGA Port Fast Ethernet w/ LED http://www.tyan.com... -
Page 7: Top View
1.4– Top View Cooling Fans EPS 12V CPU 1 CPU 2 Memory Riser card SMDC Slots ( Server Management Daughter Card) http://www.tyan.com... -
Page 8: Chapter 2: Hardware Installation
(i.e. power supply case). For the safest conditions, Tyan recommends wearing a static safety wrist strap. (2) Avoid touching the motherboard components, IC chips, connectors, memory modules, and leads. -
Page 9: Opening The Chassis
2.1 Opening the chassis 2.1.1 Push the top cover toward back. 2.1.2 Lift up the top cover and remove it from the chassis. 2.1.3 Top cover removed. http://www.tyan.com... -
Page 10: Installing Hdd
2.2.1 Slide the HDD into place. 2.2.2 Connect the Power cable to HDD. 2.2.3 Connect ATA cable to HDD. Note: ATA cable is pre-connected to M/B (J23). 2.2.4 Secure the drive with 4 screws from the bottom of the chassis. http://www.tyan.com... -
Page 11: Installing Processor(S) And
2.3.5 Your processor is installed 2.3.6 Repeat these steps for any additional processors if you are using more than one processor. 2.3.7 Seat heatsinks between brackets (pre-installed) on the processor and attach heatsinks clips to secure. http://www.tyan.com... - Page 12 2.4 – Installing Add-on PCI Card 2.4.1 Loosen the screw and remove PCI slot cover. 2.4.2 Plug your PCI/PCI-X add-on card into the PCI socket slot on the riser card. 2.4.3 Secure Add-on card by tightening the screw from the side. http://www.tyan.com...
-
Page 13: Installing Memory Modules
2.5.3 The B2723T15/B2723T15M requires that memory modules be installed IN PAIRS. Please refer to S2723/Tiger i7501 M/B User’s Manual page 16~18 for exact details. 2.5.4 To ensure thermal performance, LOW PROFILE memory modules are recommended. http://www.tyan.com... -
Page 14: Installing Vent Duct
2.6 Installing Vent Duct 2.6.1 Attach the vent duct on the CPU area. 2.6.2 Place the vent duct on the top of CPU area, in between the capacitors as shown in pictures. http://www.tyan.com... -
Page 15: Finishing Up
In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com... - Page 16 Should you still prefer to have rails in order to slide the system in and out from the cabinet, you may purchase a separate rail kit from Tyan. Please contact your local Tyan office for more details.
- Page 17 3.1 Installing system into a cabinet or telco rack 3.1.1 Place the system between the poles inside the cabinet. 3.1.2 Secure the system to the desired location using screws provided by cabinet manufacturer. 3.1.3 Finished look. http://www.tyan.com...
-
Page 18: Chapter 4: Server Management Daughter
IT Managers to have remote and multi-interface access to monitor, control, and diagnose activities. The Tyan SMDC is powered by an intelligent controller known as the Baseboard Management Control (BMC). The BMC is a standalone mini-CPU that runs on its own Real Time Operating System (RTOS) to complete a variety of tasks. -
Page 19: Features At A Glance
SMDC allows for system diagnostic when the system is not in Diagnostic operation (either intentionally or accidentally) through remote IPMI command execution. BMC Firmware SMDC supports onboard update of the BMC firmware. Update Alert Standard Forum Tyan System Operator™ http://www.tyan.com... -
Page 20: Jumper Setting
Teamed with other IPMB Devices (PMCs and EMCs) Remote Monitor, Control and Diagnostics Sensor Repository System Event Log Field Replaceable Unit Information Storage Emergency Management Port Console Real Time Clock Upgrade firmware Front Panel LED and Buzzer “Always Ready” TYAN System Operator ™ (TSO) OEM Drivers http://www.tyan.com... - Page 21 Hardware Monitoring The latest hardware from TYAN is equipped with Baseboard Management Controller (BMC) from QLogic Zircon, which provides not only system monitoring but also remote manageability. The BMC can always monitor the hardware regardless of how the operating system is running. With the BMC onboard, any IPMI-compliant software can monitor, control or diagnose the hardware locally, or from a remote site.
- Page 22 Certain pre-programmed actions may take place such as system reboot or system shutdown. Field Replaceable Unit Information Storage (FRU) Chassis, Board, Product and other important service information are stored and secured in an area generally known as FRU. http://www.tyan.com...
- Page 23 The boot block section code is normally programmed in factory and it provides protection against accidental flash failure or power loss. Front Panel LED and Buzzer (Optional) In additional to standard BMC functionalities, BMC firmware controls Front Panel LED and motherboard Buzzer for error warning and display. http://www.tyan.com...
- Page 24 TSO is a software tool created specifically for IPMI-compliant systems with SMDC. It intends to provide IT managers the ability to monitor, control and diagnose their Tyan server boards with ease and flexibility in a remote control configuration. Consult Tyan System Operator™...
-
Page 25: Smdc Features
When the window titled “COM1 Properties” appears, choose the following settings: Select 38400 for Bits per second Select 8 for Data bits Select None for Parity Select 1 for Stop bits Select None for Flow control Press OK http://www.tyan.com... - Page 26 Select Ctrl + H under “Backspace key sends” Select Auto detect for Emulation Type in ANSI for “Telnet terminal ID” Select 500 for Backscroll buffer lines Leave the box for “Play sound when connecting or disconnecting” unchecked Press OK http://www.tyan.com...
- Page 27 The ASCII Setup window will then appear. Uncheck the “Wrap lines that exceed terminal width” option. Enter 0 in the “Line delay” and “Character delay” options. (EMP continued on the next page) http://www.tyan.com...
- Page 28 Change from one menu to the next Up/Down Keys More between selections, go to submenu Enter Open highlighted section Go back to previous menu Note: Remember to use CTRL-L to refresh the terminal screen if there is a display problem. http://www.tyan.com...
- Page 29 Note: Please open flash.exe on the TSO CD and follow the directions on how to flash. The file extensions end with .mhx and .bin. http://www.tyan.com...
- Page 30 The table below is a key of the possible conditions that your system can be in. Status Description Lwer_N_Crtcl Below Lower Non-Critical Threshold Lwer_Crtcl Below Lower Critical Threshold Lwer_N_Rcvbl Below Lower Non-Recoverable Threshold Uper_N_Crtcl Above Upper Non-Critical Threshold Uper_Crtcl Above Upper Critical Threshold Uper_N_Rcvbl Above Upper Non-Recoverable Threshold O.K. Sensor is running within Thresholds http://www.tyan.com...
-
Page 31: Tyan System Operator (Tso)
4.6 TYAN System Operator™ (TSO) Summary TSO Summary General Features • Sensor Monitor Service • System Control and Diagnose Panel • System Up/Down/Power Cycle/NMI • FRU Browser • SDR Browser • SEL Browser • SNMP Architecture • Watchdog Timer Activation/Deactivation •... - Page 32 Appendix 1: Safety document of Tyan B2723T15/B2723T15M Notice for the USA Compliance Information Statement (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: This device may not cause harmful interference, and This device must accept any interference received including interference that may cause undesired operation.
- Page 33 Appendix2: Safety document of Tyan SMDC (Server Management Daughter Card) Notice for the USA Compliance Information Statement (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions:...
