  • Page 1 TN70E-B7106 Service Engineer’s Manual...
  • Page 2 TECHNOLOGY CORPORATION and has been reviewed for accuracy and reliability prior to printing. MITAC assumes no liability whatsoever, and disclaims any express ® or implied warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MITAC retains the right to make changes to produce descriptions and/or specifications at any time, without notice.
  • Page 3 FCC Declaration ● Notice for the USA Compliance Information Statement (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: ‧This device may not cause harmful interference.
  • Page 4 Warning This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. CAUTION Lithium battery included with this board. Do not puncture, mutilate, or dispose of battery in fire. There will be danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer.

  • Page 5: About This Manual

    How this guide is organized This guide contains the following parts: Chapter 1: Overview This chapter provides an introduction to the TYAN TN70E-B7106 barebones and standard parts list, describes the external components, gives an overview of the product from different angles.

  • Page 6: Safety And Compliance Information

    Safety and Compliance Information Before installing and using TYAN TN70E-B7106, take note of the following precautions: ·Read all instructions carefully. ·Do not place the unit on an unstable surface, cart, or stand. ·Do not block the slots and opening on the unit, which are provided for ventilation.

  • Page 7: Safety Information

    You must become familiar with the safety information in this guide before you install, operate, or service TYAN products. Symbols on Equipment Caution. This symbol indicates a potential hazard.
  • Page 8 · Make sure racks are coupled together if it is a multiple-rack installation. · Make sure the rack is level and stable before installing an appliance in the rack. · Make sure the leveling jacks are extended to the floor. http://www.tyan.com...
  • Page 9 · In all European electrical environments, you must ground the Green/Yellow tab on the power cord. If you do not ground the Green/Yellow tab, it can cause an electrical shock due to high leakage currents. http://www.tyan.com...
  • Page 10 TYAN, your authorized TYAN partner, or their agents. Equipment Modifications · Do not make mechanical modifications to the system. TYAN is not responsible for the regulatory compliance of TYAN equipment that has been modified.
  • Page 11 – Liquid has been spilled on the product or an object has fallen into the product. – The product has been exposed to rain or water. – The product has been dropped or damaged. – The product does not operate normally when you follow the operating instructions. http://www.tyan.com...

  • Page 12: Table Of Contents

    Table of Contents Chapter 1: Overview ................ 15 About the TYAN TN70E-B7106 ..........15 Product Model ................ 15 Features.................. 16 Standard Parts List ..............22 1.4.1 Box Contents ..............22 1.4.2 Accessories ..............22 About the Product ..............23 1.5.1 System Front View ............
  • Page 13 Appendix II: PCIE Slot Location and Setup Items Corresponding List ..................... 90 Appendix III: Cable Connection Tables ......... 92 Appendix IV: Fan and Temp Sensors ..........94 Appendix V: FRU Parts Table ............99 Appendix VI: Technical Support ........... 100 http://www.tyan.com...
  • Page 14 NOTE http://www.tyan.com...

  • Page 15: Chapter 1: Overview

    Leveraging advanced technology from ® Intel , TN70E-B7106 server system is capable of offering scalable 32 and 64-bit computing, high bandwidth memory design, providing a rich feature set and incredible performance, and lightning-fast PCI-E bus implementation. The TN70E-B7106 not only empowers your company in nowadays IT demand but also offers a smooth path for future application usage.

  • Page 16: Features

    Thermal Design Power Processor Max up to 205W (TDP) wattage Up to 10.4/9.6 GT/s with Intel UltraPath System Bus Interconnect (UPI) support Chipset Intel C621 Supported DIMM Qty (8)+(8) DIMM slots Memory DDR4 RDIMM/RDIMM DIMM Type / Speed 3DS/LRDIMM/LRDIMM 3DS 2666 http://www.tyan.com...
  • Page 17 (2) PCI-E Gen3 x8 slots PCI-E (1) PCI-E Gen3 x16 slots (w/ x8/x16 link) Expansion Note: The total power consumption of the Slots PCIe slots cannot exceed 150W Pre-install TYAN Riser M7106-L24-3F, M7106-R24-3F Card Port Q'ty (2) GbE ports, (1) PHY Controller Intel I210-AT...
  • Page 18 Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant Manual (1) Quick Installation Guide Package Installation CD (1) TYAN installation CD Contains Barebone (1) TN70E-B7106 Barebone B7106T70EV8E4HR Specifications Form Factor 2U Rackmount Chassis Model TN70E System 27.56" x 17.32" x 3.43" (700 x 440 x...
  • Page 19 Memory channel 6 Channels per CPU Memory voltage 1.2V (2) sets of the following expansion combination : Expansion PCI-E (2) PCI-E Gen3 x8 slots Slots (1) PCI-E Gen3 x16 slots (w/ x8/x16 link) Note: The total power consumption of the http://www.tyan.com...
  • Page 20 PCIe slots cannot exceed 150W Pre-install TYAN Riser M7106-L24-3F, M7106-R24-3F Card Port Q'ty (2) GbE ports, (1) PHY Controller Intel I210-AT Realtek RTL8211E (3) Mini-SAS HD (12-ports) + Connector (2) SATA-III (totally support 14 ports) Storage SATA Controller Intel C621 Speed 6.0 Gb/s...
  • Page 21 RoHS RoHS 6/6 Compliant Manual (1) Quick Installation Guide Package Installation CD (1) TYAN installation CD Contains Barebone (1) TN70E-B7106 Barebone NOTE: 1. The specifications are subject to change without prior notice. 2. Please visit our website for the latest specifications.

  • Page 22: Standard Parts List

    Standard Parts List This section describes TN70E-B7106 package contents and accessories. Open the box carefully and ensure that all components are present and undamaged. The product should arrive with packaged as illustrated below. 1.4.1 Box Contents If any items are missing or appear damaged, contact your retailer or browse to TYAN’s website for service:...

  • Page 23: About The Product

    The following views show you the product. 1.5.1 System Front View M1701T70-FPB Front Panel Board Power Button with green LED ID Button IPMI LED USB 2.0 Port ID LED USB 2.0 Port RESET Button 3.5” /2.5” SSD/ HDD bays http://www.tyan.com...
  • Page 24 Chassis Locate LED ID LED key.* System not identified HDD LED State Color Description Solid On Drive present, no activity Activity LED Green Blinking Drive present, with activity Solid On HDD Failed Status LED Blinking @1Hz Identify Blinking @4Hz Rebuild http://www.tyan.com...

  • Page 25: System Rear View

    ID LED will light blue if the system is identified. Users from remote sites can also activate the ID LED by entering a few commands in IPMI. For detailed software support, please visit http://www.tyan.com for the latest AST2500 user guide.
  • Page 26 The chart below illustrates the different LED states. 10/100/1000 Mbps LAN Link/Activity LED Scheme Left LED Right LED Link Green 10 Mbps Active Blinking Green Link Green Green 100 Mbps Active Blinking Green Green Link Green Amber 1000 Mbps Active Blinking Green Amber No Link http://www.tyan.com...

  • Page 27: System Top View

    1.5.3 System Top View (12) Hot-swap 3.5’/2.5’ HDD trays M1290T70E-BP12E-12 HDD Backplane Board (8) System fans M1601T70E-D-PDB Power Distribution Board DELTA, DPS 770GB C 770W Power Supply (2) Hot-swap 2.5” SSD trays http://www.tyan.com...
  • Page 28 Riser Card Bracket (M7106-L24-3F, M7106-R24-3F pre-installed) CPU Sockets Memory Slots Expansion Slots http://www.tyan.com...

  • Page 29: Chapter 2: Setting Up

    Caution! To avoid damaging the motherboard and associated components, use torque force within the range kgf/cm (6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com...

  • Page 30: Precautions

    Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to TN70E-B7106 or injury to yourself.  Ground yourself properly before removing the top cover of the system.

  • Page 31: Installing Motherboard Components

    CPUs, memory modules and add on cards. 2.1.1 Removing the Chassis Cover Follow these instructions to remove TN70E-B7106 chassis cover. 1. Remove the screw on the left side, and unscrew the rear top cover on the back side. Slide to lift the rear top cover up.

  • Page 32: Installing The Cpu And Heatsink

    Installing the CPU and Heatsink Follow the steps below on installing CPUs and CPU heatsinks. TN70E-B7106 has two CPU sockets. Align and install the processor on the carrier. Carefully flip the heatsink. Then install the carrier assembly on the bottom of the heatsink and make sure the gold arrow is located in the correct direction.
  • Page 33 Take out the protection cap. Align the heatsink on the CPU socket by the guide pins and make sure the gold arrow is located in the correct direction. Then place the heatsink onto the top of the CPU socket. http://www.tyan.com...
  • Page 34 To secure the heatsink, use a T30 Security Torx to tighten the screws in a sequential order (1 2  3  4). When disassembling the heatsink, loosen the screws in reverse order (4  3  2  1). http://www.tyan.com...

  • Page 35: Installing The Pci-E Card

    2.1.3 Installing the PCI-E Card Follow these instructions to install the PCI-E card. 1. Unscrew the riser card bracket. 2. Remove the riser card bracket from the chassis. http://www.tyan.com...
  • Page 36 3. Unscrew to remove the dummy brackets. 4. Insert the PCI-E card into the riser card bracket and screw it firmly. Follow the same procedures to insert the card to the other side of the riser card bracket if necessary. http://www.tyan.com...
  • Page 37 5. The same procedure to install the PCIE card to the second riser card. 6. Reposition and screw the riser card bracket into the chassis. http://www.tyan.com...

  • Page 38: Installing The Memory

    Align the memory module with the slot. When inserted properly, the memory slot locking levers lock automatically onto the indentations at the ends of the module. Follow the recommended memory population table to install the other memory modules. http://www.tyan.com...
  • Page 39 Memory Population http://www.tyan.com...

  • Page 40: Installing Hard Drives

    2.1.5 Installing Hard Drives The TN70E-B7106 supports twelve 3.5”/2.5” hot-swap HDD/SSDs and two 2.5” hot-swap SSDs. Installing 3.5” Hot-Swap Hard Drives Follow these instructions to install a 3.5” HDD. Warning!!! Always install the hard disk drive to the chassis after the chassis has been secured on the rack.
  • Page 41 Place the 3.5” hard disk drive into the HDD tray and secure the HDD to the HDD tray using 4 screws. Reinsert the HDD tray into the chassis. Push to secure the locking lever until it clicks into place. http://www.tyan.com...
  • Page 42 Follow these instructions to install a 2.5” HDD/SSD. Warning!!! Always install the hard disk drive to the chassis after the chassis has been secured on the rack. Press the locking lever latch and pull the locking lever open. Slide the HDD tray out. http://www.tyan.com...
  • Page 43 Place the 2.5” HDD/SSD into the HDD tray and align the 2.5” HDD/SSD with its guide pins. Turn over the HDD tray and secure the HDD/SSD to the tray using 4 screws. http://www.tyan.com...
  • Page 44 Reinsert the HDD tray into the chassis. Push to secure the locking lever until it clicks into place. http://www.tyan.com...
  • Page 45 Always install the hard disk drive to the chassis after the chassis has been secured on the rack. Press the locking lever latch and pull the locking lever open. Remove the 4 screws to detach HDD tray bracket. Secure one side HDD screws. http://www.tyan.com...
  • Page 46 Secure the other side HDD screws. Reinsert the HDD tray into the chassis. Push to secure the locking lever until it clicks into place. http://www.tyan.com...

  • Page 47: Rack Mounting

    19" rack. NOTE: Before mounting the TYAN TN70E-B7106 in a rack, ensure that all internal components have been installed and that the unit has been fully tested. However, to make the installation easier, we suggest that you remove all HDD trays before you insert the chassis into the rack.
  • Page 48 Draw out the inner rail from the rail assembly. When the rail comes to a stop pull the tab to release the latch and completely draw the inner rail out. Align the inner sliding rail on the side of the server, and pull towards the arrow to secure the hooks http://www.tyan.com...
  • Page 49 Repeat steps 2 to 4 to secure the sliding rail to the other side of the server. Installing the Outer Rails to the Unit Secure the outer rails to the rack using four M5 screws and four washers (A) on each side. Rack Mounting the Server Draw out the middle rail to the latch position. http://www.tyan.com...
  • Page 50 When the inner rails come to a stop, pull the tab to release the latch and push the whole system in. Secure the mounting ears of the unit to the rack using two M5 x 20L screws (C). http://www.tyan.com...
  • Page 51 NOTE http://www.tyan.com...

  • Page 52: Chapter 3: Replacing Pre-Installed Components

    This chapter explains how to replace the pre-installed components, including the Motherboard, M1713-G24-FPB Front Panel Board, M1283G24-BP12E-4 Backplane, M1601T70-D-PDB Power Distribution board, M7106-L24-3F M7106-R24-3F Riser cards, System fan and Power supply unit etc. Disassembly Flowchart The following flowchart outlines the disassembly procedure. http://www.tyan.com...

  • Page 53: Removing The Cover

    Removing the Cover Before replacing any parts you must remove the chassis cover first. Follow Chapter 2.1.1 to remove the cover of the TN70E-B7106. Replacing Motherboard Components Follow these instructions to replace motherboard components, including the motherboard. 3.4.1 Disconnecting All Motherboard Cables Disconnect all cables connected to the motherboard.

  • Page 54: Replacing The Riser Card

    3.4.2 Replacing the Riser Card Follow these instructions to replace the M7106-L24-3F M7106-R24-3F Riser cards. Unscrew the riser card bracket. Remove the riser card bracket from the chassis. http://www.tyan.com...
  • Page 55 Unscrew the M7016-L24-3F riser card to replace with a new one. Unscrew the M7016-R24-3F riser card to replace with a new one. Follow the steps described earlier in reverse to reinstall the riser card bracket. http://www.tyan.com...

  • Page 56: Pci-E Riser Cards Specification

    3.4.3 PCI-E Riser Cards Specification M7106-L24-3F Riser Card 3.4.4 Connector Pin Definition (M7106-L24-3F) Location Definition PCIe X16 SLOT 4P Power Connector PCIe X8 SLOT PCIe X8 SLOT http://www.tyan.com...

  • Page 57: Connector Pin Definition (M7106-R24-3F)

    M7106-R24-3F Riser Card 3.4.5 Connector Pin Definition (M7106-R24-3F) Location Definition PCIe X8 SLOT 4Pin Power Connector PCIe X16 SLOT PCIe X8 SLOT Signal Signal J2 (PWR1) +12V http://www.tyan.com...

  • Page 58: Removing The Motherboard

    After removing all of the aforementioned cables, follow the instructions below to remove the motherboard from the chassis. Remove the air duct, processor and heatsink if installed. Remove nine screws securing the motherboard to the chassis. Carefully lift the motherboard from the chassis. http://www.tyan.com...

  • Page 59: Replacing The Front Panel Board

    Replacing the Front Panel Board Follow these instructions to replace the M1701T70-FP Front Panel Board. 1 Unscrew to release the Front Panel Board cover. 2 Remove the Front Panel Board cover. http://www.tyan.com...
  • Page 60 3 Unscrew the Front Panel Board to replace a new one. 4 Disconnect the Front Panel Board to replace a new one. 5 Follow the steps described earlier in reverse to reinstall the Front Panel Board. http://www.tyan.com...

  • Page 61: Front Panel Board Specifications

    Power On/Off LED Color: Green (after power on)  ID LED Color: Blue LEDs  Warning (IPMI) LED Dual Color: Amber (Warning) / Green (Normal)  RESET button  Push buttons ID button  Power On/Off button with Power On/Off LED http://www.tyan.com...

  • Page 62: Fpb Led And Connector Pin Definition

    Chassis ID LED Locate LED key.* System not identified J1: FPIO connector Definition Definition PW_LED+ +5VSB ID_LED+ PW_LED- ID_LED- HD_LED+ LED_FAULT1- HD_LED- LED_FAULT2- PWR_SW+ LAN_ACT PWR_SW- LAN_LINK# RESET+ SMB_DAT RESET- SMB_CLK ID_SW- Temp_sensor SMB_ALR FPB_HDD_ACTIVITY_G- SMB_CLK FPB_HDD_FAULT_R- SMB_DAT http://www.tyan.com...

  • Page 63: Replacing The Usb Board

    Replacing the USB Board Follow these instructions to replace the M1702T70-USB Board. 1 Unscrew to release the USB front cover. 2 Remove the USB front cover. http://www.tyan.com...
  • Page 64 3 Unscrew the USB Board. 4 Disconnect the USB Board to replace a new one. 5 Follow the steps described earlier in reverse to reinstall the USB Board. http://www.tyan.com...

  • Page 65: Usb Board Specifications

    USB Board Connector Pin Definition J2: 2x5-pin Connector for FP Connector of Motherboard Definition Description Definition Description VCC_USB USB power VCC_USB USB power USB_P0_N Port1(J1) USB- USB_P1_N Port2(J3) USB- USB_P0_P Port1(J1) USB+ USB_P1_P Port2(J3) USB+ GND1 Ground GND2 Ground No connect http://www.tyan.com...

  • Page 66: Replacing The System Fan

    Replacing the System Fan Follow these instructions to replace the fan. Disconnect the power cable. Press the button to take out the fan from the chassis. http://www.tyan.com...
  • Page 67 Release the rubber screws from the fan. 1 Loose the screws on both sides. 2 Push the latch in the direction as the arrow shown to release the fan from the iron holder. http://www.tyan.com...
  • Page 68 3 Remove the iron holder to replace a new fan. 4 After replacing a new one, put the fan unit back into the cage. http://www.tyan.com...

  • Page 69: Replacing The Fan Backplane Board

    Replacing the Fan Backplane Board Follow these instructions to replace the M1806G70-FB Fan Board in your system. 1. Disconnect all the fan power cable. Use a screw driver to unscrew the fan cage. http://www.tyan.com...
  • Page 70 And lift it up from the chassis. Release the 14 screws on the Fan Backplane Board to replace a new one. Follow the steps described in reverse order to reinstall the fan cage. http://www.tyan.com...

  • Page 71: Fan Bp Board Specifications

    (2) 1x4pin R/A Power Connector  (8) 2x2pin Fan Connectors Integrated I/O  (1) 2x10pin Barebone Fan Connector  (1) 2x2pin Connector for S7086 3.8.2 Fan BP Board LED Definitions FAN Status Green LED(Right) Red LED(Left) With Fan Without Fan http://www.tyan.com...

  • Page 72: Connector Pin Definitions

    3.8.3 Connector Pin Definitions Power Connector (PWR1/PWR2) Definition Definition +12V Barebone Fan Connector (J8) Definition Definition FANIN1 FANIN6 FANIN2 FANIN7 FANIN3 FANIN8 FANIN4 SIO_FANIN1 FANIN5 SIO_ FANIN2 MB_PWM2 MB_PWM1 SIO_ FANIN3 SMBUS_3V3_DATA SIO_ FANIN4 SMBUS_3V3_CLK VDD_3.3_AUX MB_PWM3 http://www.tyan.com...

  • Page 73: Replacing The Hdd Backplane Board

    Before detach the HDD backplane, please remove all the HDD trays with HDDs, otherwise the HDD backplane will be damage when strains at the disassembly. Disconnect all cables connected to the M1290T70E-BP12E-12 Backplane. Remove the fan cage. Unscrew the HDD BP Board. http://www.tyan.com...
  • Page 74 Lift up the HDD Backplane bracket. The HDD BP Board bracket is as shown below. Unscrew the backplane and replace with a new HDD backplane board. Follow the procedures described earlier to reinstall the HDD backplane board bracket into the chassis. http://www.tyan.com...

  • Page 75: Hdd Backplane Board Features

    3.9.1 HDD Backplane Board Features Front View Rear View Form Factor Dimension: 422.4*29.8mm 2 OCU Link Connector Input Specifications 3 Mini SAS HD Connector Input Overview 12 SATA HDD or 8 SATA HDD + 4 NVMe Output http://www.tyan.com...

  • Page 76: Connector Definition

    SATA Connector HDD7 SATA Connector HDD8 SATA Connector HDD9 SATA Connector HDD10 SATA Connector HDD11 SATA Connector SATA0_3 Mini SAS HD Connector SATA4_7 Mini SAS HD Connector SATA8_11 Mini SAS HD Connector NVME01 OCULink Connector NVME23 OCULink Connector Power Connector http://www.tyan.com...

  • Page 77: Replacing The Power Distribution Board

    Power Distribution Board in your system. Disconnect all cables connected to the power distribution board. Unscrew to take off the power distribution board and replace with a new one. Insert the PDB into the chassis following the above procedures in reverse. http://www.tyan.com...

  • Page 78: Replacing The Rear Hdd Backplane Board

    3.11 Replacing the Rear HDD Backplane Board Follow the instructions to replace the M1287G88-BP12-2 HDD backplane Board Disconnect all cables and unscrew the power distribution board. http://www.tyan.com...

  • Page 79: Hdd Backplane Features

    HDD Backplane Features Front View Rear View  PCB Dimensions: 93*36*2mm  Layer: 4 layers  (2) SATA Connectors  (1) JTAG Jumper(J1)  Integrated I/O (1) SGPIO Connector(J2)  (2) 7-pin SATA connector  (1) 4 Pin Power connector http://www.tyan.com...

  • Page 80: Connector Definition

    HDD0: HDD Connector Definition Definition SAS_TX0+ SAS_TX0- SAS_RXBN0 SAS_RXBP0 SAS0_PRESENT_L HD0_V5 VDD_5_RUN VDD_5_RUN HD0_PRS_L SAS0_LED HD0_V12HD VDD_5_RUN VDD_5_RUN GND1 GND2 HDD1: HDD Connector Definition Definition SAS_TX1+ SAS_TX1- SAS_RXBN1 SAS_RXBP1 SAS0_PRESENT_L HD1_V5 VDD_5_RUN VDD_5_RUN HD1_PRS_L SAS1_LED HD1_V12HD VDD_5_RUN VDD_5_RUN GND1 GND2 http://www.tyan.com...
  • Page 81 SAS_RXBP0 SATA1: SATA Connector Definition Definition SAS_TX1+ SAS_TX1- SAS_RXBN1 SAS_RXBP1 J1: JTAG Connector Definition Definition CPLD_JTAG_TCK CPLD_JTAG_TDO VDD_3P3_RUN CPLD_JTAG_TMS CPLD_JTAG_TDI J2: SGPIO Connector Definition Definition SMBUS_3V3_CLK SAS_SIO_DIN_A SMBUS_3V3_DATA SAS_SIO_DOUT_A SAS_SIO_END_A SAS_SIO_CLK_A VCC3_AUX PW1: Power Connector Definition Definition VDD_12_RUN VDD_5_RUN http://www.tyan.com...

  • Page 82: Replacing The Power Supply

    Follow these instructions to replace the power supply module in your system. Press the latch to pull the power supply out. After replacing a new power supply, press and hold the latch to push the power supply back into the chassis. http://www.tyan.com...
  • Page 83 NOTE http://www.tyan.com...

  • Page 84: Appendix I: Installing Io Plate For Ocp Card

    Appendix I: Installing IO Plate for OCP Card Follow these instructions to install the IO Plate for OCP Card. Here shows how to install the IO Plate for the dual-port LAN card M7062-I599-2T. Unscrew the riser card bracket. Remove the riser card bracket from the chassis. http://www.tyan.com...
  • Page 85 4. Take out the IO plate for LAN card. Use a screwdriver to break the LAN port’s semi shearing. Break one semi-shearing if a single-port LAN card is installed. Break both for a dual-port LAN card. http://www.tyan.com...
  • Page 86 5. Insert the IO Plate to the OCP card LAN port. 6. Screw the IO Plate to the chassis http://www.tyan.com...
  • Page 87 7. Insert the LAN card into the OCP slot 8. Secure the LAN card to the chassis http://www.tyan.com...

  • Page 88: Appendix I: How To Recover Uefi Bios

    UEFI recovery bootloader that would prevent the recovery process itself from working. In no event shall Tyan be liable for direct, indirect, incidental, special or consequential damages arising from the BIOS update or recovery.
  • Page 89 “Flash update completed. Press any key to reset the system” displayed on screen. Remove the USB disk and reboot. If your system does not have video output or the POST code halts at “FF” on the right-lower portion of the screen, please contact Tyan representatives for RMA service. http://www.tyan.com...

  • Page 90: Appendix Ii: Pcie Slot Location And Setup Items Corresponding List

    Connectors Socket1 IOU0(IIO 1A1B E.PCIE M7106-L24-3F(do Motherboar Configuration PCIe Br1) Socket1 IOU1 (IIO 2C2D D.PCIE M7106-R24-3F(up) Component Configuration PCIe Br2) Socket1 IOU1 (IIO 2A2B2C D.PCIE M7106-R24-3F(mid Configuration PCIe Br2) dle) Socket1 IOU0 (IIO 1C1D D.PCIE M7106-R24-3F(do Configuration PCIe Br1) http://www.tyan.com...
  • Page 91 3A3B3C3D E.PCIE M7106-L16-1F chapter 2.4 Configuration PCIe Br1) Board Parts, Socket1 IOU1(IIO 2A2B2C2D D.PCIE M7106-R16-1F Jumpers and Configuration PCIe Br2) Connectors Motherboard Components PCIe x16 FH/HL cards (In Left and Right 1U riser cards) M7106-L16-1F (Sold separately) M7106-R16-1F (Sold separately) http://www.tyan.com...

  • Page 92: Appendix Iii: Cable Connection Tables

    S7106 MB M1701T70-FPB  FPIO_1 Front Panel USB Cable Front Panel Connect to S7106MB M1702T70-USB  USB3_FPIO1 Power Supply Cables M1601T70-D-PDB Connect to S7106 MB  PW1 (MB) PWR1  PATX1 (MB1)  PATX2 (MB2)  J7 (PSMI) PSMI_HD1 http://www.tyan.com...
  • Page 93 SATA HDD Cable M1287G88-BP12-2-1 S7106 MB Connect to Rear HDD BP  SSATA0 SSATA0  SSATA1 SSATA1 SGPIO Cable M1287G88-BP12-2-1 S7106 MB Connect to Rear HDD BP  SSATA_SGPIO1 Control Internal cable S7106 MB Connect to Chassis  J121 Chassis http://www.tyan.com...

  • Page 94: Appendix Iv: Fan And Temp Sensors

    (rpm) Temp Sensor: SYS_Air_Outlet (RT3) MB_Air_Inlet (RT2). They detect the system temperature around. NOTE: The system temperature is measured in a scale defined by Intel, not in Fahrenheit or Celsius. http://www.tyan.com...
  • Page 95 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
  • Page 96 http://www.tyan.com...
  • Page 97 Fan speed of SYS_FAN_2 SYS_FAN_3 Fan speed of SYS_FAN_3 SYS_FAN_4 Fan speed of SYS_FAN_4 SYS_FAN_5 Fan speed of SYS_FAN_5 SYS_FAN_6 Fan speed of SYS_FAN_6 SYS_FAN_7 Fan speed of SYS_FAN_7 SYS_FAN_8 Fan speed of SYS_FAN_8 SYS_FAN_9 Fan speed of SYS_FAN_9 http://www.tyan.com...
  • Page 98 SYS_FAN_10 Fan speed of SYS_FAN_10 SYS_FAN_11 Fan speed of SYS_FAN_11 SYS_FAN_12 Fan speed of SYS_FAN_12 http://www.tyan.com...

  • Page 99: Appendix V: Fru Parts Table

    M7106-L24-3F, PCIEx24 Riser card PCIE Riser Card FRU-RC-0500 5411T5640007 M7106-R24-3F, PCIEx24 Riser card HDD backplane HDD BP FRU-RC-0700 5411T5640016 FRU;M1290T70E-BP12E-12; for TN70E-B7106; Single Box; RoHS Rack CRAL-0170 340786900010 SLIDE RAIL MIC ASSY Mounting TF-POWER CORD;SBU,US,125 V,16 FRU-CS-0330 332810000514 AWG(1.31mm²),1800mm,AC PWR CORD...

  • Page 100: Appendix Vi: Technical Support

    MITAC serves multiple market segments with the industry’s most competitive services to support them. TYAN's tech support is some of the most impressive we've seen, with great response time and exceptional organization in general.” — Anandtech.com Please feel free to contact us directly for this service at tech-support@tyan.com...
  • Page 101 Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. ® TN70E-B7106 Service Engineer’s Manual V1.0b...
