Radio CD MP3 WMA
Orlando MP46
7 646 480 310
Operating instructions
http://www.blaupunkt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Orlando MP46 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blaupunkt Orlando MP46

  • Page 1 Radio CD MP3 WMA Orlando MP46 7 646 480 310 Operating instructions http://www.blaupunkt.com...
  • Page 3: Arrow Buttons

    Controls 1 On/Off button 8 DISPL button Short press: Mutes the device. Short press: Briefl y displays alternative Long press: Switches the device off. display contents (e.g. time). Long press: Changes display contents. button to open the fl ip-release con- trol panel.
  • Page 4: Table Of Contents

    Contents Notes and accessories ...... 43 Traffi c information ......55 Disposal of old unit Switching traffi c information (EU countries only) ......43 priority on/off ....... 55 Installation ........43 Setting the volume for traffi c Optional equipment(not part of announcements ......
  • Page 5 Contents CD changer mode ......65 Adjusting the display settings ... 71 Switching to CD changer mode ..65 Entering a switch-on message ..71 Selecting CDs ........ 65 Adjusting the display brightness ..72 Selecting tracks ......65 Adjusting the viewing angle ..... 72 Fast seek tuning (audible) ....
  • Page 6: Notes And Accessories

    You cannot switch the device on/off using tems available to dispose of the old unit. the remote control. You can fi nd out from your Blaupunkt dealer or on the Internet at www.blaupunkt.com which remote controls can be used with...
  • Page 7: Detachable Control Panel

    Notes and accessories Control panel Amplifi er Detachable control panel You can use all Blaupunkt and Velocity am- plifi ers. Theft protection The device is equipped with a detachable CD changers control panel (fl ip-release panel) as a way You can connect the following Blaupunkt of protecting your equipment against theft.
  • Page 8: Attaching The Control Panel

    Control panel Notes: Switch-off time (OFF TIMER) • The device is switched off after a time After opening the control panel, the device preset by you. For further details, is switched off after an adjustable time. You please read the section "Switch-off can set this time from 0 to 30 seconds.
  • Page 9: Switching On/Off

    Switching on/off Volume Switching on/off Adjusting the volume There are various ways of switching the de- You can adjust the volume in increments vice on/off: from 0 (off) to 66 (maximum). To increase the volume, Switching on/off using button 1 turn the volume control 3 clockwise.
  • Page 10: Quickly Reducing The Volume (Mute)

    "MUTE" appears on the display. scribed in the installation instructions. Cancelling mute You can fi nd out from your Blaupunkt dealer To return to your previously set volume which navigation systems can be used with level, your car sound system.
  • Page 11: Switching The Confi Rmation Beep On/Off

    Volume Press the MENU button 9. Switch the BEEP ON or OFF with the or button :. button : repeatedly Press the until "VOLUME MENU" appears on the When you have fi nished making your chang- display. button : to open the press the MENU button twice 9.
  • Page 12: Radio Mode

    Radio mode To save the setting, Radio mode switch the device off and on again or This device is equipped with an RDS radio wait approx. 8 seconds. The radio receiver. Many of the receivable FM stations starts playing with the last setting se- broadcast a signal that not only carries the lected (radio, CD, CD changer or AUX).
  • Page 13: Selecting The Waveband/Memory Bank

    Radio mode Six stations can be stored in each memory Switching REGIONAL on/off bank. Press the MENU button 9. To switch between the FM memory banks "USER MENU" appears on the display. (FM1, FM2 and FMT) and the MW and LW button : repeat- Press the wavebands,...
  • Page 14: Setting The Sensitivity Of Station Seek Tuning

    Radio mode LO1" means it is set to the lowest sensitiv- Browsing through broadcasting ity setting. networks (FM only) If a radio station provides several programmes, Set the desired sensitivity with the you have the option of browsing through its or button :.
  • Page 15: Listening To Stored Stations

    Radio mode The storing procedure begins. "FM Setting the scanning time TRAVELSTORE" appears on the display. Press the MENU button 9. After the process has completed, the radio button : repeatedly Press the will play the station that is stored in memory until "VARIOUS MENU"...
  • Page 16 Radio mode When you have fi nished making your chang- PTY-EON If you specify the programme type and start seek tuning, the radio will switch from the press the MENU button twice 9. current station to a station of the selected programme type.
  • Page 17: Optimising Radio Reception

    Radio mode button : repeatedly The selected programme type appears Press the briefl y on the display. until "HICUT" appears on the display. button : to start button : to switch Press the Press the seek tuning. High Cut on or off. The radio will then tune into the next station "HICUT OFF"...
  • Page 18: Traffi C Information

    Traffi c information Traffi c information Setting the volume for traffi c announcements Your device is equipped with an RDS-EON Press the MENU button 9. receiving unit. EON (Enhanced Other Network) ensures that whenever a traffi c button : repeatedly Press the announcement (TA) is broadcast, the sys- until "VOLUME MENU"...
  • Page 19: Cd Mode

    Playback begins from the point at which it with the Compact-Disc logo. Copy-pro- was last interrupted. tected CDs can cause playback problems. Blaupunkt cannot guarantee the proper Selecting tracks functioning of copy-protected CDs! Press one of the arrow buttons : to Besides being able to play audio CDs on this select the next or previous track.
  • Page 20: Fast Seek Tuning (Audible)

    CD mode Fast seek tuning (audible) Cancelling Scan and continuing listening to a track To fast seek tuning backwards or forwards, To end the scanning process, press and hold down the or button press the MENU button 9. : until fast seek tuning backwards / forwards begins.
  • Page 21: Confi Guring The Display

    CD mode Confi guring the display Switching CD text on/off Press the MENU button 9. You can choose from various display op- button : repeatedly Press the tions in CD mode: until "VARIOUS MENU" appears on the • "Normal Mode": display.
  • Page 22: Ejecting A Cd

    CD mode MP3/WMA mode Ejecting a CD MP3/WMA mode button 2. Press the You can also use this car sound system to play CD-Rs and CD-RWs that contain MP3 The control panel opens out towards you. music fi les. You can also play WMA fi les. <...
  • Page 23 MP3/WMA mode This device supports as many subdirecto- If you like your fi les to be in the correct or- ries as your burner software can create de- der, you should use burner software that spite the fact that the maximum directory places fi...
  • Page 24: Switching To Mp3 Mode

    MP3/WMA mode 4. MP3-Browse-Mode: Switching to MP3 mode First line: Track name 1 MP3 mode is activated in the same way as Second line: Track name 2 normal CD mode. For further details, please Third line: Track name 3 read the section entitled "Switching to CD mode"...
  • Page 25: Selecting A Directory

    MP3/WMA mode To switch between the different display op- Note: tions, The device will automatically skip any press the MENU button 9. directories that do not contain MP3 fi les. The device will automatically cor- button : repeatedly Press the rect the number of directories for the until "VARIOUS MENU"...
  • Page 26: Selecting Tracks/Fi Les

    MP3/WMA mode Selecting tracks/fi les Random track play – MIX (not in MP3 browse mode) Selecting tracks/fi les using the arrow To play the tracks in the current directory in buttons (Normal, Clock and Info mode) random order, To move up or down to another track/fi le in briefl...
  • Page 27: Repeating Individual Tracks Or Whole Directories - Repeat (Not In Mp3 Browse Mode)

    MP3/WMA mode Note: Interrupting playback (PAUSE) You can set the scanning time. For fur- button ;. Press the 3 ther information on setting the scan- "PAUSE DISC" appears on the display. ning time, please read the section en- titled "Setting the scanning time" in the Cancelling pause "Radio mode"...
  • Page 28: Cd Changer Mode

    CD changer mode CD changer mode Repeating individual tracks or whole CDs (REPEAT) Note: To repeat the current track, Information on handling CDs, inserting briefl y press the 4 RPT button ;. CDs and operating the CD changer can be found in the operating instructions "REPEAT TRACK"...
  • Page 29: Scanning All Tracks On All Cds (Scan)

    CD changer mode Clock time Cancelling MIX Clock time Briefl y press the 5 MIX button ;. Displaying the time "MIX OFF" appears and MIX on the display disappears. To briefl y display the time, button 8 for long- press the DISPL Scanning all tracks on all CDs er than two seconds.
  • Page 30: Selecting 12/24-Hour Clock Mode

    Clock time When you have fi nished making your chang- Selecting 12/24-hour clock mode press the MENU button twice 9. Press the MENU button 9. button : repeat- Press the Briefl y displaying time with edly until "CLOCK MENU" appears on switched-off device the display.
  • Page 31: Sound

    Sound Sound Adjusting the middle You can select 1 of 4 centre frequencies You can perform the sound settings (bass, (500 Hz, 1 kHz, 2 kHz, 3 kHz). In addition, middle, treble and sub-out) separately for you can adjust the level between ±7 for the every source (radio, CD, CD changer, AUX, selected centre frequency.
  • Page 32: Setting The Left/Right Volume Distribution (Balance)

    Sound Preamplifi er output or button : repeatedly Preamplifi er output Press the until the desired centre frequency ap- (Preamp-Out/Sub-Out) pears on the display. You can use the preamplifi er outputs button : to adjust Press the (Preamp-Out) of the car sound system to the level between ±7.
  • Page 33: X-Bass

    Preamplifi er output X-Bass button : repeat- X-BASS Press the edly until "SUBOUT" appears on the X-Bass allows you to increase the bass at display. low volume. button : once. Press the The selected X-Bass setting is effective for or button : repeatedly Press the all audio sources (radio, CD, CD changer or until the desired frequency appears on...
  • Page 34: Equalizer Presettings (Presets)

    If you switch on the device, a brief mes- grammed. sage is shown on the display. The text "BLAUPUNKT" is preset at the factory. To select an equalizer setting, Instead, you can enter your own text of up press the AUDIO button 5.
  • Page 35: Adjusting The Display Brightness

    Display To enable "AUTO DIM", Adjusting the display brightness button : repeat- press the If your car sound system is installed as edly until "DIM NIGHT" appears on the described in the installation instructions display. and your vehicle features the correspond- ing connection, the display brightness is button : until "AUTO Press the...
  • Page 36: Adjusting A Positive Or Negative Display Presentation

    Display Press the MENU button 9. Adjusting a positive or negative display presentation button : repeatedly Press the until "DISPLAY MENU" appears on the You can adjust whether the display con- display. tents should be displayed in the positive or button : to open the negative mode.
  • Page 37: External Audio Sources

    You can obtain this cable (Blaupunkt no.: 7 607 897 093) from your Blaupunkt dealer. press the MENU button 9 once. The AUX input must be activated in the To start the seek tuning again, menu.
  • Page 38: Adjusting The Aux Preamplifi Cation

    AUX input for connecting Blaupunkt navigation sys- can be adjusted in 4 increments (0 to 3). tems. You can fi nd out from your Blaupunkt Press the MENU button 9. dealer which navigation systems can be used with your car sound system.
  • Page 39: Technical Data

    Technical data Technical data Amplifi er Output power: 4 x 18 watts sine at 14.4 V and 1% distortion factor at 4 ohms. 4 x 26 watts sine in accordance with DIN 45324 at 14.4 V at 4 ohms. 4 x 50 watts max. power Tuner Wavebands:...
  • Page 40 Bitte den ausgefüllten Gerätepass sicher aufbewahren! Please keep the fi lled-in radio pass in a safe place! Prière de conserver soigneusement la carte d’autoradio remplie ! Tenete per favore il libretto di apparecchio, debitamente riempito, in un posto sicuro! Bewaar de ingevulde apparaatpas op een veilige plaats! Vänligen förvara ifyllt apparatpass på...
  • Page 41 (MAL) +604-6382 474 +604-6413 640 Gerätepass Orlando MP46 Name: ..............7 646 480 310 Typ: ..............Serien-Nr: BP ..............Blaupunkt GmbH, Robert-Bosch-Straße 200, D-31139 Hildesheim 02/06 - CM-AS/SCS1 (dt, gb, fr, it, nl, sw, es, pt, dk, pl, cz, sk) 8622404852...
