- Page 1 Radio / CD / MP3 Modena MP54 Sevilla MP54 Operating instructions 7 644 260 310 7 644 262 310 http://www.blaupunkt.com...
- Page 2 Bitte aufklappen Open here Ouvrir s.v.p. Aprite la pagina Hier openslaan a.u.b. Öppna här Por favor, abrir Favor abrir Åbn her...
- Page 4 Button to switch the device on/ off and operate the volume mute feature. button for opening the de- tachable control panel (flip-re- lease panel). RDS button to switch the RDS function on/off (Radio Data Sys- tem). BND button (Band) to switch to radio mode, to select the FM memory banks and the MW and LW wave-...
-
Page 5: Table Of Contents
CONTENTS Notes and accessories ... 37 Detachable control panel ... 38 Switching on/off ... 39 Adjusting the volume ... 40 Radio mode ... 43 Adjusting the tuner settings ... 43 Switching to radio mode ... 43 Convenient RDS functions ... 43 Selecting the waveband / memory bank ... -
Page 6: Notes And Accessories
You cannot switch the device on/off us- ing the remote control. Amplifiers You can use all Blaupunkt and Velocity amplifiers. CD changers You can connect the following Blaupunkt CD changers: CDC A 08, IDC A 09 and CDC A 03. -
Page 7: Detachable Control Panel
DETACHABLE CONTROL PANEL Detachable control panel (flip-release panel) Theft protection The device is equipped with a detacha- ble control panel (flip-release panel) as a way of protecting your equipment against theft. The device is worthless to a thief without this control panel. Protect your device against theft by tak- ing the control panel with you whenev- er you leave your vehicle. -
Page 8: Switching On/Off
CONTROL PANEL Note: When attaching the control panel, make sure you do not press the display. If the device was still switched on when you removed the control panel, it will automatically switch on with the last settings activated (i.e. radio, CD/MP3, CD changer or AUX) when the panel is replaced. -
Page 9: Adjusting The Volume
SWITCHING ON/OFF Switching on by inserting a CD If the device is switched off and there is no CD present in the drive, button 2. press the The flip-release panel opens. Gently insert the CD with its printed side uppermost into the drive until you feel some resistance. - Page 10 You will need a cable for this with the following Blaupunkt number: 7 607 001 503. You can find out from your Blaupunkt dealer which navigation systems can be used with your car sound system. If the sound system receives a traffic...
- Page 11 ADJUSTING THE VOLUME button 7 repeat- Press the edly until “TEL/NAVI VOL” appears in the display. Set your preferred volume level us- buttons 7. ing the When you have finished making your changes, press the MENU button 9 twice or the OK button : twice.
-
Page 12: Radio Mode
Radio mode This device is equipped with an RDS radio receiver. Many of the receivable FM stations broadcast a signal that not only carries the programme but also additional information such as the sta- tion name and programme type (PTY). The station name appears in the dis- play as soon as the tuner receives it. -
Page 13: Selecting The Waveband / Memory Bank
RADIO MODE Switching REGIONAL on/off Press the MENU button 9. button 7 repeat- Press the edly until “REGIONAL” appears in the display. “OFF” or “ON” is dis- played alongside “REGIONAL”. To switch REGIONAL on/off, press button 7. Press the MENU button 9 or the OK button :. -
Page 14: Setting The Sensitivity Of Station Seek Tuning
Setting the sensitivity of station seek tuning You can choose whether the radio should only tune into stations providing good reception or whether it can also tune into those with a weak reception. Press the MENU button 9. button 7 repeat- Press the edly until “SENS”... -
Page 15: Listening To Stored Stations
RADIO MODE Listening to stored stations Select the memory bank or wave- band. Press the station button 1 - 3 6 or 4 - 6 ; that the station you want to listen to is assigned to. Scanning receivable stations (SCAN) You can use the scan function to briefly play all the receivable stations. - Page 16 If the tuned radio station or another station on the broadcasting net- work broadcasts your selected pro- gramme type at a later point in time, the radio will automatically switch from the currently tuned sta- tion or from CD/MP3 mode or CD- changer mode to the station whose programme type matches the one you selected.
-
Page 17: Optimising Radio Reception
RADIO MODE Optimising radio reception Treble reduction feature during interference (HICUT) The HICUT function improves reception during poor radio reception (only FM). If interference occurs, the system auto- matically reduces the treble thus reduc- ing the interference level. Switching HICUT on/off Press the MENU button 9. -
Page 18: Cd Mode
TRAFFIC INFORMATION If you hear the warning sound, you can either switch off traffic information pri- ority or tune into a station that broad- casts traffic information. Setting the volume for traffic announcements Press the MENU button 9. button 7 repeat- Press the edly until “TA VOLUME”... -
Page 19: Selecting Tracks
CD MODE Note: If the ignition was switched off be- fore you inserted the CD, you will first have to switch on the device by pressing button 1 in order to start playing the CD. If a CD is already inserted in the drive, press the SRC button @ repeated- ly until “CD”... -
Page 20: Repeating Tracks (Repeat)
Repeating tracks (REPEAT) If you want to repeat a track, press the 5 RPT button ;. “REPEAT TRACK” appears briefly in the display and the RPT symbol lights up. The track is repeated continuously until you deactivate RPT. Cancelling REPEAT If you want to deactivate the repeat func- tion, press the 5 RPT button ;... -
Page 21: Naming Cds
CD MODE Naming CDs The car sound system allows you to assign names for up to 30 CDs so that you can recognise them more easily. The names can be up to eight charac- ters long. “CD NAME FULL” will appear in the dis- play if you try assigning more than 30 names. -
Page 22: Traffic Announcements In Cd Mode
CD MODE Traffic announcements in CD mode If you wish to receive traffic announce- ments in CD mode, press the TRAF button =. Traffic announcement priority is active when a traffic-jam symbol lights up in the display. For further details, read the chapter entitled “Traffic information re- ception”. - Page 23 MP3 MODE This device supports as many subdirec- tories as your burner software can cre- ate despite the fact that the maximum directory depth defined by the ISO 9660 standard is only 8. T001 T002 T003 T004 T005 T001 T002 T003 T004 T005...
-
Page 24: Switching To Mp3 Mode
Do not use “mixed” CDs containing both non-MP3 data and MP3 tracks (the device will only read MP3 files during MP3 playback). Do not use mix-mode CDs contain- ing both CD-audio tracks and MP3 tracks. If you try playing a mix- mode CD, the device will only play the CD-audio tracks. -
Page 25: Scanning Tracks (Scan)
MP3 MODE Scanning tracks (SCAN) You can briefly play all the tracks on the Press and hold down the OK but- ton : for longer than two sec- onds. The next track will then be played briefly. “TRACK SCAN” appears in the display alongside the flashing track numbers. - Page 26 Configuring the MP3 scrolling text You can configure the device to display one of the following scrolling texts eve- ry time you change the track. The de- vice displays the scrolling text once. After the device has displayed the scroll- ing text it returns to the default display (see above).
-
Page 27: Cd-Changer Mode
CD-CHANGER MODE CD-changer mode Note: Information on handling CDs, in- serting CDs and operating the CD changer can be found in the oper- ating instructions supplied with your CD changer. Switching to CD-changer mode Press the SRC button @ repeat- edly until “CHANGER”... -
Page 28: Random Track Play (Mix)
Random track play (MIX) To play the tracks on the current CD in random order, briefly press the 4 MIX button ;. “MIX CD” appears briefly and MIX lights up in the display. To play the tracks on all inserted CDs in random order, press and hold down the 4 MIX button ;... -
Page 29: Clock - Time
CLOCK - TIME CLOCK - Time Briefly displaying the time You can make the time appear continu- ously in the bottom part of the display while any audio source is activated. For further information on this, read the rel- evant sections in the relevant chapters. Setting the clock time To set the clock time, press the MENU button 9. -
Page 30: Sound
Sound You can adjust the sound settings (bass and treble) separately for each source (radio, CD/MP3, CD changer, AUX, traf- fic announcement, telephone/naviga- tion). The volume distribution settings (balance and fader) apply to all the au- dio sources. Note: You can only adjust the audio set- tings for traffic announcements and the navigation system whilst a traf- fic announcement or navigation an-... -
Page 31: X-Bass
SOUND Equalizer presets This device is equipped with an equal- izer that has been preset with settings for the “ROCK”, “POP” and “CLASSIC” music styles. To select an equalizer preset, press the AUDIO button >. “BASS” appears in the display. button 7 repeatedly Press the until “EQ POP”, “EQ ROCK”, “EQ... -
Page 32: Configuring The Level Display
CONFIGURING THE LEVEL DISPLAY / ADJUSTING THE BRIGHTNESS Configuring the level display The level display temporarily provides you with a symbolic representation of the volume and audio settings whilst you are adjusting them. When you are not changing any set- tings, the level display depicts the sound system’s output level. -
Page 33: External Audio Sources
Your car sound system has a TMC output, which you can use for connecting Blaupunkt navigation systems. You can find out from your Blaupunkt dealer which nav- igation systems can be used with your car sound system. -
Page 34: Specifications
Specifications Amplifier Output power: 4 x 25 watts sine in accordance with DIN 45 324 at 14.4 V 4 x 45 watts max. power Tuner Wavebands in Europe: 87.5 - 108 MHz MW : 531 - 1602 kHz 153 - 279 kHz Wavebands in the United States: 87.5 - 107.9 MHz AM :... - Page 35 01-89583 8394 210 94 12 711 01-4598830 02-369 62464 40 2085 023-565 6331 66-817 157 01-2185 11111 916-467952 08-7501810 01-8471650 02-6130 0514 01-324 8756 022-8771260 0212-3460040 708-6817188 +55-19 3745 2773 +604-6413 640 Blaupunkt GmbH CM/PSS 8 622 403 883 WWW: http://www.blaupunkt.com...
