Billion BIPAC 7100G User Manual

802.11g adsl router
Hide thumbs Also See for BIPAC 7100G:
Table of Contents

Advertisement

Quick Links

Download this manual
BIPAC 7100G
802.11g ADSL Router
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIPAC 7100G and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BIPAC 7100G

Summary of Contents for Billion BIPAC 7100G

  • Page 1 BIPAC 7100G 802.11g ADSL Router User Manual...

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 ....................1 ....................1 NTRODUCTION 1.1 An Overview of BIPAC 7100G ..................1 1.2 Package Contents .......................2 1.3 BIPAC 7100G Features....................2 1.4 BIPAC 7100G Application ...................3 Chapter 2 ....................4 ADSL M ............... 4 SING ILLION...
  • Page 4 Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.5 Firewall ........................... 34 3.4.3.5.1 Packet Filter ........................34 3.4.3.5.2 Bridge Filtering....................... 36 3.4.3.5.3 Intrusion Detection ......................37 3.4.3.5.4 Block WAN Request ..................... 38 3.4.3.5.5 URL Blocking ......................... 39 3.4.3.6 VPN (Virtual Private Networks) ..................40 3.4.3.7 Virtual Server.........................

  • Page 5: Chapter 1

    Introduction 1.1 An Overview of BIPAC 7100G BIPAC 7100G ADSL Modem/Router provides a high-speed Ethernet port for high-speed Internet browsing. It can support downstream transmission rates of up to 8Mbps and upstream transmission rates of up to 1024Kbps. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1);...

  • Page 6: Package Contents

    One power adapter 1.3 BIPAC 7100G Features BIPAC 7100G ADSL Modem/Router provides the following features: ADSL Multi-Mode Standard: Supports downstream transmission rates of up to 8Mbps and upstream transmission rates of up to 1024Kbps. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2;...

  • Page 7: Bipac 7100G Application

    PPTP pass through function to establish a VPN connection if the user likes to run the PPTP client in his local computer. Simple Network Management Protocol (SNMP): It is an easy way to remotely manage the router via SNMP. 1.4 BIPAC 7100G Application...

  • Page 8: Chapter 2

    Chapter 2 Using Billion ADSL Modem/Router 2.1 Cautions for Using Billion ADSL Modem/Router Do not place the router under high humidity and high temperature. Do not use the same power source for the device with other equipment. Do not open or repair the case yourself. If the device is too hot, turn off the power immediately and have a qualified serviceman repair it.

  • Page 9: The Rear Ports

    Chapter 2 Using the ADSL Modem/Router 2.3 The Rear Ports Port Meaning Power ON/OFF switch Power Switch Connect the supplied power adapter to this jack. After the device is powered on, press it to reset the device or restore to factory default settings.
  • Page 10 Billion BIPAC 7100G 802.11g ADSL Router verify that the PWR, SYS, LAN and ADSL SYN LEDs are lit. If they are not, verify that you are using the proper cables. So long as the cables are connected and the LEDs are lit normally, follow section “3.2 Configuring the Network Properties”...

  • Page 11: Chapter 3

    IP address through a DHCP server or a fixed IP address which must be in the same subnet of BIPAC 7100G. The default IP address of router is 192.168.1.254 and subnet mask is 255.255.255.0. The best and easy way is to configure the PC to get an IP address from BIPAC 7100G.
  • Page 12 Billion BIPAC 7100G 802.11g ADSL Router 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons.

  • Page 13: Configuring Pc In Windows 2000

    Chapter 3 Configuration Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double- click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4.

  • Page 14: Configuring Pc In Windows 95/98/Me

    Billion BIPAC 7100G 802.11g ADSL Router 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring PC in Windows 95/98/ME 1. Go to Start / Settings / Control Panel.
  • Page 15 Chapter 3 Configuration 4. Select the IP Address tab. In this page, click the Obtain an IP address automatically radio button. 5. Then select the DNS Configuration tab. 6. Select the Disable DNS radio button and click OK to finish the configuration.

  • Page 16: Factory Default Settings

    Billion BIPAC 7100G 802.11g ADSL Router Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double- click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties.

  • Page 17: Password

    Chapter 3 Configuration User Name Password Administrator Level admin password User Level user password 2. Device IP Network settings in LAN site IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 3. ISP setting in WAN site Virtual Circuit 0: 1483 Routed IP LLC 4.

  • Page 18: Configuring With Web Browser

    Billion BIPAC 7100G 802.11g ADSL Router VPI/VCI, VC-based/LLC-based multiplexing, Username, Password, Service PPPoE Name, and Domain Name System (DNS) IP address (it can be automatically assigned by your ISP when you connect or be set manually). VPI/VCI, VC-based/LLC-based multiplexing, Username, Password, and...

  • Page 19: Status

    Chapter 3 Configuration If you want to configure the device with administrator level, type admin in the username field and password in the password field. Then, click “OK” to log in. You can modify these passwords for security and management purpose. At the configuration homepage, the left navigation pane where bookmarks are provided links you directly to the desired setup page, including: Quick Start...

  • Page 20: Status - Adsl Status

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.1.1 Status – ADSL Status Displays the status of your ADSL connection. It will refresh every two seconds.

  • Page 21: Adsl Status - Wan Status

    Chapter 3 Configuration 3.4.1.1.1 ADSL Status – WAN Status 3.4.1.1.2 ADSL Status – ATM Status...

  • Page 22: Status - Lan Status

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.1.2 Status – LAN Status Displays the status of your Local Area Network (LAN) connection.

  • Page 23: Lan Status - Tcp Status

    Chapter 3 Configuration 3.4.1.2.1 LAN Status – TCP Status 3.4.1.3 Status- PPP Status Displays the status of your PPP connection. It will refresh every ten seconds.

  • Page 24: Status- Vpn Connect Status

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.1.4 Status- VPN Connect Status Through this page you can check connection status of Virtual Private Network (VPN). Once you setup your VPN tunnel the information of connection will show on this page. 3.4.1.5 Status- Learned MAC Table...

  • Page 25: Routing Table

    Chapter 3 Configuration 3.4.1.6 Routing Table Display the current routing paths of BIPAC 7100G.

  • Page 26: System Log

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.1.7 System Log Display the system logs cumulated till the present time. You can trace the historical information through this function. 3.4.1.8 Security Logs Display the information of security logs. If hacker attacks your sever, he will be isolated by the firewall...

  • Page 27: Quick Start

    Chapter 3 Configuration 3.4.2 Quick Start If you use this device to access the Internet through the ISP, this web page is enough for you to configure this router and access the Internet without a problem. Please check Chapter 3.3 (Information from the ISP), then enter the proper values into this web page, click the Apply button and then click the Save Config button to save all of the configuration parameters to FLASH.

  • Page 28: Configuration

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3 Configuration When you click this item, you get following sub-items to configure BIPAC 7100G. LAN, WAN, Firewall, System, VPN, Virtual Server, Advanced and Help 3.4.3.1 WAN The screens below contain settings for the WAN interface toward Internet.
  • Page 29 Chapter 3 Configuration Virtual Circuit Virtual Circuit: Enable/Disable the settings of this VC. Bridge: If you set this device to be bridge mode, select Enable; if not, please select Disable. IGMP: You can Enable or Disable this function.
  • Page 30 Billion BIPAC 7100G 802.11g ADSL Router Encapsulation: There are eleven ways ─ PPPoE VC-Mux, PPPoE LLC, PPPoE None, PPPoA VC-Mux, PPPoA LLC, 1483 Bridged IP VC-Mux, 1483 Bridged IP LLC, 1483 Routed IP VC-Mux, 1483 Routed IP LLC, Classical IP over ATM, Native ATM ─ for the device to have a public IP address and then to access Internet.

  • Page 31: Lan

    Chapter 3 Configuration MTU: Maximum Transmission Unit indicates the network stack of any packet is larger than this value will be fragmented before the transmission. During the PPP negotiation, the peer of the PPP connection will indicate its MRU and will be accepted. The actual MTU of the PPP connection will be set to the smaller one of MTU and the peer’s MRU.

  • Page 32: Wireless

    Billion BIPAC 7100G 802.11g ADSL Router DHCP Server DHCP Server: Check DHCP Server to enable the router to distribute IP Addresses, subnet mask and DNS setting to computers. Hence, the following fields will be activated. If you do not check this selection, remember to specify a static IP address, subnet Mask, and DNS setting for each of your local computers.

  • Page 33: Advanced Setting

    Chapter 3 Configuration SSID : Enter the unique ID given to the Access Point (AP) built in the wireless broadband firewall gateway. To connect to this device, your wireless clients must have the same SSID as that of this device. Channel : Select the ID of channel you would like to use.

  • Page 34: System

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.4 System There are five items under the System section: Password, Time Zone, Upgrade, Factory Setting and Restart. 3.4.3.4.1 Password In factory setting, the default password is password, and that for user is also password. You can change the default password to ensure that someone cannot adjust your settings without your permission.

  • Page 35: Time Zone

    3.4.3.4.2 Time Zone BIPAC 7100G does not have a real time clock on board; instead, it uses the simple network time protocol (SNTP) to get the current time from the SNTP server in outside network. Please choose your local time zone and click Submit.

  • Page 36: Upgrade

    Billion BIPAC 7100G 802.11g ADSL Router Automatically adjust clock for daylight saving changes: It is optional for different time zone area. SNTP Server IP Address: Specify the IP address if you want to use your familiar SNTP server. 3.4.3.4.3 Upgrade...

  • Page 37: Factory Setting

    Chapter 3 Configuration To upgrade the firmware of BIPAC 7100G, you should download or copy the firmware to your local environment first. Press the “Browse…” button to specify the path of the firmware file. Then, click “Upgrade” to start upgrading. When the procedure is completed, BIPAC 7100G will reset automatically to make the new firmware work.

  • Page 38: Restart

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.4.5 Restart In case the router stops responding correctly or in some other way stops functioning, you can perform the restart. Your setting won’t be changed. Performing the restart, click on the Submit button.
  • Page 39 Chapter 3 Configuration Add: Click this button to add a new packet filter rule. After click, next figure will appear. Edit: Check the Rule No. you want to edit. Then, click the “Edit” button. Delete: Check the Rule No. you want to delete. Then, click the “Delete” button. Outgoing Incoming: Determine whether the rule is for outgoing packets or for incoming packets.

  • Page 40: Bridge Filtering

    Billion BIPAC 7100G 802.11g ADSL Router Active: Choose “Yes” to enable the rule, or choose “No” to disable the rule. Packet Type: Specify the packet type (TCP, UDP, ICMP or any) that the rule will be applied to. Select TCP if you want to scope for the connection-based application service on the remote server using the port number.

  • Page 41: Intrusion Detection

    Chapter 3 Configuration Enable Bridge Filtering: Check Yes to enable this function or check No to disable. Src MAC: Enter the source MAC address. Dest MAC: Enter the destination MAC address. Type: Enter the Ethernet type. Block Forward: Check Block if you want to block requests from the source MAC address sending to the destination MAC address.

  • Page 42: Block Wan Request

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.5.4 Block WAN Request Check “Enable” if you want to exclude outside PING request from reaching on this router.

  • Page 43: Url Blocking

    Chapter 3 Configuration 3.4.3.5.5 URL Blocking URL blocking function enables you to avoid your LAN PCs from accessing some URLs. You must check the “Enable” radio button to make the following figure appear for further configuration. Always Block: Check this will block all browsing requests from PCs Block: to specify the time period when you want this function activated.

  • Page 44: Vpn (Virtual Private Networks)

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.6 VPN (Virtual Private Networks) we will introduce the VPN settings to establish a secure communication path with remote site based on IPsec. Please check “Enable” and click “Add” button. Then you will see IKE Setup page as below figure.
  • Page 45 Chapter 3 Configuration Remote Gateway IP or Host Name: the public IP address or host name of remote VPN device. For example, it may be jet.dyndns.org (If remote IP is not fixed.) or 210.243.142.29. Remote Subnet: The IP subnet of remote LAN environment, network ID. For example, it is 192.168.4.0 Remote Subnet Mask: The range of remote IPs can be communicated.

  • Page 46: Virtual Server

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.7 Virtual Server Being a natural Internet firewall, the ADSL Router protects your network from being accessed by outside users. When it needs to allow outside users to access internal servers, e.g. Web server, FTP server, E- mail server or News server, this product can act as a virtual server.

  • Page 47: Advanced

    Chapter 3 Configuration Public Port (from) & Port (To): Enter the public port number & range you want to configure. Port Type: Select TCP if you want to scope for the connection-based application service on the remote server using the port number. Or select UDP if you want to scope for the connectionless application service on the remote server using the port number.

  • Page 48: Dns

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.8.2 DNS A Domain Name System (DNS) contains a mapping table for domain name and IP address. In the Internet, every host has a unique and friendly name such as www.yahoo.com and IP address. The IP address is so hard to remember that you may just enter the friendly name www.yahoo.com...

  • Page 49: Dynamic Dns

    Chapter 3 Configuration 3.4.3.8.3 Dynamic DNS With Dynamic DNS service, a domain name can be translated into a dynamic IP address, which is often issued by ISP for dial-up service. A local server, such as Web server, Email server or FTP server, can then be easily accessed without knowing the changing IP address.

  • Page 50: Nat

    Password: Enter the password used for sign-up. Period: Set the time period for the Router to exchange information with the DDNS server. In addition to update periodically according to this period setting, BIPAC 7100G will take the same action automatically whenever the assigned IP changes 3.4.3.8.4 NAT...
  • Page 51 Chapter 3 Configuration Session Name: Enter the desired session name. User’s IP: Allows the user to assign the IP address to map the corresponding NAT/NAPT sessions. Session Name status will be displayed at the middle of this page to show the corresponding Session Name with its IP address.

  • Page 52: Rip

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.8.5 RIP RIP: Default is Disabled. Border Gateway: Default is Enabled. Supply Interval seconds: The default value is 30 seconds. Expire Timeout seconds: The default value is 180 seconds. Garbage Timeout seconds: The default value is 120 seconds.

  • Page 53: Snmp

    Chapter 3 Configuration 3.4.3.8.6 SNMP Simple Network Management Protocol (SNMP) is an optional feature that may or may not be supported by your ADSL Bridge/Router.

  • Page 54: Static Routing

    Billion BIPAC 7100G 802.11g ADSL Router SNMP is an application layer protocol that is used for managing networks. SNMP is an optional feature that may or may not be in the specific firmware that you are working with. There are several components that make up the SNMP structure, including agents, network management stations (NMS), network management protocols, and a management information base (MIB).
  • Page 55 Chapter 3 Configuration Add: Click this button to add a new static routing. When you click this button, the next figure appears. Delete: Check the item you want to delete. Then, click the “Delete” button. Destination / Subnet Mask / Gateway Address: Fill in these fields required by this Static Routing function.

  • Page 56: Misc Configuration

    Billion BIPAC 7100G 802.11g ADSL Router 3.4.3.8.8 MISC Configuration HTTP server access: Default at Restricted. HTTP server port: Default at 80. FTP server: Default at Enabled. TFTP server: Default at Disabled. DMZ: Regarding the DMZ Host, it is a local computer exposed to the Internet. Therefore, an incoming packet will be checked by NAT algorithms in the ADSL Router, then passed to the DMZ host when the packet is not sent by hacker or not limited by the virtual server list.

  • Page 57: Diagnostic Test

    Chapter 3 Configuration 3.4.3.8.9 Diagnostic Test As soon as you enter the test program, all tests will run automatically to diagnose the connection status of the device. Checking LAN Connection Testing Ethernet LAN connection This test passes if the Ethernet LAN interface is working properly. Checking ADSL Connection Testing ADSL Synchronization This test checks your DSL modem to see if it can successfully negotiate and establish a DSL connection...
  • Page 58 Billion BIPAC 7100G 802.11g ADSL Router This test sends ATM OAM F5 Segment loop back request cells to the central office equipments through your DSL connection. This test will pass if response cell is received. Since your service provider might not support this test, your DSL modem could still work even if this test fails.

  • Page 59: Save Config

    3.4.4 Save Config Click the Submit button to write settings to flash. Then, the system will reboot for changes to take effect.

  • Page 60: Chapter 4

    Chapter 4 Troubleshooting If the ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider. This could save your time and effort but if the symptoms persist, then consult your service provider. Problems Starting Up the ADSL Router Problem Corrective Action...
