SE4
Sprint Elliptical
OWNER'S MANUAL
CAUTION:
Exercise of a strenuous nature, as is customarily done on this equipment, should not be
undertaken without first consulting a physician. No specific health claims are made or implied as they
relate to the equipment.
IMPORTANT:
Read all instructions carefully before using this product. Retain this owner's
manual for future reference.
BH North America
Foothill Ranch, California 92610

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sprint Elliptical SE4 and is the answer not in the manual?

Questions and answers

Related Manuals for BH FITNESS Sprint Elliptical SE4

Summary of Contents for BH FITNESS Sprint Elliptical SE4

  • Page 1 Sprint Elliptical OWNER’S MANUAL CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment. IMPORTANT: Read all instructions carefully before using this product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety……......………….…..1 Training......………………………3 Pre-Assembly Instructions……......7 Assembly Instructions…………………..9 Maintenance....…………...……..13 Exploded View ………........14 Parts List …………………......15 Warranty……..………………………....16 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 3: Safety

    STOP – do not use the equipment until the problem has been resolved KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 4 As your fitness level improves, the training threshold should be raised. Working through your program and gradually increasing the overload factor is important. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 5: Training

    (b) the pulse count is to approximate your BPM rate at the time you are exercising. Since heart rate slows as you recover, a longer count isn’t as accurate. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 6 The rest period req uired bet ween st rength trainin g exercises may var y fro m person to perso n. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 7 Bring your heel as close to your buttocks as possible. Hold for 15 counts and repeat with left foot up BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 8 Hold, then repeat on the other side for 15 counts BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 9: Pre-Assembly Instructions

    Foothill Ranch, CA 92610 Phone: 949-206-0330 Fax: 949-206-0013 Email: fitness@bhnorthamerica.com Web: www. .com Mon - Fri 8am - 5pm PST Toll free: 866-325-2339 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 10 77. Flat Washer M-8 7R. Right Pedal with Lower Swing Arm 78. Screw M-8x50 18. Handlebar Post A. Bottle of Threadlocker BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www. .com • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 11: Assembly Instructions

    (fig. 3) using Washers, Nuts and Bolts (77, 76 & 78) respectively. Figure 3 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 12 Install the bottle holder (34) onto the handlebar post support on the Main body using screw (66) (Fig. 5A) Figure 5 Figure 5A BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 13 (26) as shown in figure 6 To change resistance settings, turn Knob (19) - CLOCKWISE to increase resistance (load) or COUNTER- CLOCKWISE to decrease (fig. 7) BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 14 (fig. 11) until weight transferred to the wheels (59) on the front stabilizer and then move. Store the unit in a cool and dry place. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 15: Maintenance

    5. After completing the steps above, re-tighten the safety nuts (69) on both sides of the flywheel BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 17: Parts List

    (15L) for plate form w/washer Washer Aluminum stop plate Screw & washer fixed bolt Plug Steel housing w/ 2*bearing Screw Release lever 45-1 Washer BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 • Phone 949-206-0330 • Fax 949-206-0013...

  • Page 18: Warranty

    For more detailed warranty information or to register your product warranty easily online, visit our website at: www.BHFitnessUSA.com FOR WARRANTY REPAIRS, PLEASE DO NOT TAKE YOUR MACHINE BACK TO THE RETAIL STORE. CONTACT BH FITNESS FIRST. BH North America Corporation 20155 Ellipse Foothill Ranch, CA 92610 Phone: 949.206.0330;...
