  • Page 1 Monoxor ® Carbon Monoxide Analyzer Instruction 0019-9326 Operation & Maintenance Rev. 7 – January 2012 Product Leadership • Training • Service • Reliability...
  • Page 2 WARRANTY Bacharach, Inc. warrants to Buyer that at the time of delivery this Product will be free from defects in mater ial and manufac ture and will conform substan tially to Bacharach Inc.’s ap plicable specifications. Bacharach’s liability and Buyer’s remedy under this warranty are limited to the repair or replacement, at Bacharach’s option, of this Product or parts thereof returned to Seller at the factory of manufac ture and shown to Bacharach Inc.’s...

  • Page 3: Table Of Contents

    Monoxor III Contents 1.0 INTRODUCTION ..................1 2.0 TECHNICAL CHARACTERISTICS...........3 3.0 PREPARING THE ANALYZER FOR OPERATION .......5 3.1 Battery Installation .................5 3.2 Probe Installation ................6 3.3 Front Panel Pushbuttons ..............7 3.4 Setup Mode ..................8 3.4.1 Entering Setup ..............8 3.4.2 Temperature Units Setup ............. 8 3.4.3 CO Channel Zero Setup ............
  • Page 4 Monoxor III Notes Instruction 0019-9326...

  • Page 5: Introduction

    Monoxor III 1.0 INTRODUCTION The Monoxor III is a portable analyzer designed to detect and display concentrations of Carbon Monoxide (CO) gas between 0 and 2000 ppm. The analyzer is capable of testing for CO in both ambient room air, and in the flue-gas stream of fossil-fuel fired furnaces and boilers.
  • Page 6 Monoxor III Notes Instruction 0019-9326...

  • Page 7: Technical Characteristics

    Monoxor III 2.0 TECHNICAL CHARACTERISTICS CO Display Range ...... 0–2000 ppm Accuracy ........±5% of reading or ±10 ppm, whichever is greater* Resolution ........1 ppm Response Time ......90% of final value within 40 sec. Battery Requirement ....Four disposable ‘AA’ Alkaline batteries Operating Time ......
  • Page 8 Monoxor III Notes Instruction 0019-9326...

  • Page 9: Preparing The Analyzer For Operation

    Monoxor III 3.0 PREPARING THE ANALYZER FOR OPERATION To prepare a new analyzer for operation, you must install four ‘AA’ Alkaline batteries, install the probe (if needed), and set the correct time and date as described in the following paragraphs.

  • Page 10: Probe Installation

    Monoxor III 3.2 Probe Installation Install the probe if the analyzer is going to be used for flue-gas CO mea- surements, or if gas measurements need to be taken from a cramped or confined area. To install the probe, simply slide its hose over the GAS inlet of the ana- lyzer (see Figure 3-2).

  • Page 11: Front Panel Pushbuttons

    Monoxor III 3.3 Front Panel Pushbuttons Note that a push button may perform several functions, depending on what screen is being displayed at the time. • Turns analyzer ON/OFF. There is a 10 or 60 second warm- up and a 5 second turn-off-delay period.

  • Page 12: Setup Mode

    Monoxor III 3.4 Setup Mode The analyzer is preset at the factory for the parameters shown below, but can be changed as described in their associated sections. Function Parameter To Change Temperature Unit °F Section 3.4.2 CO Channel Auto Zero Section 3.4.3...

  • Page 13: Co Channel Zero Setup

    Monoxor III 1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly press ENTER until the Temperature Units Setup Screen is displayed. 2. Press the ▲ or ▼ button until the desired temperature unit (°F or °C) is displayed.

  • Page 14: Time Setup

    Monoxor III 3.4.4 Time Setup There are two Time Setup Screens, one for hours and the other for min- utes. Two bars appear above the segments being changed. The clock is in a 24 hour format, but will appear as AM/PM on the printout.

  • Page 15: Year Setup

    Monoxor III 3.4.6 Year Setup The Year Setup Screen is labeled “yEAr”. 1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly press ENTER until the Year Setup Screen is displayed. 2. Press the ▲ or ▼ button until the correct year is displayed.
  • Page 16 Monoxor III Notes Instruction 0019-9326...

  • Page 17: Operation

    Monoxor III 4.0 OPERATION To operate the Monoxor III, you simply . . . • Turn the analyzer ON • Wait for the unit to warm up • Take a gas sample 4.1 Taking a Gas Sample Important! If the CO channel is set up for Auto Zero (refer to Section 3.4.3), ensure that the analyzer will be sampling...

  • Page 18: Ending A Test

    Monoxor III 4.2 Ending a Test WARNING! Burn Hazard. Do not touch the probe after removing it from a flue. Allow the probe to cool before han- dling (about 5 minutes). After taking a gas sample, remove the probe and take the analyzer to an area containing fresh air.

  • Page 19: Co Sensor Error Screen

    Monoxor III 4.5 CO Sensor Error Screen When the CO channel is set up for Auto Zero (refer to Section 3.4.3), a CO sensor error will occur if the detected Carbon Monoxide level is above 50 ppm during the warm-up period.

  • Page 20: Operating Tips

    Monoxor III 4.8 Operating Tips • When an analyzer is brought in from a cold vehicle, let it warm up slowly to minimize condensation. Temperatures below freezing will not damage the analyzer; however, bringing a cold analyzer into a warm, humid environment may cause condensate to form inside the case.

  • Page 21: Printing Test Results

    Monoxor III 4.10 Printing Test Results Turn ON the printer. Refer to the printer’s instruction manual for detailed operation and maintenance information. If not already done, set the printer param- eters as follows: • Data – 8 bits • Baud – 9600 •...
  • Page 22 Monoxor III Notes Instruction 0019-9326...

  • Page 23: Calibration & Maintenance

    Technical Characteristics Section of this manual, the standards used must be at least 4 times as accurate as the stated accuracy of the Monoxor III. 5.1 Entering the Calibration Mode and Testing the Display Segments 1.

  • Page 24: Ambient Temperature Calibration

    500 ppm (P/N 0024-0492) CO calibration gas • Calibration Kit, (P/N 0024-7059) If you are primarily performing flue-gas testing, calibrate the Monoxor III with 500 ppm CO calibration gas. If the analyzer will be primarily used for ambient testing, then you may wish to consider 100 ppm CO calibration gas.
  • Page 25 Monoxor III 2. Allow the pump to run and sample fresh air for at least 1 minute. 3. Use the ▲ or ▼ buttons to set the displayed value to 0 ppm. 4. Do one of the following: a. End this procedure and save the new zero value by holding down the ENTER button for 2 seconds;...

  • Page 26: Water Trap / Filter Maintenance

    Monoxor III 5.4 Water Trap / Filter Maintenance The Water Trap / Filter Assembly removes water condensate from the gas sample, and prevents soot from contaminating the internal components of the analyzer. See Figure 5-2. Drain the water condensate after every test and during each test if the water level nears the tip of the riser tube in the water trap side.

  • Page 27: Co Sensor Replacement

    Monoxor III 5.5 CO Sensor Replacement • CO Sensor, (P/N 0024-7265) Material Required: • CO Sensor Gasket, (P/N 0024-1112) • #1 Phillips Screwdriver Procedure: 1. Disassemble the analyzer as follows: a. Remove the battery cover and the batteries, uncovering one of the cover hold-down screws.

  • Page 28: Pump Assembly Replacement

    Monoxor III • #1 Phillips Screwdriver Procedure: 1. Disassemble the analyzer as follows: a. Remove the battery cover and the batteries, uncovering one of the cover hold-down screws. b. Remove and set aside all four cover hold-down screws. c. With the analyzer on its back, remove the front cover, laying it face down to the left of the body.
  • Page 29 Monoxor III (RED WIRE) SENSOR Not Used PUMP (RED WIRE) Figure 5-3. CO Sensor Located on Backside of Printed Circuit Board Instruction 0019-9326...
  • Page 30 Monoxor III CO SENSOR GASKET PUMP HOLD DOWN CLAMP Figure 5-4. Back Case Component Locations Instruction 0019-9326...

  • Page 31: Replacement Parts

    Protective Rubber Boot w/Magnet ..........0024-1127 True Spot Smoke Test Set ...............0021-7006 Filter Paper, True Spot (40 strips) ..........0021-0019 6.3 Service Centers Replacement parts and service can be obtained by contacting one of the fol- lowing Bacharach Service Centers: Instruction 0019-9326...
  • Page 32 Bacharach, Inc. 621 Hunt Valley Circle New Kensington, PA 15068 Phone: 1-800-736-4666 Fax: 724-334-5723 Email: help@mybacharach.com Canada Bacharach of Canada, Inc. 20 Amber St. Unit# 7 Markham, Ontario L3R SP4 Canada Phone: 905-470-8985 Fax: 905-470-8963 Email: bachcan@idirect.com 7.0 HAZARDS OF...

  • Page 33: Hazards Of Carbon Monoxide

    Monoxor III Carbon Monoxide (CO) poisoning results in headache, nausea, chronic tiredness, confusion, dizziness, and sometimes coma or death. CO effects people by cutting off the supply or Oxygen to their muscles and brain. The harmful effects of CO exposure depend on both the concentration of CO in the air and the length of exposure.

  • Page 34: Declaration Of Conformity

    Monoxor III 8.0 Declaration of Conformity Instruction 0019-9326...
  • Page 35 Monoxor III Notes Instruction 0019-9326...
  • Page 36 World Headquarters 621 Hunt Valley Circle, New Kensington, PA 15068 Ph: 724-334-5000 • Fax: 724-334-5001 • Toll Free: 800-736-4666 Web site: www.mybacharach.com • E-mail: help@mybacharach.com Printed in U.S.A.
