Operating Guide
Compact Programmable
Room Air Conditioner with remote control
CP18C30
66121417 (4-06)
Please register
your air conditioner
Whenever you call to request service
on your appliance, you will need to
provide your complete model number
and serial number. You can find this
information on the model and serial
number label.
Please record model and serial
number information below:
MODEL NUMBER
SERIAL NUMBER
PURCHASE DATE
Advertisement
Table of Contents
Related Manuals for Friedrich CP18C30
Summary of Contents for Friedrich CP18C30
-
Page 1: Operating Guide
Operating Guide Compact Programmable Room Air Conditioner with remote control CP18C30 66121417 (4-06) Please register your air conditioner Whenever you call to request service on your appliance, you will need to provide your complete model number and serial number. You can find this information on the model and serial number label. -
Page 2: Table Of Contents
Window Installation (on some models) ...7 Through-the-Wall Cabinet Installation ...9 Complete Installation ... 10 Air Conditioner Use... 11 Starting Your Air Conditioner—Digital Control ... 12 Remote Control Operation ... 13 Normal Sounds ... 13 Air Conditioner Care... 14 Cleaning the Air Filter ... 14 Cleaning the Front Panel... -
Page 3: Installation Requirements
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions: Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Installation Requirements Tools and Parts Gather the required tools and parts before starting installation. -
Page 4: Electrical Requirements
Ground wire must be connected to ground screw located in lower right corner of air conditioner when air conditioner is in cabinet. The electrical ratings for your air conditioner are listed on the model and serial number label. The model and serial number label is located behind the front panel on the flange below the control panel area. -
Page 5: Recommended Grounding Method
NOTE: Your unit’s device may differ from the ones shown. A. Reset button B. Test button This room air conditioner is equipped with a power supply cord required by UL. This power supply cord contains state-of-t he-art electronics that sense leakage current. If the cord is crushed, the electronics detect leakage current and pow er will be disconnected in a fraction of a second. -
Page 6: Installation Instructions
Remove and dispose of/recycle packaging materials. � Remove tape and glue residue from surfaces before turning on the air conditioner. Rub a small amount of liquid dish soap over the adhesive with your fingers. Wipe with warm water and dry. -
Page 7: Window Installation (On Some Models)
NOTES: Handle air conditioner gently. � Be sure your air conditioner cabinet does not fall out of the � opening during installation or removal. The place where the power cord exits the air conditioner � should be no more than 4 ft (122 cm) from a grounded 3 prong outlet. - Page 8 Install Cabinet into Window Handle air conditioner gently. � Be sure your air conditioner cabinet does not fall out of the � opening during installation or removal. The place where the power cord exits the air conditioner � should be no more than 4 ft (122 cm) from a grounded 3 prong outlet.
-
Page 9: Through-The-Wall Cabinet Installation
B. Locking nut C. Adjustment bolt NOTES: Handle air conditioner gently. � Be sure your air conditioner cabinet does not fall out of the � opening during installation or removal. The place where the power cord exits the air conditioner �... -
Page 10: Complete Installation
2. Insert cabinet into the framed wall opening. The top of the 3. Use a level to check that cabinet is level side to side. 4. Check that air conditioner cabinet is tilted to the outside so 5. Reuse the insulation to seal opening between cabinet and 6. -
Page 11: Air Conditioner Use
This section explains proper air conditioner operation. IMPORTANT: If you turn off the air conditioner, wait at least 3 minutes � before turning it back on. This prevents the air conditioner from blowing a fuse or tripping a circuit breaker. -
Page 12: Starting Your Air Conditioner-Digital Control
Timer Delay To set the Timer for a 1- to 24-hour delay until the air conditioner turns off (the air conditioner must be On): 1. Press TIMER. Indicator light will flash. 2. Press the plus or minus button to change the delay time from 1 to 24 hours. -
Page 13: Remote Control Operation
1º until it reaches 64°F (18°C). To set Timer for a 1- to 24-hour delay before air conditioner is turned off (air conditioner must be On): 1. Press TIMER. Indicator light on air conditioner control panel will flash. -
Page 14: Normal Sounds
Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your air conditioner properly. Call your local authorized dealer for an annual checkup. Remember… the cost of this service call is your responsibility. -
Page 15: Assistance Or Service
For service assistance or to locate factory-authorized parts in your area, call our Customer Service Center at 210-357-4400, or your nearest authorized service center. You also can visit www.friedrich.com to locate your nearest Friedrich Service Center. There is excessive heat or moisture (open container �... -
Page 16: Warranty
ANY PART: If any part supplied by FRIEDRICH fails because of a defect in workmanship or material within twelve months from date of original purchase, FRIEDRICH will repair the product at no charge, provided room air conditioner is reasonably accessible for service.
