Operating Guide
Compact Programmable
Room Air Conditioner with remote control
CP14
CP18
CP24
66121417 (1-07)
Please register
your air conditioner
Whenever you call to request service
on your appliance, you will need to
provide your complete model number
and serial number. You can fi nd this
information on the model and serial
number label.
Please record model and serial
number information below:
MODEL NUMBER
SERIAL NUMBER
PURCHASE DATE
Advertisement
Table of Contents
Related Manuals for Friedrich CP14
Summary of Contents for Friedrich CP14
-
Page 1: Operating Guide
Operating Guide Compact Programmable Room Air Conditioner with remote control CP14 CP18 CP24 66121417 (1-07) Please register your air conditioner Whenever you call to request service on your appliance, you will need to provide your complete model number and serial number. You can fi nd this information on the model and serial number label. -
