5/10 Rev. 5.05-00
Ersatzteile
Gehäuse ......................................................
Kunststoff- und Blechteile ........................
Gussteile ..................................................
Materialabrollung .........................................
Foliendorne ..................................................
Folien-Abrolldorn AP 5.6 ..........................
Folien-Abrolldorn AP 5.4 ..........................
Folien-Aufrolldorn AP 5.6 .........................
Folien-Aufrolldorn AP 5.4 .........................
Antrieb..........................................................
Druckmodul..................................................
Vorschubwalze.........................................
Etiketten-Lichtschranke, Materialführung.
Druckkopf-Einheit.....................................
Druckkopf-Andruckachse .........................
Elektronik .....................................................
Platinen ....................................................
Kabel „AP 5.x basic" .................................
Kabel „AP 5.x basic" Spender ..................
Kabel „AP 5.x peripheral" .........................
Kabel „AP 5.x peripheral" Spender...........
AP 5.x Spender ............................................
SERVICE MANUAL / SERVICE-HANDBUCH
AP 5.4-AP 5.6
Housing .................................................................. 2
Plastic and sheet metal parts.............................. 2
Cast parts............................................................ 3
Material unwinder ...................................................4
Ribbon mandrels .....................................................5
Ribbon unwind mandrel AP 5.6........................... 5
Ribbon unwind mandrel AP 5.4........................... 6
Ribbon rewind mandrel AP 5.6............................ 7
Ribbon rewind mandrel AP 5.4............................ 8
Drive .......................................................................9
Print module .........................................................10
Feed roller......................................................... 10
Label sensor, material guide............................. 11
Printhead unit.................................................... 12
Printhead pressure axle .................................... 14
Elektronics ............................................................15
Boards............................................................... 15
Cables AP 5.4 basic .......................................... 17
Cables AP 5.4 basic dispenser ......................... 18
Cables AP 5.x peripheral................................... 19
AP 5.x dispenser ...................................................21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP5.4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avery Dennison AP5.4

Summary of Contents for Avery Dennison AP5.4

  • Page 1: Table Of Contents

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH AP 5.4-AP 5.6 Ersatzteile Spare Parts Gehäuse ............Housing ..............2 Kunststoff- und Blechteile ......Plastic and sheet metal parts......2 Gussteile ..........Cast parts............3 Materialabrollung ......... Material unwinder ...........4 Foliendorne ..........Ribbon mandrels .............5 Folien-Abrolldorn AP 5.6 ......

  • Page 2: Housing

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Ersatzteile / Spare Parts AP 5.4-AP 5.6 Gehäuse / Housing Kunststoff- und Blechteile / Plastic and sheet metal parts Bezeichnung Designation Teilenr. / Part number Gehäuse Displayseite Cover control panel A100486 Rückhaube Rear hood A3842 Abdeckung Stecker Cover connector...

  • Page 3: Spare Parts

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Gussteile / Cast parts Bezeichnung Designation Teilenr. / Part number Kugellager (klein) Ball bearing (small) A3881 Bronzelager Bronze bushing A3879 Plastikkappe Plastic cap A9588 Kugellager (groß) Ball bearing (large) A3882 Gummifuß...

  • Page 4: Material Unwinder

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Materialabrollung / Material unwinder Bezeichnung Designation Teilenr. / Part number Achse Axle A3865 AP 5.4 A9944 AP 5.6 Achse Axle A3864 AP 5.4 A9968 AP 5.6 Führungsscheibe Guide disk A3773 Schenkelfeder...

  • Page 5: Ribbon Mandrels

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Foliendorne / Ribbon mandrels Folien-Abrolldorn AP 5.6 / Ribbon unwind mandrel AP 5.6 Bezeichnung Designation Teilenr. / Part number Einstellachse ZSB Adjust axle assy. A100395 Foliendorn ZSB Ribbon mandrel assy.

  • Page 6: Ribbon Unwind Mandrel Ap 5.4

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Folien-Abrolldorn AP 5.4 / Ribbon unwind mandrel AP 5.4 Bezeichnung Designation Teilenr. / Part number Folien-Abrolldorn ZSB Ribbon unwind mandrel assy. A4023 Distanzring 4 mm Spacer ring 4 mm A3790 Stahlscheibe ZSB Thrust disk assy.

  • Page 7: Ribbon Rewind Mandrel Ap 5.6

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Folien-Aufrolldorn AP 5.6 / Ribbon rewind mandrel AP 5.6 Bezeichnung Designation Teilenr. / Part number Einstellachse ZSB Adjust axle assy. A100395 Foliendorn ZSB Ribbon mandrel assy. A100176 Distanzring 4 mm Spacer ring 4 mm A3790...

  • Page 8: Ribbon Rewind Mandrel Ap 5.4

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Folien-Aufrolldorn AP 5.4 / Ribbon rewind mandrel AP 5.4 Bezeichnung Designation Teilenr. / Part number Folien-Aufrolldorn ZSB Ribbon rewind mandrel assy. A4025 Distanzring 4 mm Spacer ring 4 mm A3790 Schaumstoffring Foam ring...

  • Page 9: Drive

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Antrieb / Drive Bezeichnung Designation Teilenr. / Part number Zahnrad Gearwheel A3780 Zahnriemen T-belt A3920 Zahnrad ZSB Gearwheel assy. A3910 Zahnriemen T-belt A3922 Schrittmotor ZSB Stepper motor assy. A3911 HDT, T=3, L=363, Z=121, B=6 HDT, T=3, L=210, Z=70, B=6...

  • Page 10: Print Module

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Druckmodul / Print module Vorschubwalze / Feed roller Bezeichnung Designation Teilenr. / Part number Abreißkanten-Kit Tear-off edge kit A101947 AP 5.4 A101948 AP 5.6 Achse ZSB Axle assy. A102019 Vorschubwalzen-Kit Feed roller kit...

  • Page 11: Label Sensor, Material Guide

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Etiketten-Lichtschranke, Materialführung / Label sensor, material guide Bezeichnung Designation Teilenr. / Part number Etikett mit Maßstab Label with scale A3935 Aluminiumprofil Aluminium profile A3919 AP 5.4 A9940 AP 5.6 Materialführung Material guiding...

  • Page 12: Printhead Unit

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Druckkopf-Einheit / Printhead unit Bezeichnung Designation Teilenr. / Part number Druckkopf-Schwenkachse Printhead swivelling axle A3874 AP 5.4 A9947 AP 5.6 Bronzelager Bronze bushing A3879 Druckkopf-Aufnahme ZSB Printhead bracket assy. A4390 AP 5.4 A100189 AP 5.6...
  • Page 13 5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Bezeichnung Designation Teilenr. / Part number Schaltfahne Druckkopf- Switching flag printhead A3829 Sensor sensor Zugfeder Extension spring A3946 AP 5.4 A101070 AP 5.6...

  • Page 14: Printhead Pressure Axle

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Druckkopf-Andruckachse / Printhead pressure axle Bezeichnung Designation Teilenr. / Part number Schließhebel-Lichtschranke Closing lever sensor A3969 Schaltfahne Schließhebel- Switching flag closing lever A3829 Sensor sensor Andruckachse Contact pressure axle A3873 AP 5.4 A9946...

  • Page 15: Elektronics

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Elektronik / Elektronics Platinen / Boards Bezeichnung Designation Teilenr. / Part number Schachtabdeckung Slot cover A3840 Kabelschelle Cable clamp A3853 Kabelhalter-Platte Cable clamp plate A3839 Wärmeleitfolie Heat conduction foil A3961 Befestigungswinkel Holding bracket...
  • Page 16 5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Einschließlich Pos. 7, 8, 10 / Includes pos. 7, 8, 10 WARNUNG! - Es besteht Explosionsgefahr, wenn die Batterie falsch ersetzt wird. WARNING! - Danger of explosion, if the battery is incorrectly replaced. AVERTISSEMENT! - Il y a un danger d´explosion, si la batterie est replacée incorrectement.

  • Page 17: Cables Ap 5.4 Basic

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Kabel „AP 5.x basic“ / Cables AP 5.4 basic A3958 Vorschub- motor A3970 Drive motor A3911 CPU-Platine A3958 A4202 CPU board A100150 A3971 Bedienfeld Operating panel A7149 A100529 A101324 Etiketten-LS (Durchlicht)

  • Page 18: Cables Ap 5.4 Basic Dispenser

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Kabel „AP 5.x basic“ Spender / Cables AP 5.4 basic dispenser A3958 Vorschub- motor A3970 Drive motor A3911 POWER CPU-Platine A3958 A4202 CPU board A100150 A3971 A100433 Bedienfeld Operating panel A7149...

  • Page 19: Cables Ap 5.X Peripheral

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Kabel „AP 5.x peripheral“ / Cables AP 5.x peripheral A3958 Vorschub- motor A3970 Drive motor A3911 POWER CPU-Platine A3958 A4202 CPU board A100150 A3971 A100433 Bedienfeld Operating panel A7149 A100529 Etiketten-LS (Durchlicht)

  • Page 20: Cables Ap 5.X Peripheral Dispenser

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 Kabel „AP 5.x peripheral“ Spender / Cables AP 5.x peripheral dispenser A4958 I orshzum - b otor A4917 Drp ye b otor A4900 Pa X EK Pa X EK W PR-Pä...

  • Page 21: Ap 5.X Dispenser

    5/10 Rev. 5.05-00 SERVICE MANUAL / SERVICE-HANDBUCH Spare Parts List AP 5.4-AP 5.6 AP 5.x Spender / AP 5.x dispenser Bezeichnung Designation Teilenr. / Part number Endstufenplatine BLDC-Motor Output stage board BLDC A4034 motor Aufwickler ZSB Rewinder assy. A4874 AP 5.4 A9952 AP 5.6 Zahnrad...
