RGB533WEAWW—30" Free-Standing Gas Range
Dimensions (in inches)
30
46-1/2
26-1/4*
46-3/8
*Depth including handle
Specification Revised 6/00
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
36±1/4
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Recommended common area
for gas outlet and electrical
outlet for GE free-standing gas
range models
30
C L
2-1/2
8
4
24
2
9
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
CERTIFIED
Installation Information:
Dimensions shown here are the
same as those shown on the
installation instructions at the
time this sheet was printed. Before
proceeding with installation, see
your Hotpoint supplier for latest
detailed preparation and installation
instructions or install from the
instructions packed with each unit.
Optional gas range
accessory drip pans:
(Available at additional cost)
To order these accessory drip pans,
call toll-free 800-626-2002.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint RGB533WEAWW
Summary of Contents for Hotpoint RGB533WEAWW
- Page 1 RGB533WEAWW—30" Free-Standing Gas Range Dimensions (in inches) Installation Information: Recommended common area Dimensions shown here are the for gas outlet and electrical outlet for GE free-standing gas same as those shown on the range models installation instructions at the Recommended area for time this sheet was printed.
- Page 2 • 2 Oven Shelves / 6 Embossed Rack Positions • White Frameless Glass Oven Door with Window • Designer-Style Handle • Optional Accessory One-Piece Drip Pans Available at Additional Cost • LP Conversion Kit Included • Model RGB533WEAWW–White on White Specification Revised 6/00...
