30" free-standing gas range

Advertisement

Quick Links

RGB533WEW—30" Gas Range
Dimensions (in inches)
30
46-1/2
28-1/4*
46-3/8
*Depth including handle
Created 8/96
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
36 1/4
For answers to your GE Monogram,
GE, Hotpoint and RCA appliance questions, call
GE Answer Center
Recommended common area
for gas outlet and electrical
outlet for GE free-standing gas
range models
30
2-1/2
8
4
24
2
9
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
GE Profile,
®
service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
CANADIAN GAS ASSOCIATION
required step in the installation
of the range.
R
APPROVED
Electrical Rating: 120V, 60Hz, 5A
Installation Information:
Dimensions shown here are the
same as those shown on the
installation instructions at the
time this sheet was printed. Before
proceeding with installation, see
your Hotpoint supplier for latest
detailed preparation and installation
instructions or install from the
instructions packed with each unit.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RGB533WEW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hotpoint RGB533WEW

  • Page 1 For answers to your GE Monogram, ™ GE Profile, GE, Hotpoint and RCA appliance questions, call GE Answer Center ® service, 800.626.2000. All GE ranges are equipped with an Anti-Tip device. The installation...
  • Page 2 RGB533WEW—30" Free-Standing Gas Range Created 8/96 Features and Benefits • White on white Model • Upswept Porcelain-Enameled Cooktop • Sealed Cooktop Burners (1) 12,000/1,000 BTU Performance Plus Burner (1) 5,000/600 BTU Simmer Burner (2) 9,500/850 BTU All-Purpose Burners • Removable Grey Square Grates •...
