ATN OTS10 COLOR-9Hz Specification

THERMAL IMAGING MONOCULAR
The OTS10-9Hz sets the standard for affordable, small, lightweight
thermal imaging cameras. It is pocket-sized, rugged and durable.
It is built around state-of-the-art uncooled thermal imaging technology. It
offers superior performance, compact size, comfort of wear and cost
efficiency which makes it the perfect thermal imaging device.
The ATN OTS10-9Hz is ideal for home security, public safety, first
responder and security operations.
BENEFITS AND FEATURES:
High resolution digital thermal imaging
Compact, light weight and durable housing
High Quality optics
Video output
Two Image/Video modes
(Black/White and Color)
Adjustable display brightness
Adjustable eyepiece diopter
Adjustable lens focus
Digital zoom
Power input capability
Waterproof
One-Year Warranty
USAGES:
Law Enforcement
Home Security
Boating
OTS10
BASIC KIT
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
1341 San Mateo Ave,
South San Francisco, CA 94080.
Public Utilities
Construction
Search and Rescue
VIDEO
OUTPUT
www.atncorp.com
e-mail: sales@atncorp.com, info@atncorp.com
OTS10 COLOR-9Hz
SPECIFICATIONS
Video Frame Rate
Magnification
Objective Focal Length
FOV
Focus Range
Focus Adjustment
Exit Pupil
Eye Relief
Detector Type
Spectral Response
Pixels
Pixel Size
Angular Resolution, mrad
Thermal Sensitivity
Range to Detect a Human
Output Format
Display
Display Format
Color
Digital ZOOM
Brightness Adjustment
Contrast Adjustment
Power Supply
Start-Up Time
Operating Time
w/one battery pack
External Power Supply
Operating Temperature
Range
Waterproof
Dimensions
Weight (w/batteries)
9Hz
1.2X
25 mm
11° x 8°
from 1m to infinity
Manual
14mm
25mm
Uncooled Microbolometer
7-14 µm
160 x 120
30 x 30 µm
1.2
< 0,1°C
475 m
Analog PAL / NTSC
OLED matrix
SVGA, 852 x 600 pxl
Color/Monochrome
2x
Manual
Automatic
2 x 3V, 123Atype
< 3 sec
4 hrs
DC 6V, 500 mA
from -20°C to +50°C
Yes, up to 10m submersion
118 x 81 x 46 mm
0.34 kg
