ATEN CS62 Specification

CS62 / CS62S
2-Port PS/2 KVM Switch
The CS62/CS62S Switch is a control unit that allows access to two computer systems from a single
console (keyboard, monitor, and mouse). The CS62/CS62S improves on previous models with a 50%
smaller desktop footprint plus attached custom KVM cables for hassle-free installation and a neat and
tidy workspace.
Setup is fast and easy; plugging cables into their appropriate ports is all that is entailed. There is no
software to configure, no installation routines, and no incompatibility problems.
Console Computers
PS/2 PS/2
Non-Powered
Features
• One PS/2 console controls two PS/2 computers
• Compact design, built in 1.2m cables(CS62),0.9m
Cables(CS62S)
• All-in-one design
• Superior video quality- up to 2048 x 1536; DDC2B
• Auto Scan function to monitor computer operation
• Non-powered
Headquarters
ATEN International CO., Ltd.
3F, No.125, Sec. 2, Datung Rd. Sijhih City, Taipei 221, Taiwan
Tel: 886-2-8692-6789
© Copyright 2009ATEN® International Co., Ltd. All brand names and trademarks are the registered property of their respective owners.
Diagram
Computer 1
OS Support
Computer 2
Win, Linux, FreeBSD
Fax: 886-2-8692-6767 E-mail : online@aten.com.tw

Specifications

Function
Computer Connections
Port Selection
Keyboard
Console
Video
Ports
Mouse
Connectors
Keyboard
KVM
Video
Ports
Mouse
LEDs Selected
Cable
Computers
Length
Emulation Keyboard/Mouse
Video
Scan Interval
Operating Temp.
Environment Storage Temp.
Humidity
Housing
Weight
Physical
Properties
Dimensions
(L x W x H)
* The specifications and pictures are subject to change without notice.
Console
PS/2
CS62 / CS62S
2
Hotkey
1 x 6-pin Mini-DIN Female (Purple)
1 x HDB-15 Female (Blue)
1 x 6-pin Mini-DIN Female (Green)
2 x 6-pin Mini-DIN Male (Purple)
2 x HDB-15 Male (Blue)
2 x 6-pin Mini-DIN Male (Green)
2 (Green)
1.2m / 0.9m
PS/2
2048 x 1536; DDC2B
3, 5, 10, 20 Seconds(default 5 sec)
0-50°C
-20-60°C
0-80% RH, Non-condensing
Plastic
0.33 kg
7.30 x 5.85 x 2.25 cm
2009. Version 1.0
