KB-4000 / KP-100 / SD-100
MULTIFUNCTION
SECURITY DEVICE
USER'S MANUAL
Rev.: C0
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Inc. expressly disclaims any
warranties, expressed, implied or statutory, including without limitation implied
warranties of merchantability or fitness for particular purpose, good title and against
infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw or http://www.posiflexusa.com
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Inc. 2006
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 19010900040

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KB-4000 and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX KB-4000

  • Page 1 KB-4000 / KP-100 / SD-100 MULTIFUNCTION SECURITY DEVICE USER’S MANUAL Rev.: C0 FCC Notes: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class...
  • Page 2: General Description

    Ex. For KP-100, KP-110 or KB-4000 with only keypad, there will be no USB interface installed; For SD- 100 without the iButton reader, there will be no 9 pin D connector.
  • Page 3: Unpacking Contents

    MECHANICAL FIXATION For KB-4000 the stand alone security device, there is little concern about the mechanical fixation as long as the security device (keyboard) is placed in a horizontal flat surface not subject to extreme environmental conditions.
  • Page 4: Cable Connection

    Please refer to the pictures above with numbered parts illustration listed below them. The USB cable could be absent from KB-4000 / KP-100 / KP-110 if the product is purchased without the smart card reader. If it is SD100 with only the iButton receptor there will only be the PS/2 cable and RS232 cable.
  • Page 5 In the cavity found at rear side of KB-4000 or KP -100 / KP-110, there is a PS/2 KB jack. Connect a standard PS/2 keyboard device to this jack and insert the cable from the PS/2 keyboard device into the cable hold groove for strain relief and fixation when a PS/2 KB is required.
  • Page 6: Keypad Programming

    The programming of the keys above the numerical keypad in KP-100 or KP-110 and those beside the numerical keypad in KB-4000 is in general the task of the system integrator and not the average end user. For end user, please go to the chapter of “OPERATION GUIDE”...
  • Page 7 If a PS/2 interface keyboard is to be used, please connect it to the extended PS/2 KB jack in the recessed cavity on back of KB-4000 / KP- 100 / KP-110 as mentioned earlier. Please note that there must not be any other PS/2 device connected in between the KB-4000 / KP-100 / KP-110 and the PS/2 KB port of the host system in the keypad programming operation.
  • Page 8 Information CD or download from our web as mentioned earlier for the ISO MSR option in KB-4000 / KP-100 and go to either the subfolder “DOS” for the MSR manager under MS-DOS or the other subfolder “Win” for setting up the MSR manager under Windows OS.
  • Page 9: Magnetic Stripe Reader

    The magnetic stripe reader in KP-100 / KP-110 or KB-4000 connects to the host through KB port and therefore requires no driver installation to get it working.
  • Page 10 interface or PS/2 KB interface through Hyper Terminal configuration setup. Please refer to instruction on our web site for the detail. In general, this should be taken care of by the software in the way organized by the system integrator. Each iButton receptor is delivered with 2 iButton keys attached.
