Installation GUIDE FOR WALL
PP7000/PP7000II/PP7700 SERIES
KIT PART NUMBER: 39351001001(beige) / 39351001002(Charcoal)

KIT CONTENT (Besides this guide):

Drill pattern on wall
80 mm
101
Fig-1 Kit content besides this guide (Printer not included)
ITEM PART NUMBER
101
10521040252
102
MTP6PLUG
PP30PAPRROLR
103
PP30PAPRROLR-C
KIT APPLICATION: This kit can be used to hang Posiflex thermal POS
Printer Wall Mount Installation Guide 1
MOUNT KIT OF
Rev. A
103
102
DESCRIPTION
Self Tapping Screw 4φ-25L
Plastic Cotter
Paper Roller Shaft (Beige)
Paper Roller Shaft (Charcoal)
printer PP7000 / PP7000II / PP7700 for wall-mount
application. Color of the wall mount kit can be selected
to match that of the printer.
Q'TY
4
4
1
P/N:19360900031
