Location Requirements

This ice maker should be installed by qualified personnel.
NOTICE:
1. Before setting the ice maker inside a cabinet, connect the water supply pipe correctly.
Untie the drain hose, insert it into the drain, and connect the power supply line.
2. Do not kink or pinch the power supply line between the ice maker and wall or
cabinet.
Installation clearance
Top view
Rear
Front

Installing the stability brackets

This operation requires at least two persons.
If you wish to install the ice maker in a free-standing mode rather than enclosed, it is
necessary to attach the two metallic stability brackets that can be found packed inside
the ice storage bin. Keeping the machine tilted to the right, but not more than 45ß , attach
one bracket to the center of the underside of the ice maker with two screws (supplied).
See illustration below. Set the unit back on its four feet, then tilt it forward in order to
screw in the second bracket on the underside of the unit opposite the first bracket. Level
the ice maker. This operation will stabilize it for free-standing operation.
To ensure proper ventilation for your ice maker, the front of the unit must be
completely unobstructed.
Side view
8
