Important
—This is a Class A device and is
intended for use in a light industrial environ-
ment. It is not intended nor approved for use
in an industrial or residential environment.
Part# 07M2113-UM
Doc# 03331U2-001,
Rev. B
Revised 8/16/07
An ISO-9001Certified
Company
USER
MANUAL
MODELS 2113 & 2115
CopperLink™-T
T1/E1 Extenders
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007
