  • Page 2: Table Of Contents

    Table Of Contents Important Safety Instructions ................1 Disc Information....................3 Front Panel ......................4 Rear Panel ......................5 Remote Control ....................6 System Connections ..................10 Connecting to Power Supply................10 Connecting to the Car Adapter................10 Connecting to External AV Signal Source ............11 Connecting to External AV Signal Source(YPbPr) ..........

  • Page 3: Important Safety Instructions

    Important Safety Instructions This symbol indicates that dangerous voltage instituting a risk of electric shock is present within this unit. This symbol indicates that there are important operation and maintenance instructions in the literature accompanying the appliance. Caution: Laser radiation when open. Do not stare into beam. Caution: use of any controls, adjustments, or procedures other than those specified herein may result in hazardous radiation exposure.
  • Page 4 Important Safety Instructions NOTES IMPORTANT FOR LASER PRODUCTS Read these instructions. 1. CLASS 1 LASER PRODUCT Keep these instructions. 2. DANGER: Visible laser radiation when open and Heed all warnings. interlock failed or defeated. Avoid direct exposure to beam. Following all instructions. 3.

  • Page 5: Disc Information

    Disc Information Discs Supported DISC LOGO CONTENTS SIZE MAXIMUM TIME 133min(SS-SL) Audio+Video 242min(SS-DL) 12cm (active picture) 266min(DS-SL) 484min(DS-DL) Audio 12cm 74min JPEG Still high resolution 12cm Audio + Video DIVX 12cm (Active picture) The operating method of some DVD discs is specified by the software maker. Please refer to the instruction manual of the disc.

  • Page 6: Front Panel

    Front Panel 1. Colour TFT screen In setup menu, use the ◄/►direction 2. Speakers buttons for the same function. 3. Power Indicator PLAY button During normal operation, it is blue; In Press to start disc playback in DVD mode. standby mode, it is red. 10.

  • Page 7: Rear Panel

    Rear Panel Open the back cover on the right side of the unit’s rear panel and you will see all jacks, as shown below: 1. Y/Pb/Pr Input Jacks 5. S-VIDEO Input Jack Connect the Y/Pb/Pr input source in Connect to the S-VIDEO input in S-VIDEO Component mode.

  • Page 8: Remote Control

    Remote Control Remote Control Drawing 5. S.M. button Press repeatedly to select the sound mode: choose from: User, Standard, Music, Movie or Speech. 6. 0~9 Number buttons Press to select numbers such as TV channel. 7. FAV button Press to enter your favourite channel. 8.

  • Page 9: Remote Control Drawing

    Remote Control Remote Control Drawing teletext. 19. MENU button (under DVD mode) Press to enter disc menu in DVD mode. In teletext mode, press to disable teletext display for page updates and press again to resume. 20. SETUP button Press to enter DVD setup menu in DVD mode.
  • Page 10 Remote Control 29. SUBTITLE button 36. ANGLE button In DVD mode, press to select subtitle In teletext mode, press the button the first languages during playback if the disc time to double the size of teletext letters in contains multiple languages. the upper half of the screen, second to 30.

  • Page 11: Preparation Of Remote Control

    Remote Control Preparation of Remote Control Using of Remote control Softly push the back cover to open the battery Point the remote control unit from no more than compartment. about 7 metres from the remote control sensor and within about 60 degrees of the front of the unit.

  • Page 12: System Connections

    System Connections • Open the back cover on the right side of the unit’s rear panel. • Do not connect the power cord until all other connections have been made. • Ensure that you observe the colour code when connecting audio and video cables. Connecting to Power Supply Plug the power supply cord to the AC wall outlet.

  • Page 13: Connecting To External Av Signal Source

    System Connections Connecting to External AV Signal Source Use the AV cables to connect the external AV signal source to the AV input jacks on the rear panel of the unit. Use an S-VIDEO cable (not supplied) to connect the external AV signal source to the S-VIDEO input jack on the rear panel of the unit.

  • Page 14: Connecting To Earphone

    System Connections Connecting to Earphones Connect earphones (headphones) to the earphone jack on the rear panel of the unit for listening to the audio output in seclusion. ◆ The internal speakers output will turn off automatically after the earphones have been connected.

  • Page 15: Connecting To A Pc

    System Connections Connecting to a PC Follow the steps and figure below to connect a PC to the unit. Connect one end of the VGA cable to the VGA input jack on the rear panel of the unit and the other end to the PC.

  • Page 16: Connecting To A Tv Antenna

    System Connections Connecting to a TV Antenna Connect TV signal source from the aerial to the TV jack on the rear panel of the unit. After connection, turn on the power of the unit. Then press the SOURCE button to select TV mode and conduct program selection.

  • Page 17: Tv Function

    TV Function NOTE: In other mode, you can refer to the following instructions in TV mode to go on with some settings. Only when there are signals, the menus can appear and be set. Preparation 1. After connection, press the POWER button to turn on the unit. 2.
  • Page 18 TV Function Brightness Setup Press the ▲▼ button to select Brightness and press the ◄► button to adjust the value. Press the MENU button to return to the previous menu. Contrast Setup Press the ▲▼ button to select Contrast and press the ◄► button to adjust the value. Press the MENU button to return to the previous menu.

  • Page 19: Audio Setting

    TV Function Audio Setting Press the MENU button once to enter the setup menu. Press the ▲▼ button to select Audio and press the ENTER button to enter the menu shown right. In this setup menu, press the ▲▼ button to select the desired item.

  • Page 20: Timer Setting

    TV Function Sound Mode Setup Press the ▲▼ button to select Sound Mode and press the ENTER button to enter. Press the ▲▼ button to select the desired item and then press the ENTER button to confirm your selection. Press the EXIT button to exit from the menu.
  • Page 21 TV Function Tuner/Channel Press the ▲▼ button to select the Tuner/Channel and press the ENTER button to enter the menu shown right. Press the ▲▼ button to select the desired item. Press the EXIT button to exit from the menu. Country Press the ▲▼...
  • Page 22 TV Function Prog Organizer Press the ▲▼ button to select the Prog Organizer and press the ENTER button to enter the menu shown right. In the Prog Organizer setup menu, press the ▲▼ button to select the desired item. Press the EXIT button to exit from the menu.
  • Page 23 TV Function Manual Install Press the ▲▼ button to select the Manual Install and press the ENTER button to enter the menu shown on the right. In the Manual Install setup menu, press the ▲▼ button to select the desired item. Press the EXIT button to exit from the menu.
  • Page 24 TV Function CH No. Press the ▲▼ button to select CH No. and press the ENTER button to enter. Press the number buttons to enter the channel number. Press the MENU button to return to the previous menu. Store Press the ▲▼ button to select Store and press the ENTER button to store the above operations. Note: The “CH No.”...

  • Page 25: Teletext Function

    TELETEXT Function Teletext is an optional function, therefore only the sets with the teletext system can receive the teletext broadcast. Teletext is a free service broadcast by most TV stations which provides up-to-the-minute information on news, weather, television programs, stock prices and many other topics. The teletext decoder of this TV can support the SIMPLE and FASTEXT systems.

  • Page 26: Nicam Function

    NICAM Function The unit supports NICAM function when in TV mode. Under NICAM TV broadcast: 1. When receiving stereo audio signals, press the STEREO/AUDIO button on the remote control repeatedly to select the sound tracks between Nicam Stereo and Mono and the screen will show the corresponding display as shown below: 2.

  • Page 27: Dvd Playback Operation

    DVD Playback Operation Preparation Connect the unit to the power supply and press the POWER button to turn on the unit. Press the SOURCE button and select DVD mode. Holding the disc with its printed side outward vertically to the disc tray and gently insert the disc into the disc tray slot.
  • Page 28 DVD Playback Operation Previous and Next Press the button to go to the next chapter. Press the button once to return to the beginning of the current chapter or track; press it twice to go to the previous chapter or track. Fast Playback Press the button on the remote control to activate fast backward or forward playback.
  • Page 29 DVD Playback Operation Various Camera Angles The movies on some discs have been recorded from various camera positions, which can make you enjoy the same scene from different perspectives. When playing a disc containing various camera angles, the camera symbol appears on the screen. Press the ANGLE button repeatedly until the desired perspective is shown.

  • Page 30: Jpeg Playback

    DVD Playback Operation JPEG Playback JPEG is a common picture format that requires small amounts of storage per image and has low loss in resolution. Hundreds of pictures can be stored on a disc in this format. In order to view JPEG photo albums, you can ask your film development company to make a ”PICTURE CD”...

  • Page 31: Divx Playback

    DVD Playback Operation Picture Rotation This can be used only when the picture is normally displayed. Once another picture is selected, rotation will be cancelled automatically. Use the button to rotate the picture. Some JPEG disc’s may not support the rotating function. DIVX Playback DIVX is the name of a revolutionary new video code, which is based on the new DIVX compression standard for video.

  • Page 32: Usb And Sd/Ms/Mmc Card Function

    USB and SD/MS/MMC Card Function Preparation In DVD mode, connect USB device to the USB port or insert SD/MS/MMC card into the SD/MS/MMC card slot on the right side of the unit. Note Make sure that files are stored on USB device or the SD/MS/MMC card before connection. File Playback Press the CARD button to select disc playback, USB playback or SD/MS/MMC playback.

  • Page 33: Dvd System Setup

    DVD System Setup Preparation In DVD mode, press the SETUP button to open DVD setup menu. Press the button to select setup menu Press the SETUP button again to exit from DVD setup menu. General Setup Page Press the SETUP button to enter General Setup Page and the screen will display as below: 1.
  • Page 34 DVD System Setup OSD Lang 1. Press the button to select OSD Lang. 2. Press the ENTER button to enter. 3. Use the button to select items. 4. Press the ENTER button again to confirm selection and return to the previous menu. Captions 1.

  • Page 35: Audio Setup Page

    DVD System Setup Media Center 1. Press the button to select Media Center. 2. Press the ENTER button to enter. 3. Use the button to select DVD, USB, SD/MMC or MS. 4. Press the ENTER button again to confirm selection and return to the previous menu. Audio Setup Page Press the SETUP button to enter General Setup Page and then use the buttons to select...
  • Page 36 DVD System Setup Dynamic 1. Press the button to select Dynamic. 2. Press the ENTER button to enter. 3. Use the button to adjust. 4. Press the ENTER button again to confirm setting and return. 5. Press the button to return. HDCD Setup On the Audio Setup Page, use the direction buttons to select HDCD Setup.
  • Page 37 DVD System Setup Video Quality Setup Select Quality in the Video Setup Page, press the ENTER button to enter the menu as below: 1. In the menu, use the button to select the desired item. 2. Press the ENTER button to enter the item. 3.
  • Page 38 DVD System Setup DivX VOD Setup Select DivX VOD in the Video Setup Page, press the ENTER button to enter the menu as below: Note: Your registration code is: XXXXXX. Please this code to register this player with the DivX(R) video On Demand Service. This will allow you to rent and purchase videos using the DivX(R) video On Demand format.
  • Page 39 DVD System Setup Subtitle 1. Press the button to select Subtitle. 2. Press the ENTER button to enter. 3. Press the button to select Subtitle language. 4. Press the ENTER button again to confirm setting and return to the previous menu. Disc Menu 1.

  • Page 40: Troubleshooting

    Troubleshooting SYMPTOM CHECK ITEM There is no display on the Make sure the unit is turned on and all connections are screen. correct. Make sure the unit is turned on and all connections are correct. There is no sound. Make sure the volume is not turned down or muted. Make sure the sound setup is correct.

  • Page 41: Specifications

    Specifications TFT-LCD Resolution 1024 x 768 TFT-LCD Screen Size 15 inches AC100～240V，50/60Hz Power DC 12V Power Consumption < 60W Dimension 388mm × 176mm × 372mm（LXWXD） Weight About 5.8 Kg Ambient Temperature 10~45℃ DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Manufactured under license from Dolby Laboratories.
