- Page 1 LCD TV TFTV-430 USER'S MANUAL PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888...
-
Page 2: Table Of Contents
Contents Safety Precautions ......Important Safety Instructions ............Overview of TV i. Panel Description ................. ii. Back Panel Description ..............Antenna Connections ..............Connections i. AV Connections ................ii. DVD Player Connection ............... iii. PC Connections ................Remote Control Overview (All Functions Except Teletext) ..... Remote Control Overview (Teletext Functions) ...... -
Page 3: Safety Precautions
NOTE TO CABLE/TV INSTALLER: Do not attempt to modify this product in any way This reminder is provided to call the cable TV without written authorisation from PALSONIC system installer's attention to Article 820-40 of Corporation Pty Ltd. Unauthorised modification the National Electric Code (U.S.A.). -
Page 4: Important Safety Instructions
Important Safety Instructions 1. Read These Instructions - All the safety and 12. Use only with the cart, stand, tripod, bracket, operating instructions should be read before the or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use product is operated. - Page 5 Important Safety Instructions 23. Outdoor Antenna Grounding - If an outside 17. Power Lines - An outside antenna system should not be located in the vicinity of overhead power antenna or cable system is connected to the product, be sure the antenna or cable system is lines or other electric light or power circuits, or grounded so as to provide some protection against where it can fall into such power lines or circuits.
-
Page 6: Overview Of Tv
Panel Description Overview of TV Press to display the menu of the available viewing sources. Press to display the OSD menu. Press to change the channel. The two buttons also act as direction buttons. Press to adjust volume level. The two buttons also act as direction buttons. Turn on/off the TV. -
Page 7: Back Panel Description
Back Panel Description Overview of TV Headphone Power Input Antenna Jack S-Video or Composite input Progressive input RGB input AV input... -
Page 8: Antenna Connections
Antenna Connections * For optimum picture quality, adjust antenna direction. Indoor Antenna Connections Typical Wall antenna jack used in apartment buildings, connect the antenna cable as shown below (Please use the correct type of antenna cable according to the type of wall antenna jack). 75 ohm Round Cable Bronze Wire 300 ohm Flat Wire... -
Page 9: Av Connections
AV Connections (Yellow) (White) (Red) Camcorder Disc Player Notes: You can connect the TV set with Disc player, Camcorder and VCR following the methods below : 1: S-Video Cable + Audio Cable. Please choose "S-Video" when you select the viewing source. 2: Video Cable + Audio Cable. -
Page 10: Dvd Player Connection
DVD Player Connection (White) (Red) (White) (Red) DVD Player Notes: Please refer to the methods below to connect TV with DVD Component signal: 1. Connect YCbCr Cable and Audio Cable to corresponding Jacks of DVD Please choose the "YCbCr" when you select viewing source. 2. -
Page 11: Pc Connections
PC Connections Set-top Box Notes: Please refer to the upward method to connect TV with set-top Box or PC. 1. Connect VGA Cable and Audio Cable to the corresponding jack of PC or Set-top Box. Please choose "PC" or "YPbPr" when you select viewing source. -
Page 12: Remote Control Overview (All Functions Except Teletext)
Remote Control Overview (All Functions Except Teletext) MUTE Power button Display status Numeric buttons One/double/tri-digit select Previous channel Channel list Select different viewing signals Enter OSD setup mode Exit Enter Next/previous channel Volume up/down Sound mode selection Dual sound selection Select image display mode To freeze current image Aspect... -
Page 13: Remote Control Overview (Teletext Functions)
Remote Control Overview (Teletext Functions) On Screen Display Power ON/Standby button Sound Off Teletext Page Up Teletext Cancel Teletext Index Teletext Page Down Teletext List/Flof Teletext Display/Mix Teletext Reveal Teletext Store Teletext Size Teletext Hold Teletext Sub-Page -11-... -
Page 14: Remote Control Operation
Remote Control Operation Batteries installation Remote control direction Point the remote control at the remote sensor. Pull the battery cover upward in the direction shown by the arrow and remove it. Insert the batteries with correct polarity. Replace the battery compartment cover. -
Page 15: Basic Operation
Basic Operation Turn On/Off 1. Connect the antenna cable to the antenna input port on TV. 2. Connect the adapter to the power input port on TV. 3. Put the power line plug into the jack of adapter. 4. Plug the power cord into the wall power outlet after connecting the power cord to the adapter. Then the TV will be in standby mode. -
Page 16: Menu Description
Basic Operation Menu Description If you want to adjust the display settings, please follow the instruction below. Press the "MENU" button to browse the PICTURE MENU, TV MENU,OPTION MENU, PC MENU in turn. Press "EXIT" to quit menu mode. Picture Option Picture Option... -
Page 17: Menu Operation
Picture Menu Menu Operation Display Performance Adjust You can adjust brightness, contrast and colour to meet your favourite picture requirement. Picture Option Press the "MENU" button to select " Picture" mode. Brightness Press " " buttons to select the item you want to adjust. Contrast Colour Press "... -
Page 18: Tv Menu
TV Menu Menu Operation Channel Setting --- Auto Searching You can set TV program list with Auto Searching function quickly. Press the "MENU" button to select "TV" mode. Press the " " buttons to select "Channel Preset". Channel Preset Press the " "... - Page 19 TV Menu Menu Operation Channel Setting --- Fine Tune "Fine tune" helps you adjust specific programs image and sound quality. Press the "MENU" button to select "TV" mode. Press the " " buttons to select "Channel Preset". Channel Preset Press the " "...
- Page 20 TV Menu Menu Operation Channel Setting --- TV system switch You can also set program list one by one by "Manual searching" function. Press the "MENU" button to select "TV" mode. Press the " " buttons to select "Channel Preset". Press the "...
- Page 21 TV Menu Menu Operation Channel Setting --- TV system switch You can change TV system by yourself if necessary. Press the "MENU" button to select "TV" mode. Picture Option Channel Preset Press the " " buttons to select "Channel Preset". Channel Exchange Program Skip Channel...
- Page 22 TV Menu Menu Operation Channel Setting --- Channel Exchange If you'd like to exchange the two channels, please use "Channel Exchange". Select current channel from one of the two channels to Picture Option be exchanged. Press the "MENU" button to select "TV" mode. Channel Preset Press "...
-
Page 23: Option Menu
Option Menu Menu Operation Option Setting --- OSD setting If you want to change the OSD setting, please enter this menu. Press "MENU" button to select "Option" mode. Picture Option Select "OSD Set" item, press " " button to enter. OSD Set Press "... -
Page 24: Option Menu
Option Menu Menu Operation Option Setting --- Colour Temperature Adjust You can change colour temperature to get a better image effect according to the current circumstance. Press "MENU" button to select "Option" mode. Picture Option Press " " buttons to select "Display Setting". OSD Set Timer Setting Display Setting... - Page 25 Option Menu Menu Operation PIP Function PIP means picture in picture, the unit can display a sub window on the screen, which displays the program from another video source. This feature is valid when Main Window is in PC mode. You can watch TV or other video on the sub window.
- Page 26 Option Menu Menu Operation Display Performance Adjust In "PIP" mode, you can adjust sub window as follows. Press the "MENU" button to select "Option" mode. Picture Option Press the " " buttons to select "Display Setting". OSD Set Timer Setting Display Setting Teletext Setting Select "PIP Setting"...
- Page 27 Option Menu Menu Operation Option Setting --- Auto Adjust You can use this function to adjust the display setting automatically. Picture Option Press "MENU" button to select "Option" mode. OSD Set Press " " buttons to select "Display Setting". Timer Setting Press "...
- Page 28 Option Menu Menu Operation Option Setting -- Teletext Setting In Teletext mode, you can enter the menu and set Teletext language and region. For the other operations, please refer to page 32. Press "MENU" button to select "Option" mode. Picture Option Press "...
-
Page 29: Pc Menu
PC Menu Menu Operation PC Mode Note: You should set the video signal to "PC" mode before adjusting PC mode setting. Press "MENU" button to enter " PC " mode. Press" " buttons to select the item to be changed. Press "... -
Page 30: Functional Button Instruction
Functional Button Instruction Mute MUTE Press the button to mute audio, press again to resume. Volume Adjustment Press "VOL+" button to increase the volume; VOL+/- Press "VOL-" button to decrease the volume. Use the numerical buttons to select the channel directly Press this button one time to display "--"on the screen, the channel range will be 00-99. - Page 31 Functional Button Instruction Browse the channel list Press "CH-LIST" button, the Channel list will be displayed on screen. CH-LIST Channel list 0 CCTV5 5 CV 6 CCT 1 CCTV1 Current channel 2 CCTV2 7 CC 3 CCTV3 8 CTV2 4 CCTV4 9 CC3 Use direction buttons to select specific channel.
- Page 32 Functional Button Instruction Exchange Channel You can also exchange two channels as follows. CH-LIST Press the "CH-LIST" button ,the channel list will be displayed on the screen. Channel list 5 CV 0 CCTV5 1 CCTV1 6 CCT 2 CCTV2 7 CC Current channel 3 CCTV3 8 CTV2...
- Page 33 Functional Button Instruction Freeze Image FREEZE Press the button to freeze the current image, press it again to exit the freeze mode. Note: Not available in PC&YPbPr modes. Image effect adjustment After pressing "IMAGE" button, the following window will be displayed on the IMAGE up-left corner of the screen: Image effect...
-
Page 34: Teletext
Teletext Teletext is an information system broadcast by certain channels which can be consulted like newspaper. It also offers access to subtitles for viewers with auditive problems or those who are not familiar with the transmission language (cable networks, satellite channels, etc.). Teletext Language Selection. - Page 35 Teletext STORE You can store four page numbers in the current channel by pressing Store and numerical buttons. 1. Select the LIST mode using the List/Flof button, then four 3-digit numbers are displayed in different colours. 2. Press the colour buttons of corresponding page that will be replaced. 3.
-
Page 36: Play Flash Memory Card
Play Flash Memory Card Play Flash Memory Card You can enjoy the pictures in your flash card with the TV directly. Several formats files can be played. Flash Memory Card Flash memory card is a small, portable and universal IC recordable card, which has lager memory capacity than floppy disk. - Page 37 Play Flash Memory Card Play Music 1. Insert flash memory card into the card slot. Press the "SOURCE" button to display the main menu and select "Flash Card" with direction buttons. Then press "ENTER" button to confirm. 2. The following menu will be displayed on the screen: 0:02:40 MENU Root...
- Page 38 Play Flash Memory Card Select a folder -- Dirl, then press" ENTER" button and the screen will display as follows. MENU Dir1 Dir2 JPEG Dir4 MODE Folder Normal PLAY/PAUSE Press " " button to pause the slide show. Press " "...
-
Page 39: Stand Uninstallation
Stand Uninstallation Please follow the instructions given. 1. Lay the LCD TV/Monitor face-down on a flat surface with a cushion or other soft materials to protect the screen. 2. Remove all cables connected on the TV/Monitor 3. Remove the four screws and then remove the stand from the LCD TV/Monitor. 4. -
Page 40: Maintenance
Maintenance Care for your TV Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have with your TV. Be sure to turn the power off and pull out the plug before you begin any cleaning. Screen Cleaning Here is a great way to keep the dust off your screen for a while. -
Page 41: Trouble Shooting
Trouble Shooting Please read this user's manual before using the TV set. If you have any troubles in using this TV set, try to solve it by the suggestions mentioned below. If you can not remove the trouble after adopting corresponding suggestions, please contact the technical service centre or dealer authorised by us. -
Page 42: Specifications
Specifications Input: AC 110 - 240V, 50Hz/60Hz Power Supply Output: DC 12V / 4A Standby: <3W Power Consumption Max: 50W Horizontal: 30 - 80KHz Frequency Vertical: 50 - 75Hz NTSC / PAL/SECAM Colour System Sync.: H/V Separate, TTL, P. or N. Video Signal: 0.7Vp-p, 75ohm Audio in: RCA JACK (MR) , 0.5Vrms (-9dB) Audio... - Page 43 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 FKV2.037.880SSE...
