- Page 1 Model: TFTV386BK USER’S MANUAL PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 38cm LCD TV/Monitor D-SUB INPUT (VGA)
-
Page 2: Table Of Contents
Contents CONTENTS Chapter 1. Important Safeguards ........Chapter 2. Specification ..........Connecting Power ......... Chapter 3. Chapter 4. Remote Control ..........Chapter 5. Menu Operation ..........AVS - Video, Scart ......... Audio Menu ............ Setup Menu ........... VGA ............... TV ..............Image Menu .......... -
Page 3: Chapter 1. Important Safeguards
Chapter 1. Important Safeguards Safety Precautions Disconnect the Power cable when not using the TV for a Long Time. Do not open the TV. Contact your dealer if the TV is not operating properly. Do not press hard with your finger or scratch with sharp objects on the surface of the LCD. - Page 4 Chapter 1. Important Safeguards Safeguards When you clean the TV and the surface of LCD panel be sure to pull the plug from the Wall outlet. Use a Soft Cloth instead of using damp duster. Do not use any chemicals such as industrial polisher, abrasive solution, wax, benzene, alcohol, or cleaning detergents.
- Page 5 Chapter 1. Important Safeguards Safety Precautions Incase of any smoke or abnormal noise, immediately stop using the product and pull the power cord from the wall outlet. Then call your local dealer or service representative for assistance. Optimal temperature conditions are 5 , Humidity 30% - 80%.
-
Page 6: Chapter 2. Specification
Chapter 2. Specifications Specification Display TFT-LCD Aspect Ratio: 4:3 Resolution: 1024 x 768 Screen Size: 15 inch (diagonal) Audio Power Amp: 3 Watts x 2 (RMS) Resolution: XGA (60Hz)1024x768 PC Compatibility Auto Size and Position Adjustment Brightness and Contrast Control Phase Control Sharpness Control Display Modes: 4:3... -
Page 7: Chapter 3. Connecting Power
Chapter 3. Connecting Power Connect the AC Cord as follows: 1. Connect the AC Cord to the Adapter. 2. Connect the Adapter (DC12V) to the terminal (DC12V) of the Unit. 3. Connect the AC Cord to the wall socket. 4. Connect the Aerial lead to the TV RF input 5. - Page 8 Chapter 3. Connecting Power Familiarizing Yourself with the Keys TFT-LCD Display Speaker Grille Power Indication LED and Remote Sensor INPUT: Change Input Mode (VGA/TV/SCART/CVBS/S-VIDEO) MENU: OSD Menu Display/I Hide. CH+: Up highlight bar to selection, Channel increase. CH-: Down highlight bar to selection. Channel decrease.
-
Page 9: Chapter 4. Remote Control
Chapter 4. Remote Control POWER Switch on LCD TV when at standby mode or vice versa. MUTE Press to mute the sound. Press again or press VOL+ to unmute. NUMBER BUTTONS Press 0-9 to select a TV channel directly when you are watching TV. - Page 10 Chapter 4. Remote Control THUMBSTICK ( / ENTER) Allows you to navigate the on-screen menus and adjust the system settings to your preference. EXIT Clears all on-screen displays and returns to TV viewing from any menu. MENU Brings up the main menu to the screen. AV/TV Press to cycle through the input source in following: VIDEO...
-
Page 11: Chapter 5. Menu Operation
Chapter 5. OSD Menu Operation AV, S-VIDEO, DVD NOTE: In this manual,the 0SD (On screen display) may be different from your TV's because it is just example to help the TV operation. Image Menu Picture Remark Scheme Brightness Contrast Hue (NC) Saturation Sharpness Colour Temp... -
Page 12: Setup Menu
Chapter 5. OSD Menu Operation 1. Press MENU: 2. Press to select sub-menu, and press ENTER to enter,and press to change. 3. Press MENU return to main menu. Image Menu Picture Remark Auto Adjust H Position V Position Phase Clock Auto Colour Press to adjust. - Page 13 Chapter 5. OSD Menu Operation Setup Menu Picture Remark OSD Language OSD Position OSD Time DCDi Factory Reset Enter the OSD Language then to select one of the language. Selecting OSD Position item then press right button enter to adjust OSD Position as follows: Select Input Source Menu Remark...
-
Page 14: Tv Set Menu
Chapter 5. OSD Menu Operation Image Menu Picture Remark Scheme Brightness Contrast Hue (NC) Saturation Sharpness Color Temp Enter the Scheme,and there are four modes: Normal/Vivid/Sports/Nature. The Hue item is disable but at NTSC system. Enter the Color Temp, and there are three modes: Cool/Warm/Standard. TV Set Menu Picture Remark... - Page 15 Chapter 5. OSD Menu Operation Press Right button enter to auto search as follow, press MENU/EXIT button to stop it Press Right button enter channel swap as follow NOTE: The Audio and Input Source Menu of TV are the same as AV's...
-
Page 16: General Troubleshooting
Chapter 6. General Troubleshooting General Troubleshooting SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION The DC power cord is Connect the DC power cord to No power not connected the DC outlet The switch is switch off Switch on the switch TV station experiencing Try another channel problems Picture setting is not... - Page 17 Chapter 6. General Troubleshooting PERSONAL COMPUTER SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION The computer is in power saving mode. Try Pressing any key on the computer key board. Check the computer power is "on". The No Signal message No picture appears on the screen Check the cable is properly connected.
- Page 18 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 P/N: 11117863...
