- Page 1 TFTV5027FL 1080p 1080p Full HDTV Resolution Full HDTV Resolution...
-
Page 2: Table Of Contents
Table Of Contents Important Safety Instructions............................2 View of Unit.................................... 4 Front Panel and Right Side Panel..........................4 Rear Panel..................................5 Remote Control..................................6 Remote Control Drawing..............................6 Preparation of Remote Control............................8 Using of Remote control..............................8 System Connections................................9 Connecting to the Power Supply............................ -
Page 3: Important Safety Instructions
Important Safety Instructions Thank you for choosing our product. Please read this manual carefully and observe all safety and operating instructions. Store the manual in a safe place for later reference. This symbol indicates that dangerous voltage instituting a risk of electric shock is present within this unit. - Page 4 Important Safety Instructions NOTES: Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use near water. Clean only with dry cloth. Do not block any ventilation openings. Maintain well ventilated conditions around the product. Do not put product on a bed, sofa or anything that blocks ventilation. Install according to the manufacturer’s instructions.
-
Page 5: View Of Unit
View of Unit Front Panel and Right Side Panel Color TFT screen Presents high resolution picture. POWER button Press to switch on or off the device (enter or exit the standby mode). VOL◄ ►buttons Press to decrease or increase the volume. When in setup menu, this button also serves the ◄►... -
Page 6: Rear Panel
View of Unit Rear Panel COMPONENT Input Jacks COAXIAl OUT Jack Connecting for the COMPONENT input Output the coaxial digital audio signal. in YPbPr mode. COMPONENT shares USB Port the same audio jacks with COMPOSITE. Connect the USB device. VGA AUDIO IN Jacks HDMI1/HDMI2/HDMI3 Input Jack Connecting for VGA audio signal input. -
Page 7: Remote Control
Remote Control Remote Control Drawing 5. SUBTITLE button In DTV/DVD mode, press to select alternate subtitle languages during view/playback of a DTV program. 6. TV.RADIO button Press to select DTV program playback or Radio program playback in DTV mode. 7. Direction buttons (▲▼◄►) In the setup menu, press the ▲▼... - Page 8 Remote Control 27. DISPLAY button In teletext mode, it is the teletext color button. Press to display the reference information of the current mode. Other defined functions on the OSD menu. 28. REC LIST button 16. TV/TXT Press to display the Record List. Press to change the mode between TV 29.
-
Page 9: Preparation Of Remote Control
Remote Control Using of Remote control Preparation of Remote Control Point the remote control unit from no more Softly push the back cover to open the than about 7 meters from the remote control battery compartment. sensor and within about 60 degrees of the Insert two batteries (1.5V, size AAA), front of the unit. -
Page 10: System Connections
System Connections Do not connect the power cord until all other connections have been made. Ensure that you observe the color code when connecting audio and video cables. Connecting to the Power Supply Connect the plug of the power cord on the rear panel of the unit to the AC 100~240V wall outlet. -
Page 11: Connecting To An External Hdmi Signal Source
System Connections Connecting to an External HDMI Signal Source Connect an HDMI signal source to one of the HDMI jacks on the rear panel of the unit. After connection, turn on the power of the unit and the HDMI signal source. Press INPUT then direction buttons to select HDMI 1, HDMI 2 or HDMI3 mode, and then press the OK button to confirm. -
Page 12: Connecting To Composite Input
System Connections Connecting to COMPOSITE Input Use the AV cables to connect the external AV signal source to the AV input jacks on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source. -
Page 13: Connecting To A Pc
System Connections Connecting to a PC The unit can be connected to a PC via the VGA cable and PC audio cable. Connect one end of the VGA cable to the VGA jack on the jack panel of the unit and the other end to the PC VGA output. -
Page 14: Connecting To Tv-Signal Input
System Connections Connecting to TV-Signal Input Connect the TV signal cable (the antenna cable, for example to the RF Jack on the back of the unit so that you can receive television programs. Connect TV signal input source from the aerial to the RF jack on the rear panel of the unit. After connection, turn on the power of the unit. -
Page 15: Basic Operation
Basic Operation Turning the TV On and Off Connect the power adapter to wall AC Outlet. A front mounted indicator light will be illuminated red indicating the TV has power. Press the POWER button on the remote control or the TV set. The TV’s indicator light will ... -
Page 16: Tv Operation And System Setup
TV Operation and System Setup Press the MENU button to display the setup menu. It includes different categories, such as Picture, Sound, Channel, Feature and Setup. You can change the category using the ▲▼ buttons and press OK button or the ►button ... -
Page 17: Sound
TV Operation and System Setup Sound The sound settings include the options for Sound Mode, Treble, Bass, Balance, Surround Sound, EQ Setting, AVL and SPDIF. Sound Mode Press the ▲▼ buttons to highlight Sound Mode and then press◄► buttons to select Standard, Music, Personal, or Movie. -
Page 18: Channel
TV Operation and System Setup Channel CHANNEL includes Auto Scan, Manual Scan,Channel Edit and Signal Information. NOTE: The Channel category is only active in DTV and ATV mode. Channel Edit The option “Channel Edit” includes Delete, Skip, Rename and Move. Delete a program: ... - Page 19 TV Operation and System Setup Auto Scan Select this item and press the OK or ► button to enter the submenu. Press the ▲▼buttons to highlight Country or Mode and press ◄► buttons to adjust, then press▲▼button to select Start and press OK or ► button to start scanning. A new window appears on the screen, where the status of the searching is documented.
-
Page 20: Lock
TV Operation and System Setup Lock The Feature settings include the options for Enable, Channel Locks, Lock Keypad, Clear Lock, etc. Note: before you can change the settings, you have to insert the preset password to enter the menu. The default is 0000. Lock Enable Press the ◄►... - Page 21 TV Operation and System Setup Mode Setting Press the ▲▼ buttons to select Mode Setting and press the◄► buttons to adjust. Time Settings Press the ▲▼ buttons to select Time Settings and press the OK or ► button to enter the submenu.
-
Page 22: Media Playback
Media Playback This unit is designed with a USB ports so that you can connect your USB device and playback the files in the USB device. NOTES: The recognition speed of a USB storage device may depend on each device. ... -
Page 23: Function Buttons
Media Playback 3. In the Music submenu as shown right, press the▲▼ direction button to select your storage device and press the OK button to open it. The songs list will appears. In the songs list, you can use the ▲▼buttons to select one of them and press the OK or button to play the song you have selected as shown below: If you want to exist the USB mode, you can press the INPUT button, and press... -
Page 24: Troubleshooting
Troubleshooting SYMPTOM CHECK ITEM Make sure the system connection is correct. Make sure the speakers are not muted. There is no sound. Set the correct sound mode. Is your disc dirty or warped? If so, clean or replace it. Make sure the unit is turned on and the connections are LED has no display. -
Page 25: Specifications
Specifications Model TFTV5027FL Screen Size 50-inch LED Native Resolution 1920 × 1080 Pixels Brightness 270 cd/ m Contrast Ratio 4000 :1 Response time (ms) 8 ms Teletext 1000 pages Speaker Output 8W+8W Power Consumption <100 W Standby Power < 1 W Dimension (with stand) 1133mm ×... - Page 26 Palsonic Customer Service Telephone (Australia) 1300 657 888 Palsonic C ABN 34 000 474 108 1 Joynton Avenue, Waterloo NSW 2017 Australia Telephone (02) 9313 7111 Facsimile (02) 9697 0655 www.palsonic.com.au...
