  • Page 1 LCD TELEVISION INSTRUCTION MANUAL TFTV68HDT TFTV81HDT TFTV81PBHDT TFTV93HDT TFTV106HDT...
  • Page 2 Precaution about LCD Panel Precaution with Manipulation • Refrain from strong mechanical shock and / or any force to the LCD panel. In addition to damage, this may cause improper operation or damage to the module and FFL(CCFL) back-light. • Note that the surface of LCD panel is very fragile and could be easily damaged. Do neither press nor scratch the surface harder than a HB pencil lead.
  • Page 3 Caution CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulat- ed “dangerous voltage”...

  • Page 4: Power Source

    Important Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. Read, Retain and Follow All Instructions Read all safety and operating instructions before operating the TV. Retain them safely for future reference.

  • Page 5: Replacement Parts

    Important Safeguards 13. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
  • Page 6 Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user's own safety, and the proper operation of the product. Ignoring or disregarding the contents of this section and Warning improper operation of this product may result in the person’s death or serious injury...
  • Page 7 Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user's own safety, and the proper operation of the product. Ignoring or disregarding the contents of this section and Caution improper operation of this product may result in the person’s death or serious injury...

  • Page 8: Table Of Contents

    Table of Contents Installation and Maintenance Antenna Connection Video Connection Camcorder & Video Game Connection DVD Player Connection STB Connection PC Connection Cable TV Broadcasting Connection Connect with the Dolby Digital AMP Name of Each Part Basic Guide Parts of the Remote Controller Method To Use Basic Menu To Watch TV Setting Up TV Stations...
  • Page 9 Supplied Accessories Make sure that the following accessories are provided with the product. AC cord AC cord Instruction manual Remote controller Batteries...

  • Page 10: Antenna Connection

    Antenna Connection Indoor Antenna Connection 1. Connect the feeder cable of the antenna to the combining adapter. WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong antenna connection. Be sure to check its direction and place when installing.
  • Page 11 Antenna Connection CTV Antenna Connection Such community TV Antenna installation may be found in most of co-op apartments. When a coaxial cable is used: Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right.

  • Page 12: Outdoor Antenna Connection

    Antenna Connection Outdoor Antenna Connection Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses Single Antenna Connection VHF Antenna BACK OF THE TV SET UHF Antenna ANT/CABLE Separate Antenna Connection. In case of coaxial cable In case of feeder cable ANT/CABLE Antenna combining...

  • Page 13: Video Connection

    Video Connection Connecting with an External Source You may connect an S-Video 1 (Rear of the TV) or S-Video 2 (Side) input to enjoy clearer and brighter picture images. You can make the connection with the AV1 or AV2 inputs. BACK OF THE TV SET VIDEO Note: If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection...

  • Page 14: Camcorder & Video Game Connection

    Camcorder & Video Game Connection Watching the Camcorder Recording or Video Game on TV 1. Prepare the S-video and RCA connector. 2. These connectors connect to AV1 or AV2 (S-Video 1 or 2) like below the picture. 3. Turn on the TV set and camcorder/video game. 4.

  • Page 15: Dvd Player Connection

    DVD Player connection When connecting with a component cable BACK OF THE TV SET Note: When you connect with the component video, please check the colour of the cable between the DVD and TV set. When connecting with a S-VHS cable and RCA cable BACK AND SIDE OF THE TV SET SERVICE INPUT L-AUDIO-R...

  • Page 16: Stb Connection

    STB (Set Top Box) Connection When connecting with a HDMI cable BACK OF THE TV SET Set Top Box Note: When the Set Top Box output is DVI signal, then the Audio cable should be connected. When connecting with a component cable BACK OF THE TV SET Set Top Box...
  • Page 17 Connection When connecting with PC (D-Sub) cable. 1. Adjust PC resolution to available resolution in LCD TV. 2. Connect between PC and TV set using the D-Sub and Audio cable like below the picture. 3. Turn on the PC and TV set. 4.

  • Page 18: Pc Connection

    Connection PC CONNECTION NOTES: 1) The resolution of the TV set is the best at 1360 z 768 (WXGA). 2) In order to display 1360 x 768 resolution, install the latest version of graphic card driver in your PC. 3) If there is a [Vertical Frequency] setting menu in the [Screen] Menu of the PC, adjust the frequency to 60Hz. 4) If the PC resolution is too high, it may be hard to read letters.

  • Page 19: Cable Tv Broadcasting Connection

    Cable TV Broadcasting Connection External Input Connection Source Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. You may make the connection to any of the Component input, Video 1 input and Video 2 input.

  • Page 20: Connect With The Dolby Digital Amp

    Connect with the Dolby Digital AMP. If you connect the optical output to the Dolby digital AMP, you can listen to better sound. BACK OF THE TV SET Optical output Dolby Digital AMP Woofer Centre Surround L Surround R...

  • Page 21: Name Of Each Part

    Name of Each Part Front / Side Panel Buttons on the TV set have the same functions as those of the remote controller. MENU Front Panel Side Panel (Left) Side Panel (Right) Control Key Buttons. Buttons: Each time you press this button, the TV will cycle through: TV / Video 1 / Video 2 / Component 1 / Component 2 / HDMI / PC MENU Button: Use this button to enter and exit the MENU.
  • Page 22 Name of Each Part Rear Panel...

  • Page 23: Parts Of The Remote Controller

    Parts of the Remote Controller (MUTE): Press this button, and the sound goes off. Press again, and the sound returns. (POWER): TV on/off button in Stand-By mode. DTV/ATV: Each time you press this button, the TV will cycle through : ATV => DTV (DVB-T) => ATV AV/COMP: Each time you press this button, the TV will cycle through: Video 1 =>...
  • Page 24 Parts of the Remote Controller RECALL : Display the present modes (ATV/DTV, Video 1/2, Comp. 1/2, PC/HDMI) and Signal information for 4 seconds. Note: In Analog TV mode, you can see information about the Programme number, Sound, and Clock. In DTV (DVB-T) mode, you can see information about a channel number, name, broadcasting time and more.

  • Page 25: Method To Use Basic Menu

    Method To Use Basic Menu Basic Menu - The basic menu appears on the screen if you press the “MENU” button of the remote control. - There are 5 items Picture, Sound, Install, Utilities and Time in the basic menu. - Each item has sub-items under it.

  • Page 26: To Watch Tv

    To Watch TV On/Off, Number, Mute, Recall, - Buttons with same name in the main body performs the same function. Press the " " button of the front or right side of the set or the "Power" button of Remote controller. You can also turn on the TV using “...
  • Page 27 To Watch TV 1. Press the " POWER)" button of the front or right side of the set or the "POWER" button of Remote controller. The Stand-By LED lamp turns on in red colour. POWER Press " " buttons of the main body or "POWER" button of the remote control.

  • Page 28: Setting Up Tv Stations

    Setting Up TV Stations Auto Programme for Analog Channel - All analog channels that can be received are stored by this method. It is recommended that you use Auto Programme during installation of this set. 1. Press the "MENU" button to select the Install menu. Mode Normal Brightness...

  • Page 29: Manual Programme

    Setting Up TV Stations Manual Programme The Manual Programme menu shows you information as follows: - Band, Channel, Search, Programme number Set ATS Broadcast Analog Auto Programme Start Picture 1. Locate the selection bar on the Manual Programme. Manual Programme Access Sound Programme Setup...
  • Page 30 Setting Up TV Stations Programme Setup (Analog TV mode only) 1. Searching for channel - f inely Move the selection bar to the Analog Pr with " " buttons. Programme Setup Analog Pr Picture Select a programme number you want to tune - f inely Name _ _ _ _ _ Fine...

  • Page 31: Programme Edit

    Setting Up TV Stations Programme Edit The Programme Edit menu shows you information as follows: - Broadcast : Analog / Digital - Program position assignment: Program number, Station name and Skip. Edit Analog 1. Skipping the program positions Picture - -- - -- - -- Move to Programme Edit in the Install menu.
  • Page 32 Setting Up TV Stations Favourite 1. Locate the selection bar on the Favourite. Set ATS Broadcast Analog Auto Programme Start Picture Move to Favourite in the Install menu. Manual Programme Access Sound Programme Setup Access Press the " " buttons. Programme Edit Access Install...

  • Page 33: Selection Of Av/Comp And Hdmi/Pc Input Signal

    Selection of AV/COMP and HDMI/PC Input Signal When watching video, Camcorder, DVD, Cable TV with AV - When pressing " " button on the TV set, screen changes as follows: DTV => ATV => Video 1 (or S-Video 1) => Video 2 (or S-Video 2) => Comp.1 => Comp.2 => HDMI => PC => DTV 1.
  • Page 34 Selection of AV/COMP and HDMI/PC Input Signal When connecting PC, STB, DVD with Multimedia 1. Pressing the "HDMI/PC" button on the remote controller. Screen changes as follows whenever pressing the “HDMI/PC” button. HDMI => PC => HDMI H D M I 1360 X 768P 60Hz 720 X 480 HDMI &...
  • Page 35 Selection of AV/COMP and HDMI/PC Input Signal Adjustment of Screen in PC mode 1. Press the "ASPECT" button. 2. Adjustment of the Auto setup PC Menu Press the "ASPECT" button and the PC Menu appears. Auto Setup AUTO Move to Auto Setup in the PC Menu. Frequency Phase Press the "...

  • Page 36: Screen Adjustment

    Screen Adjustment When setting up various screen modes - The user may select various screens designed for a good picture without adjusting the brightness, contrast or colour individually. 1. Pressing the "PICTURE" button. Screen changes as follows whenever pressing the "PICTURE" button. Normal =>...
  • Page 37 Screen Adjustment When adjusting the screen to taste - You can enjoy various screens by adjusting Brightness, Contrast, Colour, Sharpness, etc to the user’s taste. 1. Select "PICTURE" by pressing the "MENU" button. Mode Normal Brightness Picture The menu screen appears as follows. Contrast Sound Colour...

  • Page 38: Sound Adjustments

    Sound Adjustment When selecting various sound modes 1. Sound mode selects what you want. Press the "S-EFFECT" button, then the sound status changes as followed: Normal => User => Concert Hall => Live => Theater => Studio Balance Balance Picture Picture Effect Effect...
  • Page 39 Sound Adjustment When adjusting sound to taste - The user can enjoy various the sound by adjusting Balance, AVC, Effect, Equaliser and Digital Volume. 1. Adjust the Balance Balance Picture Move to Balance in the Sound menu. Effect Mode Theater Sound Adjust the balance level by using the "...
  • Page 40 Sound Adjustment 4. Adjust the Audio Equalizer Move to Balance in the Sound menu. Adjust User mode using the " " buttons. Balance Picture Select and use the relevant frequency by pressing the Effect Mode User Sound " " buttons. 100 Hz 300 Hz Install...
  • Page 41 Sound Adjustment Stereo and MPEG/Dolby Digital (Digital TV mode only) 1. Mono Sound Selection In Stereo reception if the stereo is weak, you can switch to MONO by pressing the " " button. The OSD character will be change to "F Mono". In Mono reception, the depth of sound is improved.

  • Page 42: Utilities

    Utilities Adjustment of Aspect ratio in TV/Video/Component mode 1. Press the "ASPECT" button The screen changes as below whenever pressing the "ASPECT" button. Wide [16:9] => Zoom 1 => Zoom 2 => Normal [4:3] 2. Adjust the Aspect ratio Aspect ratio Wide[16:9] Subtitle Move to Aspect Ratio in the Utilities menu.

  • Page 43: Set Password

    Utilities Subtitle (Digital TV mode only) 1. Setup of Subtitle Aspect ratio Wide[16:9] Move to Subtitle in the Utilities menu. Subtitle Picture Lock Access Select Subtitle to "On/Off" using the " VOL " button. Sound MGDI plus DEMO Demo Install Utilities Time Exit...

  • Page 44: Block Programme

    Utilities Lock 2. Block Programme Move to Block Programme in the Lock menu. Set password Access Block Programme Access Picture Press the " VOL " buttons to access the Block Parental guidance MENU Sound VOL- VOL+ Programme. Install Select a channel number that you wish to block by Utilities pressing the "OK/SELECT"...

  • Page 45: Child Lock

    Utilities Child Lock 1. Press the "LOCK" button The lock changes either On or Off whenever pressing the "LOCK" button. Note.: This prevents the use of the TV set without the remote control. If the Child Lock is "On", the set can only be switched back on using the remote control. Hotel Lock In the Hotel Lock mode, the Install menu is not displayed and the Volume controls is limited by 60.

  • Page 46: On Time Volume

    Utilities 3. Setting the On time / On time Setup / On time PR / Auto clock On time Volume Set Current time 12 : 00 A.M. Picture On time MENU Move to On Time in the Time menu. Sound On time setup 12 : 00 A.M.
  • Page 47 Utilities 4. Setting the Off time / Off time Setup Auto clock Set Current time 12 : 00 A.M. Picture Move to Off Time in the Time menu MENU On time VOL- Sound On time setup : 00 A.M. VOL+ Select the Off Time to "On using the "...

  • Page 48: Pip (Picture-In-Picture / Pop (Picture-Of-Picture)

    PIP (Picture-In-Picture)/ POP (Picture-Of-Picture) 1. Watching PIP/POP By pressing the "PIP/POP" button on the remote controller repeatedly, you can select one of the following settings: If you want to change the position of sub picture, press the "P.POSITION" button.
  • Page 49 PIP(Picture-In-Picture)/ POP(Picture-Of-Picture) If you want to swap main for sub, press the “P.SWAP” button. If you want to change sub screen input, press the “P.INPUT” button. Sub screen change as followed : PIP/POP table PIP/POP mode table. Video1 Video2 Comp.1 Comp.2 HDMI Main Video1 Video 2...

  • Page 50: Teletext

    Teletext Teletext SWITCHING TELETEXT ON/OFF Press the “TELETEXT” button ( The index page or the page viewed last will appear. Repeatedly press the “TELETEXT” button the mode in the following order: TV=> TELETEXT => TV NOTE: Teletext works only in TV/VIDEO mode. COLOUR BUTTONS IN TOP/FLOF TELETEXT A red, green, yellow and blue field is shown at the bottom of the screen.

  • Page 51: Channel Banner (Digital Tv Mode Only)

    Channel Banner (Digital TV mode only) Channel Banner - The channel banner displays information about a channel number, name, broadcasting time, audio service and more. You can see this banner by pressing "RECALL" button or " " buttons on the Remote Control.

  • Page 52: Electronic Program Guide (Epg)

    Electronic Program Guide (EPG) - The DTV Electronic Program Guide (EPG) displays program information about each channel, up to seven days ahead. - You can edit your own profiles, and record programs. - By pressing the "GUIDE" button to access EPG directly, you can see all channels broadcasting now.

  • Page 53: Troubleshooting

    Troubleshooting Symptoms and Solutions Please check the following items before asking for repair service. Symptom Check items Neither picture - Check the contact of sockets is all right. nor sound - Check the TV main power is on. Picture is OK - Check the Volume control is set to minimum or mute.
  • Page 54 Troubleshooting In DVB-T mode Some Problems will only occur when viewing DVB channels. Due to the different techniques involved in digital reception, DVB signal quality can be poor even if you appear to have a strong signal when viewing analogue porgrammes. The DVB system requires a good quality signal to provide the best picture.
  • Page 55 Troubleshooting In PC mode Symptom Check "Not available signal" - Check the resolution and frequency of your PC. Then, adjust them appears on to optimum condition for LCD TV. the screen. - Refer to the table of PC mode input format. (If registered resolution and frequency on the table no listed then no picture will be displayed.) "No signal"...

  • Page 56: Standard Of Product

    Standard of Product Screen Size 68cm 81cm 106cm 93cm LCD Panel Aspect Ratio 16:9 16:9 16:9 16:9 Resolution 1366 x 768 (WXGA) 1366 x 768 (WXGA) 1366 x 768 (WXGA) 1366 x 768 (WXGA) Pixel Pitch 0.4215mm 0.51075 mm 0.6810 mm 0.6000 mm 3000:1 Contrast Ratio...
  • Page 57 PALSONIC CORPORATION PTY. LTD. (Incorporated in NSW) 1 Joynton Avenue WATERLOO NSW 2017 Telephone: 02 9313 7111 - Fax: 02 9313 7555 48586300E10H-R0...
