Traynor YCS50 Service Manual page 4

Cabinet Impedance (ohms):
Power @ min. impedance (Watts):
Minimum Impedance (ohms):
Burst Power - 2 cycle:
Speaker Configuration - LF (Size / Power):
Channel 1 - inputs:
Channel 1 - controls:
Channel 1 - switches:
Channel 2 - inputs:
Channel 2 - controls:
Channel 2 - switches:
Channel Switching:
Master Volume Control:
Main Tone Controls:
Line Out (type / configuration):
Line Out Sensitivity (Vrms):
Effects Loop / Location:
Effects Footswitch / Function:
Effects Return Sensitivity (Vrms):
Internal Reverb / Effects:
External speaker output / location:
Dimensions (DWH, inches):
Dimensions (DWH, cm):
Weight (lbs / kg):
Specifications
Model: YCS50 / YCS50H / YCS90
Type: Combo / Head / Combo Guitar Amplifiers
8 / na / 8
50 / 50 / 90
4 ohms on all models
60 / 60 / 110
1 12-inch 60 watts / n.a. / 2 12-inch 120 watts
Input Channels: 1
1-1/4-inch shared with channel 2
Gain, Boost Level, Volume, Treble, Mid, Bass,
Reverb, Effects Return
Boost, Modern, Scoop
1-1/4-inch shared with channel 1
Gain, Volume, Treble, Mid, Bass, Reverb, Effects
Return
Bright, USA/Brit, Expander
2 Channels, Boost on Channel 1, Footswitchable
Yes
Presence, Resonance, Voice
Master Outputs: Preamp Out (TRS), D.I. Out (XLR), Effects Send
with Control (TRS)
Preamp Out (TRS), D.I. Out (XLR), Effects Send
with Control (TRS)
300 mV
Effects Volume: Master send, dual returns
Rear
Reverb and Effects Return Footswitchable
300 mV
Accutronics Dual Spring Long Tank
LED Indicators: Ch1, Ch2, Boost, Power/Standby
Protection: Mains Fuse
1 (rear panel)
Other Features:
Class A low power mode 15/15/25 Watts
10.5x25x21.5 / 10x27x11 / 10.5x27.5x21.5
27x64x55 / 25x69x28 / 27x70x55
48lbs./22kg / 38lbs./17kg / 51lbs./23kg
