Traynor YCS50 Service Manual page 3

1
2
5
6
7
*NOTE: Replacement grills 'Special-Order' and are only
available while the model is in production.
SERVICE-QuickGuide-ycs50-00-1v0.xls
3
2
4
2
18
17
6
8 9
10
# Part# Description
Labeled Components
1 8268 TRAYNOR LOGO PLASTIC NICKEL PLA
2 CORNER,2 LEGS NOTCED BLACK POWD
8570
3 8451 10" STRAP HANDLE,BLACK METAL EN
4 #4 X 1/4 PAN PH TYPE A ZINC / #10 WASHER
8770/8817
5 7081 12" 8R 60WPGM SPKR CELEST VI
6
3698 SPST ROKR SW QUIK 180" AC PWR B
7 3438 IEC PWR SOC W/.205TAB &FUSE 10A
8 3923 XLR MALE PCB MT HORZ MTHOLE-V SNAP
9
3450 1/4 ALL GOLD PC MNT JK SKT
10 8431 KNOB BUDGIE-BEAK
11 8633 KNOB ROUND PUSHBUTTON 1/4" BLAC
12 5881 6L6 TETRODE OUTPUT TUBE
13
12AX7 12AX7 DUAL TRIODE PREAMP TUBE
14
3731 SPRING RETAINER FOR OUTPUT TUBE
3902 72" RCA PREFAB CABLE STEREO
15
3552 NYLON SPRING CLAMP
16
3921
17 1/4" JCK PCB MT VERT STER RT SWT
18 8430 KNOB CHICKEN-BEAK
6397 JEWELED PILOT LAMP AMBER REG
19
8862/8817 #10 X 1 1/2 PAN PH TYPE A JS500 / #10 WASHER
20
21 8522 RUBBER BUMPER WITH WASHER -SMAL
22
3426 8' 3/16 SJT AC LINE CORD REMOVB
23
3537 ACC# 4EB3C1B LONG REVERB
24
TFS-2B TRAYNOR DUAL FOOTSWCH 10' CORD-
20
21
9
12 13
14
15
22
23
Reverb
24
Footswitch
11
19
18
11
16
Guitar Combo
9
