Operation
1. Room Temperature
Displays current ambient
temperature in the room.
2. Set Temperature
Displays and controls the heater
to the temperature at which the
thermostat is currently set to.
Press 8 to lower the thermostat
and press 9 to raise the
thermostat. Pressing both 8 and
9 together will toggle between
Celsius and Fahrenheit.
3. Flame Effect Icon
The flame icon will flicker if and
when the Flame Effect is turned
on. Press 11 to turn the Flame
Effect on, and press 10 to turn the
Flame Effect off.
4. Purifire™ Icon
The display arrows for the
Purifire™ will cycle when turned
on. Press 13 to turn the Purifire™
function on, and press 12 to turn
Purifire™ off.
! NOTE: The Purifire™ function
on this device will control only
18
those units with the Purifire™
installed.
5. Heat Off Indicator
This function manually overrides
the thermostat control and
prevents the fireplace's heater
from coming on.
To do this, press 8 to decrease
Set Temperature to any
temperature below 0
To reactivate heat from "HEAT
OFF" setting, press 9 to increase
the thermostat Set Temperature.
The Set Temperature will be
displayed starting at 21
replacing the "HEAT OFF" icon.
6. Function Lock Indicator
Enabling this function will lock out
the Wall Switch Remote Control
so as to prevent the current
settings from being changed.
To Enable, press 8, 9, and 10
sequentially. To disengage,
press 8, 9 and 10 sequentially
again. The Indicator icon will be
displayed when enabled.
C or 32
F.
o
o
C (70
F),
o
o
