Selecting Machines in Serial Deck
Control Mode
When using a Digidesign SYNC peripheral with
machines connected to each of its two 9-pin
ports, or to serial ports on the computer, use the
Peripherals dialog to choose which machine to
control.
To choose a machine for Serial Deck Control
mode:
In Pro Tools, choose Setup > Peripherals, and
1
click the Machine Control tab.
In the 9-pin Machine Control (Deck Control)
2
section, select Enable.
Choose SYNC 9-Pin Out 1 or SYNC 9-Pin Out 2,
3
or an available serial port from the Port pop-up
menu.
Choose the appropriate machine profile from
4
the Machine Type pop-up menu.
Click OK to close the Peripherals dialog.
5
Using Serial Time Code for
Positional Reference
If you are using a Digidesign SYNC peripheral
connected to your DigiSerial port, and your ma-
chine has 9-pin serial time code capability, you
can use serial time code for positional reference.
This will help achieve faster lockup times.
To use serial time code for positional reference, a
Video Reference signal must be present, as indi-
cated by the Ref Present indicator in the Session
Setup window. Both the SYNC peripheral and
the external machine should be locked to the
same video reference signal.
When using Serial Time Code for positional ref-
erence, you can regenerate LTC.
To enable Serial Time Code:
Choose Setup > Session.
1
Choose Serial Time Code from the Positional
2
Reference pop-up menu.
Choosing Serial TIme Code in the Session Setup window
To regenerate LTC when locking to Serial Time
Code:
Choose Setup > Session.
1
Choose Serial Time Code from the Positional
2
Reference pop-up menu.
In the Transport window, click the Gen LTC
3
button.
Gen LTC button in Transport window
