Using a Paddle Device in Local
Mode
When using MachineControl in Local mode
with or without an external synchronizer, you
can use a supported third-party paddle device to
issue the following Pro Tools track commands:
• Input monitoring
• Record Enable
• Record Safe
• Solo
• Solo Mute
See Chapter 7, "Using a Paddle Device in
Local Mode."
Remote 9-Pin Deck Emulation
Mode
With Remote 9-Pin Deck Emulation mode (also
called Remote 9-Pin mode), an external synchro-
nizer can take control over Pro Tools transport
and recording functions.
Pro Tools responds to commands sent by the
master 9-pin machine controller, but because
Pro Tools is in Remote mode, many of its trans-
port commands are locked out.
Remote and Remote/LTC Chase
Modes
When using an external machine controller to
control Pro Tools, you can configure Pro Tools
to emulate a 9-pin deck in either of the follow-
ing modes:
Remote mode Pro Tools emulates a device that
can be the time code master or time code slave.
Remote/LTC Chase mode Pro Tools emulates a
device that receives track and transport arming
commands, while chasing incoming LTC.
12 MachineControl Guide
Track Arming
In Remote Deck Emulation mode, you can arm
Pro Tools tracks from an external machine.
Features include remote control of individual
record enables for up to 48 tracks, with select-
able record protocol and mode. Included factory
and user programmable profiles let you config-
ure track arming for any machine type.
For arming tracks during playback, refer to
the TrackPunch feature description in the
Pro Tools Reference Guide.
