Volvo S40 Wiring Diagram page 156

Connectors
64/43:16-26 - 64/45
64/43
26-pin black
No. Passenger door harness
16 -
17 3/127A:8 Passenger Door Module (PDM),
RHD
18 3/127A:17 Passenger Door Module (PDM),
RHD
19 -
20 3/127A:9 Passenger Door Module (PDM)
21 3/127A:18 Passenger Door Module (PDM)
22 16/3:2 Speaker, passenger door
23 16/3:1 Speaker, passenger door
24- -
26
64/45
19-pin black
No. Left rear door harness
1 3/128:6 Left Rear Door Module (LDM)
2 6/117:4 Interior temperature sensor
3-8 -
9 3/128:18 Left Rear Door Module (LDM)
10 63/192A Branching point
11 3/260:1 Contact, locking, rear left
12 3/264:3 Contact, unlocking, rear left
13 3/76:3 Lock unit, left rear door
14 3/76:1 Lock unit, left rear door
15 3/76:2 Lock unit, left rear door
16 16/130:4 Antenna, rear left door lock
17 16/130:5 Antenna, rear left door lock
18 16/6:2 Speaker, left rear door
19 16/6:1 Speaker, left rear door
- -
BK 4/56F:31
BK 4/56F:28
- -
BK 31/116
BK 4/56C:24
BK 16/105B:3
64/112:12
BK 16/105B:11 Audio Module (AUD)
64/112:11
- -
BK 64/41:4
4/56F:21
BK
- -
BK 4/56C:21
BK 63/172
BK 4/93A:21
BK 4/93A:16
BK 4/93D:13
BK 4/93B:2
BK 4/93B:1
WH 4/93D:21
BK 4/93D:3
BK 16/105B:4
64/112:14
WH 16/105B:12 Audio Module (AUD)
64/112:13
TP3990202 S40 (04-)/V50 2006
Floor harness
Central Electronic Module
(CEM)
Central Electronic Module
(CEM)
Ground connection
Central Electronic Module
(CEM)
Audio Module (AUD)
Connector
Connector
Floor harness
Connector
Central Electronic Module
(CEM)
Central Electronic Module
(CEM)
Branching point
Keyless Vehicle Module (KVM)
Keyless Vehicle Module (KVM)
Keyless Vehicle Module (KVM)
Keyless Vehicle Module (KVM)
Keyless Vehicle Module (KVM)
Keyless Vehicle Module (KVM)
Keyless Vehicle Module (KVM)
Audio Module (AUD)
Connector
Connector
-
BK
BK
-
BK
BK
BK
WH
-
BK
BK-OG
-
OG-BU
BK
BN-GN
BN-YE
BN-WH
BN-BU
YE-BU
WH-GN
GY-OG
GY-WH
WH-VT
