Owner's Manual
Model
Digital Personal Monitor
Introduction
Thank you very much for purchasing the Model 6301D.
Model 6301D is the digital personal monitor with 10W of internal power amplifier and is
equipped with the digital input terminal (XLR-3-31 type) as well as the analog input
terminal (PHONE). Furthermore, the digital through terminal (XLR-3-32 type) can be used
to connect multiple 6301D.
Fully read this manual before using the unit so that you can use the unit properly.
