Active monitor speaker
6301ND/NX/NE/NB
Thank you for purchasing this Fostex product.
This manual provides instructions for basic use of the unit.
Read this before using the unit for the first time.
Owner's Manual
© FOSTEX COMPANY All Right Reserved
8588131000
(587416)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6301ND and is the answer not in the manual?

Questions and answers

Summary of Contents for Fostex 6301ND

  • Page 1 (587416) Owner's Manual Active monitor speaker 6301ND/NX/NE/NB Thank you for purchasing this Fostex product. This manual provides instructions for basic use of the unit. Read this before using the unit for the first time. © FOSTEX COMPANY All Right Reserved...
  • Page 2: Warnings And Precautions

    „ WARNINGS and PRECAUTIONS „ • CAUTION: To prevent electric shock hazard, do not connect to mains power ATTENTION: Danger d’explosion si les piles sont remplacées de façon supply while grille is removed. incorrect. Remplacer les piles seulement par le même type de pile ou ATTENTION: Pour éviter tout risque de choc électrique, ne connectez pas l’équivalent.
  • Page 3 Introduction The 6301N series are small monitors with built-in amplifiers for various kinds of monitoring. „ Features of 6301ND/NX/NE/NB „ • The cone–shaped, full-range speaker produces stable sound. • As the speaker is compact and consists of a single unit, it can be placed anywhere.
  • Page 4: Part Names And Functions

    Part names and functions „ Front „ (same for 6301ND/NX/NE/NB) [VOLUME] Adjusts the volume. [POWER] indicator Lights to indicate the state of the unit. [ON/OFF] button Turns the unit on/off. • Use a standard AC outlet. • Disconnect the plug from the outlet when the unit will not be used for a long time.
  • Page 5 [INPUT SEL] switch 6301NX/NE Used to select the type of analog signal that the digital signal is transformed into. Choose between left and right (R+L), left only (L), and right only (R). [AC IN] terminal Used to connect to a power outlet using the supplied power cord.
  • Page 6 The [POWER] indicator • 6301ND Unlit: The power is off Lit in green: A device is connected to the [DIGITAL IN] terminal and the digital signal is locked Lit in orange: A plug is inserted in the analog input terminal (phone) Lit in red: In standby •...
  • Page 7: Troubleshooting

    Solutions There is no sound. • Check the connection. (  page 4, page 5, page 6) • Check the set volume of each device. Specifications 6301ND 6301NX 6301NE 6301NB Type Sealed powered speaker system Speaker 100 mm cone-shaped, full-range speaker × 1...
  • Page 8: Dimensional Drawings

    Dimensional drawings (6301ND is pictured above, but the external dimensions are the same for each model.)
  • Page 9: Optional Accessory

    Ask a professional to fix the unit to a wall using firmly using the screws supplied with EB-6301. the bracket. Otherwise the unit may fall and cause accidents Fostex is not responsible for accidents and leading to injuries and damage. casualties caused by using the bracket. 6301ND/NX/NE/NB...
  • Page 10 „ Accessories of EB-6301 „ • Mounting screw × 2 • Rubber washer (with no grooves) × 2 • Rubber washer (with grooves) × 2 „ Dimensional drawings of EB-6301 „...
  • Page 11 „ Attaching EB-6301 „ 1 Remove the screws on the top and bottom of the 6301N series. 2 Attach the rubber washers (with no grooves) to the top and bottom of the unit. 3 Fit the rubber washers (with grooves) onto the mounting screws. 4 Adjust the unit to your preferred position in the bracket, then attach and tighten the mounting screws prepared in step 3.
  • Page 12: Declaration Of Ec Directive

    In the electrical fast transient/burst requirements, surge, conducted disturbances by radio-frequency fields, power frequency magnetic field, radiate electromagnetic field requirements and static electricity discharging environment, this could be affected by generation of noise in some cases. FOSTEX DISTRIBUTORS LIST IN EUROPE * Including non-EU countries (as of Jan. 2014) Austria...
